DI-784

11a/11g Dualband

108Mbps Wireless Router

5V DC Power Adapter

speciﬁcations subject to change without notice.

Before You Begin

1. If you purchased this router to share your high-speed Internet connection with other

computers, you must have either an Ethernet-based Cable or DSL modem with an

established Internet account from an Internet Service Provider (ISP).

2. It’s best to use the same computer that is connected to your modem for conﬁguring the

DI-784 Dualband Wireless Router. The DI-784 acts as a DHCP server and will assign

all the necessary IP address information on your network. See Appendix at the end

of this Quick Installation Guide or the Manual on the CD-ROM for setting each

network adapter to automatically obtain an IP address.

Check Your Package Contents

DI-784 11a/11g Dualband 108Mbps Wireless

Router

CD-ROM (containing Manual and Warranty)

Ethernet (Straight-Through) Cable

If any of the above items are missing, please contact your reseller.

This product can be set

up using any current web

browser, i.e., Internet Explorer

6 or Netscape Navigator 7

Using a power supply

with a different voltage

rating will damage this product

and void the warranty

Connecting The DI-784 Wireless

Router To Your Network

C. LAN PORTS These

are the connections

for Ethernet cables

to Ethernet enabled

computers.

Reset Button

Pressing this button restores the Router to

its original factory default settings.

B. WAN PORT This is

for the connection of an

Ethernet cable to the Cable

or DSL modem.

A. Receptor for

Power Adapter.

First, connect the power adapter to the at the back panel of the receptor

DI-784 and then plug the other end of the power adapter to a wall outlet or power

strip. The Power LED lights up indicating proper operation.

B. 1. Power off your Cable or DSL modem; devices that do not have a on/off switch and

will require you to unplug the power adapter. Now, the DI-784 should be powered on

and the Cable / DSL modem should be turned off.

Cable / DSL modem ( ) – DI-784 ( )

Power Off Power On

2.Connect an Ethernet cable to the Ethernet jack located on the Cable / DSL modem.

After the Ethernet cable is securely connected, power on the Cable / DSL modem by

turning on the unit or plugging in the power adapter.

Cable / DSL modem ( ) – DI-784 ( )

Power On Power On

3. Insert the other end of the Ethernet cable to the WAN PORT on the back panel of

the DI-784. The WAN LED light will illuminate to indicate proper connection. If the

WAN LED is not illuminated, please go back to step B1 and repeat the steps.

C. Insert an Ethernet cable to on the back panel of the DI-784 and an LAN Port 1

available Ethernet port on the network adapter in the computer you are using to

conﬁgure the DI-784. The LED light for LAN Port 1 illuminates to indicate proper

connection. (Note: The LAN Ports on the DI-784 are Auto-MDI/MDI-X. Meaning you

can use a straight-through or crossover-Ethernet cable in the LAN Ports.)

D. Computers equipped with D-Link 802.11a/b/g wireless adapters will be able to

connect out of the box with the DI-784 using their default wireless settings.

D. Antenna

Used to

wirelessly

connect to

802.11a/b/g

adapters.
