CRUX RVCCH-75WT Manual

CRUX Ikke kategoriseret RVCCH-75WT

Læs gratis den danske manual til CRUX RVCCH-75WT (3 sider) i kategorien Ikke kategoriseret. Denne vejledning er vurderet som hjælpsom af 2 personer og har en gennemsnitlig bedømmelse på 4.6 stjerner ud af 1.5 anmeldelser. Har du et spørgsmål om CRUX RVCCH-75WT, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/3

- Interface includes Audio / V eo I t to co ect an extra A/V source. id npu nn

- Spare Tire mo t reverse amera inc ed. un c lud

- tes MYGIG Screen for enabli Video features. Ac�va ng

- Su orts vehicles with ma pp nual transmission. See note below.

- Plug and Play co ec ons for ease of use. nn �

NOTE: Does not supply +12V Reverse Trigger on vehicles with manual transmission. Camera power

must be tapped from the + V reverse light wire ins ad12 te . Video in Mo�on will not work for

manual transmissions.

- MyGig Naviga on Radio �

CH- WT MODULE 75

CH- WT HARNESS 75

CH- S CAMERA 01

Rev.092617

1 / 3

1. Remove the outside mounted spare re.

2. Mount the metal bracket onto the spare re bolts and secure with the star washers. camera’s

3. Route the cable towards the radio and make the power and video connecons.

4. Remove the factory radio to gain access to the factory connectors.

5. Plug in the T-harness with WHITE and GRAY connectors. (See Wiring Diagram above)

6. Connect the 8-pin Molex connector from the T-harness with GRAY connectors to the CAN Interface.

7. Use the WHITE 12V Reverse Output wire to power the camera (see Wiring Diagram above). DO NOT

connect the red power wire, near the camera, insulate this red wire to avoid to the reverse light and

from shorng. the vehicle has a manual transmission, the camera power must be tapped to the If

+12V reverse light wire instead. In this case the WHITE 12V Reverse Output wire is not used and

should be insulated to avoid from shorng.

8. Plug in the YELLOW MALE RCA from the camera cable to the YELLOW FEMALE RCA of the T-Harness

with WHITE connectors.

9. Connect GREEN wire to +12V for non permanent Video in Moon feature. a

10. Set the proper DIP Switch sengs on the CAN Interface. (See Chart above)

11. Cut the thin white wire on the camera cable to enable the parking guide lines.

12. Test the camera before re-installing the radio.

Rev.0926 17

2 / 3

Please note that the WHITE 12V

Reverse Output wire does not

supply power on vehicles with

manual transmission and should

be insulated to avoid from

shorng. Connect the camera

power to the OE reverse light

+12V wire instead.

DIP SWITCH SETTING

DIP 1

OFF

VIM Disable

DIP 2

Rear-View Camera Enable

DIP 3

OFF

N/A

DIP 4

OFF

Opon for GREEN Wire

DIP 5

OFF

CAN Terminaon Radio Side

DIP 6

CAN Terminaon Car Side
