ASSEMBLY INSTRUCTION MODEL #4456-GA-CL-MWP
LIGHTING THE WAY FOR SIXTY YEARS
All electrical components must be
installed by a licensed electrician
in accordance with the National
Electric Code and the appropriate
local electrical codes.
WARNING:
Electrical Danger Turn Power Off
R
CUL
You will need 12-Candelabra Base Bulb
40 Watts Recommended 60 Watts Max
USE LED BULBS FOR EXTENDED USE
How to Install
WARNING: This product can expose you to Lead,
which is known to the State of California to cause cancer
and/or birth defects or reproductive harm. For more
information go to www.P65Warnings.ca.gov
Crystal Sets
DETAILED ILLUSTRATION
A 52Sets. (1)14mm + AS20-2"
.
.
.
. .
B 4Sets. AS20-2.5"(No Jewel)
.
.
.
. .
C 12Sets. (1)14mm + AS20-2.5"
.
.
.
. .
D 4Sets. (2)14mm + AS20-2.5"
.
.
.
. .
E. 24Sets. (1)14mm + AS20-2.5"
F 8Sets. (14)14mm
.
.
.
. .
G 1Piece. (4)14mm + AS8-40mm Ball
.
.
.
..
GD E
AC F
B
The fixture is dry rated
A
B
C
D
E
F
G
24"
29"
(4(A) CRYSTALS)
C
A
EE
1.Do a complete inventory of all parts and components
before you start installing.
2.Screw the top glass dish & Loop on the coupling.
4.After safety attaching fixture into outlet box, install
bobeches, bulbs (not included) and proceed to connecting
the power.
5.When you begin to dress the fixture,start with packet
labeled(A).
6.IMPORTANT: Apply crystal sets in alphabetical order.
3.Place the glass dish and small metal dish over the bottom
metal cover and secure with the finial.
Part Number
B
PART NUMBER MODEL #4456-GA-CL-MWP
LIGHTING THE WAY FOR SIXTY YEARS
A
C
E
F
G
H
I
J
D
Outlet box Part Numbers
B.
.
.
.. (1)-Mounting Plate
C (2)-Outlet Box Screws
.
.
.
..
D.
.
.
.. (1)-Lock Washer
E.
.
.
.. (1)-Hex Nut
F.
.
.
.. (1)-Nipple
G (1)-Canopy; w5" x h1" (
.
.
.
.. XFB4454GACAN5IN)
H.
.
.
.. (1)-Collar Ring
I.
.
.
.. (1)-Collar Loop
J.
.
.
.. (1)-Chain; 72", 4mm (XFB4454GACHA4MM)
K.
.
.
.. (1)-Ground Wire
L.
.
.
..
(1)-Frame
M.
.
.
..
A (2)-Wire Connector
.
.
.
..
N.
.
.
..
P.
.
.
..
(1)-Middle Glass Dish Ø4", 11mm hole (XFB4455DIBOB4IN)
(2)-Metal Dish
(1)-Bottom Glass Dish; Ø4", 11mm hole, 4pin (XFB4454GABOB4IN)
Q.
.
.
..
S.
.
.
..
R.
.
.
..
(12)-Candle Sleeve; h3" ( )XFB4452GACDL3IN
(12)-Bobeche; Ø4", 24mm hole, 4pin (XFB4454GABOB4IN)
( )-Rosette
PART BAG : Includes Parts A, CⅠ
PART BAG : Includes Parts B, D, E, F, H, IⅡ
O.
.
.
..
(2)-Finial ( )XFB4454CHFIN
X
Y
Z
S
T
U
V
L
Q
P
U.
.
.
..
V.
.
.
..
X.
.
.
..
W.
.
.
..
T.
.
.
..
Z.
.
.
..
Y.
.
.
..
(1)-Loop
(1)-Top Glass Dish Ø4", 13mm hole, 4pin(XFB4456DIBOB4IN)
(1)-Metal Dish
(2)-Metal Dish
(1)-Glass Column
(1)-Thread
(1)-Metal Sleeve
