ASSEMBLY INSTRUCTION MODEL #GAB-B7303-GA
1.Do a complete inventory of
all parts and components
before you start installation.
2.Attach the light cluster to
the swivel.
3.Insert recommended bulb
(not included).
4.Attach the top end of the chain
to the hook located inside the
top banding.
5.Raise the canopy onto the
outlet box, and secure it with
the ball nuts.
6.Dress the fixture with crystal
as illustrated.
A
B
C
A=
B=
C=
Bea
Bea
Bea
BeaBea d Set
d Set
d Set
d Setd Set s
s
s
ss
A.16 Sets.
(3)25mm 2 holes
B.28 Sets.
(4)25mm 2 holes
C.40 Sets.
(5)25mm 2 holes
H
H
H
HHo
o
o
oow t
w t
w t
w tw to I
o I
o I
o Io In
n
n
nns
s
s
sst
t
t
tta
a
a
aal
l
l
lll
l
l
ll
Canopy(W9.84",H0.98")
You will need 3- Candelabra Base Bulb
40 Watts Recommended 60 Watts M ax.
USE LED BULBS FOR EXTENDED USE
This fixture i s DAMP rated
A
MODEL #GAB-B7303-GAPART NUM BER
A. (1) - Mounting Hardware
B. (1) - Canopy(W9.84",H0.98") #XRE7303GACAN9.84IN
C. (2) - Ball Nut #XRE7303GABANUT
D. (1) - Swivel
E. (1) - Light Cluster
F. (3) - Top Chain(L5",D1.8MM)
G. (1) - Middle Ring
H. (3) - Bottom Chain(3.74",D1.8MM)
I. (1) - Bottom Ring
C
D
E
B
H
G
F
I
