Side 1/2

ASSEMBLYINSTRUCTIONMODEL#KEN-8304-BF

CRYST

RAMA

WARN ING:

Electri calDan ger Tur nPoweroff

WARNING: ThisproductcanexposeyoutoLead

whichisknowntothestateofCaliforniatocausecancer

and/orbirthdefectsorreproductiveharm.Formore

informationgotowww.P65Warnings.ca.gov

LI G HT I N GT H EW A YFO RS I X T YY E A R S

installedbyali censedelectri ci an

inaccordancewiththeNati onal

Allelectri calcompo nent smustbe

Electri cCodeandtheappropriate

locale le ctricalcodes.

1Pc

3Pcs

ROD2=

ROD1=

6”

12”

ROD2

ROD1

5-7/8’’

22-1/2’’

62-1/2’’

18-1/4’’

20-5/8’’

3-1/8’’

3-7/8’’

15-1/4’’

GLASSPANEL

GLASSDIFFUSER

1’’

CLIP

SCREWS

CLIP

METALFRAME

GLASSDIFFUSER

GLASSPANEL

(4PCS)

TOPMETALRING

SOCKET

LIGHTCLUSTER

CENTER

ROD

HANGINGROD

SCREW

COUPLER ROD

Howtoinstall

8.Determinethepreferredhangingheightandadjustthe

requiredrods.

10.Slipcanopykitalongwireandthreaditintothetopofthe

rodassembly.

12.Installthebulb(notincluded)intothesocket.

9.Feedthewiresthroughtherodsandconnectthemtogether.

6.Separatethemountingplatefromthecanopykitbyremoving

thescrews.

7.Installthemountingplatetotheoutletboxusingtwooutlet

boxscrews.

11.Installcanopyontothemountingplate,andsecurewiththe

mountingscrews.

This fixtu re is Damp rated

Y ouw illn ee d4- Me diu mBaseB ul b

60WattsRecom mende d100WattsMax.

USELEDBUL BSF OREXTE NDEDUSE

1.Slidetheglassdiffuserontothebottomofmetalframeand

secureitwithclips.

2.Slidetheglasspanelsinsidethemetalframeandsecureit

withclips.

3.Slipthecenterrodassemblyalongwireandthreadontothe

nipplelocatedonthetopofthelightcluster.

4.Insertthehangingrodintothesideholesoftopboxonthe

centerrod,andsecurethehangingrodfromthetopwiththe

screws.

5.Putthetopmetalringoverthemetalframe.Lineupthehole

onthebottomofhangingrodwiththeholeonthetopmetal

ringandthebracketonthemetalframe,and secureitwith

screws.

BRACKET

CRYST

RAMA

L I G H T I N GT H EW A YF O RS I X T YY E A R S

PartNumber

PartNumbers

A.(1)-Mountinghardware

C.(1)-CanopykitW5-7/8’’xH1’’ #XRF8303BFCAN5.875IN

G.(1)-Coupler

F.(3)-RodD5/8’’xL12’’ #XRF8303BFROD12IN

D.(2)-Mountingscrew

E.(1)-RodD5/8’’xL6’’ #XRF8303BFROD6IN

ASSEMBLYINSTRUCTIONMODEL#KEN-8304-BF

I.(1)-Centerrodassembly#XRF8304BFSTEM

B.(1)-Mountingplate

J.(4)-HangingrodD3/8’’xH12-1/8’’ #XRF8304BFSIDEROD

K.(1)-Lightcluster

L.(1)-Topmetalring

M.(4)-Glasspanel

N.(1)-Glassdiffuser#XRF8304DIFF20.625IN

O.(1)-Metalframe

P.(4)-Screw

H.(4)-Screw
