Side 1/7

Refer to the numbered drawings that relate to the numbered paragraphs

in the instruction manual

TR2S GB 09 2014

1.1

2.1

Contents

Introduction 1

Installation 1

Use and safety 3

Cleaning, hygiene and storage 5

Fault-ﬁnding 5

Maintenance 6

Compliance with regulations 7

Parts list - exploded view A

Electrical diagrams C

Introduction

1.1 DESCRIPTION

This multi-purpose vegetable slicer is used for slicing, ﬁne slicing,

stripping, grating, cutting into chips and cubes various food

products (preparation of crudités, vegetables, fruits, cheeses,

etc.).

With its varied cutting equipment which provides high hourly

outputs, this is the professional vegetable slicer for restaurants,

community kitchens and small industries.

A Pusher

B Ram

C Hopper

D Casing

E Base

F Stand

G Body

H Control panel

I Locking pin

Installation

2.1 DIMENSIONS - WEIGHT (INDICATION ONLY)

• Packaging dimensions in mm:

L: 580 W: 300 H: 600

• Appliance dimensions:

• Appliance weight:

09/2021

Introduction

The User Manual contains useful information for the user on

how to work correctly and in complete safety, and is designed

to make it easier to use the machine (called “machine” or “ap-

pliance” below).

What follows is in no case intended to be a long list of warnings

and constraints, but rather as a series of instructions meant to

improve the service provided by the machine in every respect,

and particularly to avoid a series of injuries or damage to equi-

pment that might result from inappropriate procedures for use

and management.

It is essential that all the people responsible for transporting,

installing, commissioning, using, maintaining, repairing or dismant-

ling the machine should consult this manual and read it carefully

before proceeding with the various operations, in order to avoid

any incorrect or inappropriate handling that might be result in

damage to the machine or put people’s safety at risk.

It is just as important that the Manual should always be available

to the operator and it should be kept carefully where the machine

is used ready for easy and immediate consultation in case of any

doubt, or in any case, whenever the need arises.

If after reading the Manual, there are still any doubts concerning

how to use the machine, please do not hesitate to contact the

Manufacturer or approved After Sales Service provider, who

is constantly available to ensure quick and careful service for

improved machine operation and optimum efﬁciency.

Note that the safety, hygiene and environmental protection stan-

dards currently applicable in the country where the machine is

installed must always be applied during all phases of machine

operation. Consequently it is the user’s responsibility to ensure

that the machine is operated and used solely under the optimum

safety conditions laid down for people, animals and property.

ATTENTION!!

Machine storage: -25°C to +50°C

Ambient temperature during operation: +4°C to +40°C

This machine is for professional use and must be used by staff trained to use, clean and maintain it, in terms or reliability and

safety.

Use the machine in adequately lit premises (See applicable technical standard for the country of use. In Europe, refer to standard

EN 12464-1)

When handling the machine, always check that the parts taken hold of are not mobile elements: risk of dropping and injury to the

lower limbs.

The machine is not designed for use in explosive atmospheres.

2.2

2.2 POSITION AND ORGANISATION

• On a table of a maximum height of between 700 and 900 mm,

the vegetable slicer takes a standard tub of a max. height of

200 mm.

• On a functional moveable base (supplied as an option).

• With tubs of large dimensions, place the vegetable slicer on

the table edge or use the moveable base.

The reference language for these instructions is French.

- Change the integral plate wire by moving the cable connection

terminal marked as upper voltage (400V) onto that marked as

lower voltage (230V).

- Change the motor wire connections (see electrical diagram).

- Reﬁt the casing, then check the direction of rotation.

2) Single phase motor.

A standardised 2-pole + Earth wall socket rated at 10/16A will

be required.

• Warning to the installer:

This electronic variable-speed vegetable slicer is ﬁtted with an

integral ﬁlter without going via the variator. To be effective, the

system’s earth must be of good quality, otherwise interference

may pass via the variator and damage it.

• No earth connection = no protection = risk of failure +

DANGER for the user!

Note: The earth values are deﬁned according to the residual

differential current and must be checked by an electrician.

To PAT test the Electrolux Range of Food Preparation Equipment,

the PCB board needs to be disconnected before any test is done.

This is due to the fact that the boards are ﬁtted with a grounding

diode that can give incorrect result during such a test. Also on

a standard appliance a ﬂash test of 25 amps and up to 3000v is

used but, as you would expect, to use this on equipment, which

has a printed circuit, board would be quite destructive to that

board. We would recommend the use of a PAT tester approved

for computer systems which use a lower rate of amps.

The appliance is perfectly safe and is CE certiﬁcated. There are

two ways to get overcome this problem.

· Disconnect the board as instructed and test using test for PC’s,

· Or install the mixer on a fused spur (no plug) as this takes it

away from being a portable appliance and the PAT test is then

not needed.

• Check that the electric mains voltage and the value shown on

the speciﬁcation plate.

• The machine must be protected by a residual current device

(RCD) and a fuse of a rating shown in column F of the speciﬁ-

cations.

• Motor speciﬁcations:

A Number of phases (1 single phase or 3 three-phase)

B Nominal voltage in volts (value, range or commutation)

C Frequency (Hertz)

D Nominal rating (Watts)

E Nominal current (Amperes)

F Rating of the fuse protecting the electric line

(Amperes)

1) Dual-voltage three-phase motor.

• A standardised 3-phase + Earth wall socket rated at 20A will

be required and a relevant sealed plug to be ﬁtted onto the power

lead.

• Check the direction of rotation with the ejector ﬁtted in the

machine.

- Remove the pusher after unlocking it (anti-clockwise direction

- Press the "On" button.

- Make a visual check on the ejector's rotation via the pusher

tube. The ejector should turn in an anti-clockwise direction

• I f the direction of rotation is reversed, change over the 2 phase

wires on the power socket.

• Connection is made at the upper voltage (e.g. 400V).

To connect at a lower voltage, (e.g. 230V), proceed as

follows:

- Disconnect the appliance and turn it over.

- Remove the 4 case retaining screws.

2.3

Must be earthed with a green/yellow wire.

2.3 ELECTRICAL CONNECTION

ATTENTION!!

Connection to the electrical power supply must be done according to proper professional practice by a qualiﬁed and authorised

person (see current standards and legislation in the country of installation).

If an adapter is used on the socket, a check must be made that the electrical characteristics of this adapter are not lower than

those of the machine.

Do not use multiple plugs

The AC power supply to the machine must comply with the following conditions;

- Maximum voltage variation: ±5%

- Maximum frequency variation: ±1% on a continuous basis, ± 2% over short periods

ATTENTION: the electrical installation must comply (for design, creation and maintenance) with the legal and standard

requirements in the country where used.

- Check that the electric mains voltage, the value shown on the speciﬁcation plate.

- The machine’s electrical power supply must be protected against voltage surges (short-circuits and excess voltages) by using

fuses or thermal relays of the appropriate gauge relative to the place of installation and machine speciﬁcations.

ATTENTION: Concerning protection against indirect contact (depending on the type of power supply provided and

connection of the exposed conductive parts to the equipotential protection circuit), refer to point 6.3.3 of EN 60204-1 (IEC

60204-1) with the use of protection devices for automatic shut-off of power in the event of an insulation fault with a TN or

TT, system, or for the IT system, with the use of a permanent insulation or differentials controller for automatic shut-off.

The requirements of IEC 60364-4-41, 413.1 must apply for this protection.

For example: in a TT system, a differential circuit breaker must be installed upline of the power supply, with a suitable

power cut-off (e.g.: 30 mA) on the earthing installation for the place where it is planned to install the machine.

ATTENTION: Failure to comply with these instructions means the customer runs the risk of machine failure and/or acci-

dents due to direct or indirect contacts.

TR2S GB 09 2021

Damage caused by a lack of earth will not be covered by

the warranty

Must be earthed by green/yellow wire.

In certain cases, depending on the sensitivity of the

protective RCD, SI-type (Super Immunity) devices may

need to be ﬁtted to prevent unwanted tripping.
