18-Port Unmanaged Desktop PoE Switch

DES-1018P/DES-1018MP

The D-Link® DES-1018P/DES-1018MP 18-Port Unmanaged Desktop PoE Switch enables users

to easily connect and supply power to PoE-capable devices such as wireless Access Points

(APs), IP cameras, and IP phones. The DES-1018P/DES-1018MP can also connect other Ethernet

devices like computers, printers, and a Network Attached Storage (NAS) to t into any type of

network application.

Power Over Ethernet IEEE 802.3af

The DES-1018P/DES-1018MP features 8 or 16 ports (respectively) that support the IEEE 802.3af

PoE protocol. Each of the PoE ports can supply up to 15.4 watts, with a total PoE budget of 80 watts

(DES-1018P) or 246.4 watts (DES-1018MP), allowing users to attach an IEEE 802.3af-compliant

device to the DES-1018P/DES-1018MP without requiring additional power. PoE is especially

suitable for devices that are far from power outlets or when users want to minimize the clutter

of extra cables as power is supplied via the Ethernet cables themselves.

Expand Your Network

The addition of two Gigabit combo uplink ports means businesses can increase their network

bandwidth using the speed of Gigabit Ethernet while oering redundancy so voice and

surveillance data are transferred reliably. The combo design can increase bandwidth by oering

two Gigabit copper or ber connections, giving administrators more options for expansion.

Cut Your Energy Costs

To help small businesses save on operating costs, the DES-1018P/DES-1018MP supports IEEE

802.3az Energy Ecient Ethernet (EEE). This feature senses network trac to automatically put

ports that are not being used to sleep, powering them on only when they are required. The

DES-1018MP also features a smart fan that automatically adjusts itself to reduce power

consumption and noise whenever possible to conserve energy, so users can reinvest the cost

savings back into their business.

Features

Versatile Connectivity

• 8 (DES-1018P) or 16 (DES-1018MP)

10/100 Mbps PoE ports

• Two Gigabit combo uplink ports

Reliability

• 2 kV surge protection for PoE ports

• IEEE 802.3x ow control

Easy Setup

• Plug-and-play installation

• Auto MDI/MDIX crossover for all ports

Green Features

• IEEE 802.3az Energy Ecient Ethernet

• Smart fan (DES-1018MP only)

• RoHS compliant

Power Your Devices

Supports IEEE 802.3af Power-over-Ethernet (PoE) to

power your PoE-capable network devices via Ethernet

cables without the need for power adapters

Reliability PoE Connections

Enhanced surge protection on all PoE ports protects

the switch when feeding power to outdoor PoE-

capable devices

Flexible Connectivity

All downlink ports support 10/100 Mbps speeds, and

two Gigabit uplink ports provide a redundant, wired

speed connection for reliable networking

Product Highlights

DES-1018P/DES-1018MP

18-Port Unmanaged Desktop PoE Switch

Hassle-Free Setup

The DES-1018P/DES-1018MP is a Plug-and-Play device that requires no

conguration, so setup is simple and hassle-free. Simply connect the switch to

a network and then connect multiple computers, share les, and make Voice-

over-IP calls across the network. Support for Auto MDI/MDIX on all ports

eliminates the need for crossover cables when connecting to another switch

or hub. Auto-Negotiation on each port senses the link speed of a network

device (either 10 or 100) and intelligently adjusts for compatibility and

optimal performance. Combining the convenience of PoE, fast performance,

reliability, and ease of use, the 18-Port Unmanaged Desktop PoE Switch is the

ideal choice for adding PoE devices to a network.

Sample Conguration

Internet

Modem

Router

Desktop

Laptop

NAS

Outdoor AP

(PoE)

Outdoor

IP Camera

(PoE)

DES-1018P or

DES1018MP

NVR

Gigabit

Connection

Outdoor

IP Camera

(PoE)

Produkt Specifikationer

Mærke:	D-Link
Kategori:	Ikke kategoriseret
Model:	DES-1018MP
Vekselstrømsindgangsspænding:	100 - 240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	280 mm
Dybde:	210 mm
Højde:	44 mm
Vægt:	2150 g
Produktfarve:	Sort
Pakkevægt:	3189.5 g
Pakkedybde:	358 mm
Pakkebredde:	329 mm
Pakkehøjde:	102 mm
Opbevaringstemperatur (T-T):	-40 - 70 °C
Relativ luftfugtighed ved drift (H-H):	0 - 95 %
Relativ luftfugtighed ved opbevaring (H-H):	0 - 95 %
Strømforbrug (typisk):	301.6 W
Driftstemperatur (T-T):	0 - 40 °C
Certificering:	FCC Class A, CE, CCC, RoHS, VCCI, BSMI, C-Tick
Pallens bruttobredde:	1200 mm
Pallens bruttolængde:	1100 mm
Netværksstandarder:	IEEE 802.3, IEEE 802.3af, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
LED-indikatorer:	Activity, Link, Power, Power fail
Forsendelseskassens bruttovægt (indvendig):	10515.5 g
Strøm over Ethernet (PoE):	Ja
Produkter pr. forsendelseskasse (indvendig):	3 stk
Forsendelseskasses kassens bredde (indvendig):	328 mm
Forsendelseskassens længde (indvendig):	374 mm
Forsendelseskassens højde (indvendig):	356 mm
Forsendelsesemballage nettovægt:	9568.5 g
Switch-type:	Ikke administreret
Basis omskiftning RJ-45 Ethernet porte, antal:	16
Basis omskiftning RJ-45 Ethernet porttype:	Fast Ethernet (10/100)
MAC adresselabel:	8000 entries
Switch kapacitet:	- Gbit/sek.
Stativ-montering:	Ja
Antal blæsere:	1 blæser(e)
Varmeafgivelse:	1029.5 BUT/t
Antal SFP modulslots:	2
Bufferstørrelse:	384 KB
Sikkerhed:	CB, cUL, LVD, CCC, BSMI
Palle bruttovægt (luft):	498197.5 g
Antal papkasser pr. palle (luft):	45 stk
Antal pr. palle (luft):	135 stk
Pallehøjde (luft):	1915 mm
Palle bruttovægt (hav):	498197.5 g
Antal papkasser pr. palle (hav):	45 stk
Antal pr. palle (hav):	135 stk
Pallehøjde (hav):	1915 mm
