The Crestron® Ultimate In-Wall Subwoofer ULTIMATE IWS82-AW-W-T-

EACH made by Origin Acoustics delivers the pinnacle of performance for

demanding residential installations. The ULTIMATE IWS82-AW-W-T-

EACH is an in-wall subwoofer designed to produce deep, gratifying bass

in any room.

In the

In the In the Box

Box

BoxBox

1 ULTIMATE IWS82-AW-W-T-EACH

 

Additional Items

Additional Items

Additional ItemsAdditional Items

1 Grille

1 Cutout Template

Installation

Installation Installation

Prepare the

Prepare the Prepare the Mounting

Mounting

Mounting Mounting Hole

Hole

HoleHole

Before finalizing the speaker location, check to make sure there are no

fixtures, pipes, air ducts, joists, or other possible obstructions. If

applicable, use a good quality stud finder to locate joists.

To identify obstructions, do the following:

 Use a drywall saw to cut a small hole at a 45° angle. An angle cut lsimplifies repair since the removed piece can be reinserted to help

plug the hole.

 Use a piece of stiff wire, bent into an L shape, with one end long lenough to explore an area equal to the size of the speaker with the

toggle clamps extended. Insert the wire into the hole, make sure it

rotates freely in a complete circle and that there is sufficient depth.

If there are no obstructions, use the supplied template to trace an

outline of the mounting hole on the wall. Cut the final mounting hole at

a 90° angle to the wall.

ULTIMATE

ULTIMATEULTIMATE IWS82-AW-W-T-EACH

IWS82-AW-W-T-EACH

IWS82-AW-W-T-EACHIWS82-AW-W-T-EACH QuickStart

Ultimate

UltimateUltimate In-Wall

In-Wall

In-WallIn-Wall Dual

Dual

DualDual 8

88 in.

in.

in.in. Subwoofer,

Subwoofer,

Subwoofer,Subwoofer, All

All

AllAll Weather,

Weather,

Weather,Weather, White

White

WhiteWhite Textured,

Textured,

Textured,Textured, Single

Single

SingleSingle

Paint the

Paint the Paint the Speaker Grille

Speaker Grille

Speaker GrilleSpeaker Grille

Painting the speaker grille should be done prior to mounting.

1. Carefully remove the thin cloth on the underside of the grille, and set

it aside for reinstallation.

2. Lightly spray paint the front of the grille from a distance. Be careful

not to plug any of the holes.

3. Once the paint is dry, put the cloth back on the underside of the grille.

Install the

Install the Install the Speaker Cable

Speaker Cable

Speaker CableSpeaker Cable

Run the speaker cable (not included) from the audio source to the

speaker location, observing all appropriate local codes. Strip the ends of

the speaker cable approximately 0.25 in. to 0.50 in. (~6 mm to ~12 mm)

and twist the strands.

Connect the

Connect the Connect the Speaker Cable

Speaker Cable

Speaker CableSpeaker Cable

Connect the speaker cable (not included) to the spring terminals by

pressing the top of the terminals down and inserting the exposed

strands into the hole. Make sure that the positive wire is attached to the

red connection, and the negative wire is attached to the black

connection.

Mount/Remove the

Mount/Remove the Mount/Remove the Speaker

Speaker

SpeakerSpeaker

On the speaker, make sure all the Toggle clamps are in the unlocked

position.

1. Fit the speaker into the hole, and using a screwdriver (not included)

turn the screws clockwise.

2. Tighten the screws until the speaker is secured to the wall; do not

overtighten.

3. To remove the speaker, turn the screws counterclockwise until the

toggle clamps rotate inward. Remove the speaker carefully from the

hole.

ULTIMATE

ULTIMATEULTIMATE IWS82-AW-W-T-EACH

IWS82-AW-W-T-EACH

IWS82-AW-W-T-EACHIWS82-AW-W-T-EACH QuickStart

Ultimate

UltimateUltimate In-Wall

In-Wall

In-WallIn-Wall Dual

Dual

DualDual 8

88in.

in.

in.in.Subwoofer,

Subwoofer,

Subwoofer,Subwoofer, All

All

AllAllWeather,

Weather,

Weather,Weather, White

White

WhiteWhite Textured,

Textured,

Textured,Textured,Single

Single

SingleSingle
