D-Link’s 40G QSFP+ Module series are hot-swappable QSFP+ transceivers that plug into

QSFP+ slots on switches and support 40G Ethernet. The D-Link 40GBASE QSFP+ Module Series

transceivers oer customers a wide variety of 40G Ethernet connectivity options for data

centers, enterprise wiring closets, and service provider transport applications.

Quad Small Form-factor Pluggable Plus Format

The transceivers use the Quad Small Form-factor Pluggable Plus format (QSFP+) connectors,

which integrate four transmitting and four receiving channels. QSFP+ supports up to 10.5 Gb/s

per channel for applications such as 40G Ethernet.

Hot Pluggable

All D-Link transceivers are hot pluggable. ou Y can connect a transceiver while the system

is powered on without causing any issues, and easily swap one for another without having

to reboot the switch each time. This permits modules to be added or removed without

interrupting the network, facilitating maintenance and greatly reducing downtime.

40G Ethernet speeds

The transceivers all support 40G Ethernet, which results in very fast data transmissions of up

to 40 Gbit/s. This is 40 times faster than Gigabit Ethernet and enables the switch to handle

faster and higher data transmissions, making it very suitable for business needs.

• Quad Small Form-Pluggable (QSFP+) form factor

• Hot pluggable

• Supports 40G Ethernet

• RoHS compliant

• Multiple Source Agreement (MSA) compliant

• IEEE 802.3ba 40GBASE QSFP+ compliant

Product Highlights

Blazing-fast Performance

Support for 40G Ethernet provides the network

transmission speed that business environments

demand

Covers Vast Distances

Support for maximum cable of lengths between

100 met s re and 10 kilomet sre 1

is ideal for

businesses spanning multiple premises

Hot-Pluggable

Easily switch out transceivers while the power is

on, facilitating network maintenance and

minimising downtime

DEM-QX Series

40G QSFP+ Transceivers

Features

DEM-QX Series 40G QSFP+ Transceivers

Technical Specications

DEM-QX01Q-SR4 DEM-QX10Q-LR4

Transceiver Type • QSFP+ • QSFP+

Fib Media supportre

• Multi-mode • Single-mode

Distance Capacity

• OM3: 100 m

• OM4: 150 m

• 10 km

Compliant Standard • IEEE 802.3ba • IEEE 802.3ba

Connector • MPO • Duplex LC connector

Single/Bi Direction • Single direction • Single direction

Wavelength • 850 nm

• nm1310

Cable Type

•Multi mode 50/125 um OM3 or OM4 fib cable re

(Single 1x12 MPO receptacle (female))

• Single mode 9/125 um fib cablere

Power • 3.3 V • 3.3 V

Hot Pluggable  

MSA Compliant  

RoHS Compliant  

1 Distance capacity dependent on model.

For more information: www.dlink.com

D-Link European Headquarters. D-Link (Europe) Ltd., First Floor, Artemis Building, Odyssey Business Park West End Road, South Ruislip HA4 6QE, United Kingdom.,

Specifications are subject to change without notice. D-Link is a registered trademark of D-Link Corporation and its overseas subsidiaries.

Updated 201February 9

Produkt Specifikationer

Mærke:	D-Link
Kategori:	Ikke kategoriseret
Model:	DEM-QX01Q-SR4
Bredde:	18.4 mm
Dybde:	115.8 mm
Højde:	13.28 mm
Vægt:	40 g
Produktfarve:	Beige,Silver
Pakkevægt:	64 g
Pakkedybde:	131 mm
Pakkebredde:	74 mm
Pakkehøjde:	49 mm
Opbevaringstemperatur (T-T):	-10 - 75 °C
Relativ luftfugtighed ved drift (H-H):	0 - 85 %
Relativ luftfugtighed ved opbevaring (H-H):	0 - 85 %
Driftstemperatur (T-T):	0 - 70 °C
Certificering:	• FCC Class B\n• CE Class B \n• VCCI Class B\n• FDA/CDRH \n• TUV\n• CSA
Pallens bruttobredde:	1220 mm
Pallens bruttolængde:	1020 mm
Netværksstandarder:	IEEE 802.3ba
Harmoniseret systemkode (HS):	85369010
Bæredygtighedscertifikater:	RoHS
Indgangsspænding:	3.3 V
Maksimal dataoverførselshastighed:	40000 Mbit/s
SFP modtagertype:	Fiberoptisk
Grænsefladetype:	QSFP+
Fiber optisk strømstik:	MPO
Maksimal overførselsafstand:	150 m
Bølgelængde:	850 nm
Forsendelseskassens bruttovægt (indvendig):	4200 g
Produkter pr. forsendelseskasse (indvendig):	50 stk
Forsendelseskasses kassens bredde (indvendig):	260 mm
Forsendelseskassens længde (indvendig):	360 mm
Forsendelseskassens højde (indvendig):	310 mm
Forsendelsesemballage nettovægt:	3200 g
SFP transceiver standard:	SR4
Understøtter hot-plug:	Ja
Strøm (maks.):	0.35 A
Tx effekt (min.):	-7.6 dBmW
Tx effekt (maks.):	2.4 dBmW
Rx effekt (min.):	-9.5 dBmW
Rx effekt (maks.):	2.4 dBmW
Palle bruttovægt (luft):	272000 g
Antal papkasser pr. palle (luft):	60 stk
Antal pr. palle (luft):	3000 stk
Pallehøjde (luft):	1990 mm
Palle bruttovægt (hav):	272000 g
Antal papkasser pr. palle (hav):	60 stk
Antal pr. palle (hav):	3000 stk
Pallehøjde (hav):	1990 mm
Digital diagnose overvågning (DDM):	Ja
Link budget:	11.9 dB
