Side 1/6

VECTOR CS1565 Series

Vector™ Performance Loudspeaker – 15” 2-Way Coaxial 60° x 45°

crestron.com | 800.237.2041

>A space-efficient, professional performance loudspeaker for

large indoor spaces

>Advanced 15” (381 mm) coaxial transducer with 60° x 45° HF horn

>Available with HF horn rotated 90° for horizontal orientation

(model VECTOR CS1565-RH)

>Integrated HF compression driver with 3 inch (76 mm)

titanium diaphragm

>Delivers superior performance in combination with a

Crestron Avia™ DSP

>Precisely tuned for accurate, uncolored sound reproduction

>Produces high intelligibility and natural sound quality for speech

and program material

>Achieves smooth bandwidth performance both within and

beyond the specified coverage pattern

>Uniform directionality affords consistent, targeted pattern control

>Capable of high SPLs without coloration or distortion

>Provides excellent cost-benefit compared to more

conventional designs

>40° trapezoidal enclosure affords a clean, unimposing appearance

>Rugged yet light construction for easy, reliable installation

>Concealed M10 mounting points

>Yoke bracket or forged shoulder eyebolts available separately

>Neutrik® speakON® input and pass-through connections

Crestron® Vector™ Performance Loudspeakers provide a professional

sound reinforcement speaker solution for large indoor spaces and venues.

Featuring a revolutionary coaxial transducer design complemented by

advanced Crestron Avia™ digital signal processing, Vector loudspeakers

deliver exceptional intelligibility and natural sound quality for speech

reinforcement, foreground music, and multimedia presentation applications.

Compact, aesthetically-pleasing enclosures afford remarkable performance

in less space. A choice of sizes and coverage patterns is offered to address

the varying applications and room geometries found in auditoriums,

theaters, lecture halls, houses of worship, convention centers, hotel

ballrooms, sports facilities, night clubs, and public spaces.

The Vector CS1565 is a compact, trapezoidal speaker enclosure loaded

with one 2-way coaxial transducer composed of a 15” (381 mm) LF driver

and a 60° x 45° HF horn with 3” (76 mm) diaphragm compression driver.

Advanced engineering and construction achieve a space-efficient speaker

design with high output capability and consistent pattern control. Its

integrated coaxial transducer aligns the low-frequency and high-frequency

elements to produce precise transient response and uniform directionality

across the entire frequency range.

Note: Specify model VECTOR CS1565-RH for applications requiring

the enclosure to be installed in a horizontal orientation. The VECTOR

CS1565-RH is assembled with its high-frequency horn rotated 90°.

Advanced Coaxial Transducer

The transducer in the Vector CS1565 represents a revolutionary

advancement in coaxial speaker design. Its high-frequency horn features

a large 3 inch (76 mm) titanium diaphragm compression driver, which

operates at frequencies lower than typical, allowing the high-frequency

horn to smooth the response of the low frequency section to reduce

shadowing of the woofer by the horn. The woofer’s large radiating surface

works in conjunction with the high-frequency horn to improve directional

control at the lower end of the horn’s frequency range resulting in better

pattern control throughout the critical voice band. The large diaphragm

also allows the compression driver to produce higher sound pressure

levels without distortion to deliver incredibly clear and dynamic sound

quality for both speech and program material.

The complete coaxial transducer assembly employs a single, powerful

ceramic magnet with dual-gap geometry, which minimizes the spacing

between the compression driver and woofer voice coils. This integrated

approach virtually eliminates the delay between the two drivers, allowing a

passive crossover to be used to seamlessly blend the horn and woofer into

a single point source. The reduced demand on the internal crossover helps

to maximize efficiency and damping, resulting in performance rivaling a

more expensive bi-amplified design. Using a single magnet also reduces

the speaker’s weight, size, and cost.

VECTOR CS1565 Series Vector

™ Performance Loudspeaker – 15” 2-Way Coaxial 60° x 45°

crestron.com | 800.237.2041

Crestron Avia™ Digital Signal Processing

Every aspect of the Vector CS1565 is designed to take advantage of

the signal refining abilities of a Crestron Avia DSP. Vector loudspeakers

and Crestron Avia processing work synergistically to produce a superior

speaker system tuned for accurate, uncolored reproduction of voice and

program signals. Precision signal processing is employed to accomplish

what can’t be done physically, strategically eliminating harsh-sounding

resonances caused by horn reflections while retaining every nuance of

the original signal.

Further refinements are employed to maximize transient response and

deliver smooth bandwidth performance both within and beyond the

speaker’s nominal coverage pattern. The result is an extremely natural

sounding speaker system with superior pattern control, improved

intelligibility, reduced listener fatigue, and higher gain before feedback.

Versatile Installation

The Vector CS1565 is particularly effective in systems where targeted

pattern control is desirable, including front of house, delay fill, and

foreground music applications. Its clean appearance and familiar format

facilitate acceptance by architects and interior designers, and the 40°

trapezoidal angle allows it to be mounted near walls or ceilings without

obstructing sight lines. Concealed M10 mounting points are included to

accommodate either an optional yoke bracket eyebolts or forged shoulder

(each sold separately).

Note: Specify model VECTOR CS1565-RH for applications requiring

the enclosure to be installed in a horizontal orientation. The VECTOR

CS1565-RH is assembled with its high-frequency horn rotated 90°.

SPECIFICATIONS

Performance

Transducers: 15 inch (381 mm) woofer with 3 inch (76 mm) voice coil,

coaxial horn with 3 inch (76 mm) titanium diaphragm compression driver,

single ceramic magnet

Beamwidth: 60° x 45° nominal, available with horn rotated 90° for

horizontal orientation (model VECTOR CD1565-RH)

Impedance: 8 Ohms nominal

Frequency Range: 43 Hz to 18 kHz (+3/-10 dB)

Power Handling: 400 Watts based on the AES power handling of

the transducers

Nominal Sensitivity: 103 dB at 1W/1m whole space using band limited

pink noise without processing

Nominal Maximum SPL: 135 dB peak, 129 dB continuous, at 400W/1m

without processing

Equalized Sensitivity: 97 dB at 1W/1m using an EIA-426-B signal

with processing

Equalized Maximum SPL: 129 dB peak, 123 dB continuous, at 400W/1m

with processing

Processing & Amplification

Digital Signal Processing: Requires processing using one output channel

of a Crestron Avia DSP, settings provided via model-specific “Speaker

Profiles” in the Crestron Avia Audio Tool software (SW-AAT)

Amplification: Requires a single channel of amplification

Recommended Amplifier Power: 400 to 800 Watts at 8 Ohms

Connections

Input: (2) Neutrik NL4 speakON 4-pole chassis connectors;

Pins 1 +/–: Speaker input and pass-through;

Pins 2 +/–: Pass-through only

Environmental

For indoor use only

Construction

Enclosure: Void-free, exterior grade Baltic Birch plywood; black

painted finish

Grille: Steel, black powder coat finish

Yoke Mounting: (2) M10 yoke points (yoke bracket sold separately)

Suspension: (12) M10 eyebolt angle points and (1) M10 pull back point

(eyebolts sold separately)

Dimensions

Height: 30.00 in (762 mm)

Width: 20.73 in (527 mm)

Depth: 19.75 in (502 mm)

Weight

61.0 lb (27.7 kg)
