DAP-X3060OU
Quick Installation Guide
Nuclias Connect AX3000 Outdoor Access Point
For FREE Nuclias Connect
centralized management software and APP,
please visit https://download.nuclias.com/
Before You Begin
This installation guide provides instructions
for installing the DAP-X3060OU on your
network. Additional documentation is also
available on the D-Link support website.
• Nuclias Connect Manual: For additional
information and instructions on how to
configure the device using Nuclias Connect.
• DAP-X3060OU User Manual: For
additional information and instructions
on how to configure the device
using the web user interface.
Package Contents
This DAP-X3060OU package
includes the following items:
• DAP-X3060OU Access Point
• Mounting Plate and Hardware
• Grounding Wire
• Quick Start Guide
• Mounting kit (Wall/Pole Mount)
- Stainless steel mount base x 1
- Stainless tie back straps x 2
- Wall screw x 4
- Wall plug p1-x4
- Stainless mount screw (hexagonal hole) x1
- M3 Screw x1
- M25x1.5 Cable Gland x2
- M25 Slotted Cap x2
If any of the above items are
damaged or missing, please contact
your local D-Link reseller.
Note: To power the unit, use an
802.3at PoE Switch or PoE Injector.
System Requirements
• Computers with Windows®, macOS®,
or Linux-based operating systems
with an installed Ethernet Adapter
• Internet Explorer 11, Safari 7,
Firefox 28, or Google Chrome 33
and above (for configuration)
Hardware Overview
LED Indicators
CON LAN (PoE)
Figure 1: Front Panel LED
# LED Description
1Power/
Status
Green (Solid) - Device
operational
Red (Flashing) - Device
booting up/Device
malfunctioned
Red (Solid) - Device
boot up has failed
Table 1: LED Description
Interface Connectors
CON LAN (PoE)
Figure 2: Bottom Connectors
# Connector Description
1Mounting
Lock
Connector for the
mount screw.
2 Reset
Press and hold for 15
seconds to factory
reset the device.
3
CON
(Console)
Port
RJ45 console port
for connection to a
management computer.
# Connector Description
4LAN (PoE)
Port
2.5G RJ-45 port for
data and Power over
Ethernet (PoE) power.
Note: Shielded Ethernet cables are highly
recommended in all networking environments.
Table 2: Interface Description
Figure 3: Rear Connectors
# Connector Description
1Grounding
Wire
Connector for the
grounding wire.
2Wall/Pole
Mount
Mount to connect to
the mounting plate
on a wall or a pole.
Table 3: Interface Description
Installation
Using Power over Ethernet (PoE)
1. Use an Ethernet cable to connect the
LAN (PoE) port on the DAP-X3060OU
to a PoE power source device such as
an 802.3at PoE switch or PoE injector.
Conguration
Using Nuclias Connect
The DAP-X3060OU is designed to be
managed through Nuclias Connect. Refer
to the for Nuclias Connect Manual
detailed configuration instructions.
Note: D-Link recommends manually
configuring the device before mounting it.
Nuclias Connect App
Conguration
1. Download the free Nuclias Connect
app from the App Store or Google Play
by searching for Nuclias Connect or
by scanning the QR code below.
2. Open the Nuclias Connect app and
follow the onscreen instructions to
discover and set up your device.
Manual Conguration
Note: The management computer,
DHCP server and DAP-X3060OU
must be in the same subnet.
Use one of the following methods to
access the web user interface:
Connecting through Ethernet
1. Use an Ethernet cable to connect the
DAP-X3060OU to the management
computer, or to the switch or router the
management computer is connected to.
2. Manage the access point from a
computer. Enter dapx3060OU.local
in the address field of your browser.
3. Log in to the administration user interface.
The default login information is
Username: admin
Password: admin
Connecting Wirelessly
1. Connect the management computer to the
default SSID of the DAP-X3060OU, “dlink”.
2. Manage the access point from a
computer. Enter dapx3060OU.local
in the address field of your browser.
3. Log in to the administration user interface.
The default login information is
Username: admin
Password: admin
Mounting
Figure 4: LAN Port Waterproof Enclosure
1. Connect an Ethernet Cable to the
LAN (PoE) port on the DAP-X3060OU.
Use the LAN Port Waterproof
Enclosures to seal the ports.
Note: Shielded Ethernet cables are highly
recommended in all networking environments.
Mounting on a Pole
Figure 5: Attaching the Mounting Plate
1. Secure mount base to the pole with the
two stainless tie back strap sets. Ensure that
the tie back is locked securely.
Figure 6: Mounting the Device
2. Align and slide the DAP-X3060OU
down so that the mounting plate
securely locks to the DAP-X3060OU.
1
1 2 3 4
Gland Sealing
Nut
Sealing
21
Mounting on a Solid Wall
Figure 7: Attaching the Mounting Plate
1. Use the mounting plate to mark the
location where to drill the holes in the wall.
2. Drill holes on the markings and place the
included anchors into the drilled holes.
3. Align and place the mounting plate on
top of the anchors and use the included
screws to secure the mounting plate to
the surface.
Figure 8: Mounting the Device
4. Align and slide the DAP-X3060OU
down so that the mounting plate
securely locks to the DAP-X3060OU.
Securing the Mount Screw and
Connecting the Grounding Wire
Figure 9: Attaching the Mount Screw
1. Use the included mount screw
(hexagonal hole) to lock the
DAP-X3060OU to the pole/wall mount.
Figure 10: Securing the Mount Screw
STAINLESS SCREW, L=25.0mm, 1/4 x 4 PCS
(4008) 5/16 X 1 1/4 × 4 PCS
