Side 1/2

INSTALLATION

RCI 171HD

MAGNETIC LOCK FOR HAZARDOUS LOCATIONS

www.dormakaba.us • Phone: 1.800.265.6630 • Fax: 1.800.482.9795 • E-mail: sales_RCI@dormakaba.comIS171HD

PCN18041

R10-18GR

See Figure 1 elevation profiles to determine mounting application

requirements for each individual application.

Note: A 2-1/2” (64mm) reveal is required to assure rigid mounting of

the RCI 171HD magnetic lock assembly.

1. Mark door according to armature template and dimensions on

reverse side.

2. Drill and prep holes in door per armature template on reverse

side.

3. Gently tap (2) 3/16” (5mm) diameter spring pins into rear side of

armature(s).

4. Insert one (1) spring washer over 5/16”-18 special shoulder

screw, insert the screw through the armature.

Add three(3) conical spring washers and one (1) flat washer over

the shoulder screw.

Carefully apply thread locking compound to exposed thread.

See Figure 2 details for each type of installation.

All parts must be assembled properly before installing the

armature to the door.

Install complete armature assembly on the door per Figure 2

detail.

5. Tighten shoulder screw securely with allen wrench.

(Do not overtighten.)

Note: All armatures are normally equipped with a permanent magnet on

one end. Be certain to install armature so magnet lines up with magnet

switch inside housing of magnetic lock assembly. See Figure 3.

6. Mark frame per magnetic lock template and dimensions on

reverse side.

7. Remove housing cover of Magnetic Lock Assembly.

8. Drill and prep frame per “D” of Magnetic Lock template.

Attach Magnetic Lock Assembly to the frame using either (2) #14

sheet metal screws or (2) 1/4”-20 machine screws and external

tooth lock washers.

Tighten only enough to hold the unit in place.

(If filler plate is used, assure thet the screws go through both the

filler plate and the door frame.)

9. Drill 7/8” (22mm) diameter hole through filler plate and frame

per template for wire harness.

10. Make all electrical connections per Electrical Specifications box

on page 2. Use wire nuts, crimp connectors or solder to assure

good connections.

11. Energize Magnetic Lock Assembly; Adjust assembly so door is

snug against door stop, tighten (2) preliminary screws securely.

12. De-energize system.

Using mounting plate as a template, drill #21 drill and tap for

10-32 screws (minimum (2) places).

Carefully apply thread locking compound to exposed threads.

See Magnetic Lock template.

Install screws and tighten securley.

Re-energize system, recheck alignment of Magnetic Lock

Assembly to Armature by opening and closing door(s).

13. Install Magnetic Lock housing cover.

Pre-Installation Instructions

IMPORTANT! Read thoroughly before attempting installation.

Do not damage or mark magnetic lock or armature face - may

reduce holding efﬁciency.

This product is intended to be used in Class I Division 2 hazardous

locations. The following guidelines must be observed to reduce the

risk of fire explosion.

All national and local codes must be followed in the installation of the

magnetic lock assembly. For code interpretation, consult a local code

authority

This unit must be connected to an NEC (National Electric code, NFPA

70) Class 2 Supply. Operating temperature for the magnetic lock will

not exceed 185 F (85° C). Maximum ambient temperture is not to °

exceed 104° F (40° C).

For supply connections, use a suitable wire with a mimimum insulation

temperature rating of 167° F (75° C)

To reduce the risk of the ignition of hazardous atmosphere, disconnect

the magnetic lock assembly from the supply circuit before opening

the magnetic lock housing. Keep the unit properly sealed while in

operation. To reduce the risk of fire or explosion, do not install the unit

where the operating temperature exceeds the ignition temperature of

the hazardous atmosphere.

This unit is intended to be used in the following atmospheres;

Acetone, Ammonium Hydroxide, ATSM fuel C, Benzene, Methyl-

Ethylketone, Diethyl-Ether, 2-Nitropropane, Ethyl-Acetate, Furfural,

Normal Hexane, Methyl Alcohol

The product should be installed in a location that will not hinder or

create a potential safety hazard to authorized personnel accessing the

protected area.

Because electromagnetic locks are used in a variety of applications

and different door frame configurations, an experienced installer with

knowledge of this product must make a determination of the optimal

mounting method for this specific application.

Do not install this product on the exterior of buildings.

Do not use as a doorstop. This will void warranty.

NOTE: It is highly recommended that thread locking compound

be applied to all screws during installation to reduce chance of

screws loosening over extended time.

PLEASE DELIVER ALL INSTALLATION INSTRUCTIONS TO

THE END-USER UPON COMPLETION OF THE INSTALLATION.

Use with Underwriters Laboritories Listed (ULC/UL) compatible power supply

Inspection and Maintenance

This product and all related accessories or parts must be inspected and maintained on a . Contacting surfaces of the quarterly basis

electromagnetic lock and armature plate must be kept free of contaminating materials. Surfaces must be cleaned periodically with a

non-abrasive cleaner.

All mounting fasteners must be inspected on a . When properly installed, the ends of the armature plate allow a slight quarterly basis

movement but the plate will feel secure when grasped at the bolt. There should be no movement to the mounting bracket or housing of

the electromagnetic lock.

For added safety, thread locking compound has been provided for the armature plate bolt and the electromagnetic lock mounting

screws.

MAGNETIC LOCK LOCATION

ARMATURE LOCATION

A B

NOTE: SPRING PINS SHOULD FLOAT FREELY INSIDE OF HOLES.

.250 (6 mm) DIA.

3/4" (19 mm) DEEP

(2) PLACES

1-3/8" REF. (35 mm)

1-13/16"

REF. (46 mm)

1-1/4" (32 mm)

3" (77 mm)

7" (179 mm)

3" (77 mm)

7" (179 mm)

5-13/16" (148 mm)

6-11/32" (161 mm)

BOTTOM EDGE OF STOP

FACE OF DOOR

LATCH EDGE OF DOOR LATCH EDGE OF DOOR

BOTTOM EDGE OF STOP

FACE OF DOOR

F F FF

D. Drill for No. 14 sheet metal screws or drill and tap

for 1/4"-20 machine screws.

E. 1/2-14 NPT, Drill 7/8" (22 mm) DIA. hole thru ller

(if used) and frame in either of locations marked

(E) for rigit conduit containing wiring harness.

Use ller plug in location not used.

F. Using actual Magnetic Lock as template, drill

and tap per STEP 12 of installation instructions.

A. For THRU BOLT mounting in hollow metal

door(s) drill 11/32" (9 mm) DIA. hole thru door,

enlarge hole in outside face to 1/2" (13 mm) DIA.

B. For THRU BOLT mounting in solid core wood

door(s), drill 11/32" (9 mm) DIA. hole thru door(s),

enlarge hole in outside face to 1/2" (13 mm) DIA.

1" (25 mm) deep.

C. For REINFORCED DOOR (Minimum 3/8" (10 mm)

thickness) drill and tap thru reinforcement for

5/16-18 screw.

2AA

SHOULDER SCREW

SEX NUT ARMATURE

SPRING WASHERS

FLAT WASHER

NOTE: FOR MACHINE SCREW MOUNTING; REINFORCEMENT AND STRUCTURING ARE REQUIRED TO WITHSTAND A 1200 LB (544 KG) LOAD.

CLEARANCE HOLES FOR FILLER PLATE TO BE SPOTTED AT JOB SITE. CAUTION: "DO NOT ATTACH MOUNTING PLATE TO FILLER PLATE ONLY!"

ELECTRICAL SPECIFICATIONS:

CURRENT DRAW: 0.50 AMPS @ 12 VDC

0.26 AMPS @ 24 VDC

WIRE COLOR CODE: ORANGE/ORANGE (12VDC)

(NON-POLARIZED) RED/RED (24VDC)

HOLDING FORCE: 1200 LB (544 KG)

*NOTE: NOT TO SCALE

ARMATURE MOUNTING TO DOOR(S) FIGURE 2

FIGURE 2C REINFORCED DOOR

FIGURE 2A HOLLOW METAL DOOR

MAGNETIC LOCK MOUNTING TO FRAME FIGURE 1

FIGURE 1A STANDARD INSTALLATION

FIGURE 1B

with an FP-178 FILLER PLATE ACCESSORY

FIGURE 1C

with an AB-179 ANGLE BRACKET ACCESSORY

WIRING FOR D.P.S (DOOR POSITION SWITCH).

DRAWING SHOWS DOOR

IN OPEN POSITION

D.P.S.

MAGNETIC

LOCK

HOUSING

MAGNET

ARMATURE

WHITE (N.O.)

BLACK

(COMMON)

RED (N.C.)

D.P.S. CONTACT RATING

0.1 AMP @ 30 VDC MAX.

FIGURE 3

FIGURE 2B WOOD DOOR

7/8"

(22 mm)

1-3/4" REF.

(45 mm)

1-1/4" (32 mm) 2-1/4"

(57 mm)

REINFORCMENT BY OTHERS

(3/8" (10 MM) MIN.) TYPICAL

FILLER

PLATE C

ANGLE BRACKET RQ'D.

NOTE: units are voltage specic
