Side 1/3
- Acvates Rear-view camera funcon via OBD II port.
- Forced rear view camera opon.
- Retains funconality of Factory-installed Navigaon System for passenger access at anyme.
- Plug and Play Installaon.
- Ford My Touch 8” MS-Sync Gen 3
1. OBD2 dongle can be used for one vehicle.
2. During programming process, maintain baery voltage above 12V.
4. Programming process takes less than 15 seconds.
5. Vehicles with Manual Transmission not compable. are
RVCFD-79F
VIM MODULE
RVCFD-79F VIDEO
INTERFACE MODULE
RVCFD-79F
OBD2 CODER
RVCFD-79F
T- HARNESS
OBD2 CODER:
The LEDs are located inside the right side of the 8-Pin connector of the OBD2 Coder.
LED
Descripon
BLUE
Solid
RED
Solid
Blinking with blue LED OFF
GREEN
Solid
Blinking with blue LED OFF
RED & GREEN
Solid
Normal Operaon
Invalid Operaon
License Expired (OBD2 Coder has been used)
RVC Coding successful
License Invalid / Blue LED ON = Diagnosc
coding in progress
Can Communicaon Error or Diagnosc
session terminated with error
rev.082117
1 / 3
LEDs
RVCFD- Video Interface Module: 79F
The LEDs are located inside the left side of the 14-Pin connector of the Video Interface Module.
BLUE ON
BLUE OFF
RED ON
RED OFF
Valid CAN / Normal operaon mode
Sleep Mode
RVC Programmed Successfully
RVC Coding has been completely removed
The OBD2 Coder can only be licensed to one vehicle. To verify if the OBD2 Coder has been used or
not, connect power to the OBD2 connector as follows: Pin 4 or 5 to Ground and Pin 16 to +12V and
observe the LED condion:
RED ashing = License has been used
GREEN ashing= Valid License (not yet used)
1. Locate the OBD2 port, typically under the steering wheel column.
2. Turn the key to the ON posion (do not start the engine). Turn o head lights.
3. Turn on radio and wait unl it is in its normal operaon.
4. Plug the OBD2 Coder into the OBD2 port.
5. Wait unl you see a solid GREEN LED then remove the OBD2 coder from the OBD2 port.
6. Turn the key to the OFF posion, remove key, open driver door then close it.
7. Open the driver door, start engine and put the gear in REVERSE. If a camera is connected, you will
see the camera image on the radio screen. If no camera is connected, within 20 seconds of
pung the gear in reverse, the radio screen will switch to a blue screen with the message
“Service Rear Vision System. This means that the RVC was coded successfully.
8. There is an opon to the remove the RVC coding. To do this, repeat steps 2 to 5 and put the gear
in reverse to verify that the coding has been removed.
1. Remove the display monitor and connect the RVCFD-79F 54-Pin T-harness between the factory
display and harness.
2. Connect the WHITE wire on the RVCFD-79F harness labeled “Reverse Output 12V 500mA” to
the camera +12V power (RED wire) and the BLACK wire labeled “Camera Ground” to the camera
ground wire.
3. Connect the YELLOW female RCA labeled “VDO Signal Output” to the camera cable RCA.
4. Apply the e-brake and put the vehicle in reverse gear. Verify the camera image on the display.
LEDs
Rev.082117
2 / 3
