IMPORTANT

This product operates on a new frequency of 433 MHz and is not inter-

changeable with previous 418 MHz units which can be easily identiﬁed:

433 MHz = Drayton brand

418 MHz = brand

CONFORMS TO THE ESSENTIAL REQUIREMENTS

OF THE FOLLOWING DIRECTIVES:

89/336/EEC Electromagnetic compatibility

BATTERY REPLACEMENT

30 days before the batteries need replacing, a battery

symbol will ﬂash in the right hand side of the display

(Dia. C).This signiﬁes that four 1.5V type AA alkaline

batteries will be needed to replace the existing ones.

If battery replacement is carried out in this condition

the programmed settings will only be held in the

memory for a maximum of one minute, after which

re-programming may be necessary.

IMPORTANT

To avoid the possibility of having to reprogramme the switching times and

temperatures, it is advisable to wait until the display with a ﬂashing battery

symbol changes to a continuous battery only display (after 30 days – Dia. D).

In this condition the unit will remain OFF but your programmed settings will

be held in the memory for a number of weeks.The two battery compar tments

can now be left open, to replace the batteries, for approximately one hour. If

the compartments are left open for longer, the unit will revert to the factory

preset times and temperatures. It may be necessary to reset the correct time

of day after changing the batteries.

The battery compar tments are situated at the bottom of the unit (press to

unlatch and slide down). Ensure new batteries are installed correctly. Close the

right hand compartment ﬁrst followed by the left.

HELPFUL HINTS

1. First/last set times

The Day 1 setting cannot be programmed before 12.00.The night setting

can be programmed at whatever time you require, even after 12.00

(midnight) so long as it is not programmed more than 23 hours 50 minutes

after the Day 1 setting.

2. Part or full day omission

If during programming the Digistat, one of the symbols on the left hand side of

the screen starts to ﬂash, this indicates that two or more of the switching times

have been set to the same time.This facility enables you to omit one or more

of the switched periods. When one or more switching times are programmed

together the later setting takes precedent. For example, if all four switching

times were set together the Digistat would control continuously at the fourth

(night) temperature setting .

3. Programme sequence

The Digistat will not allow you to program the switched periods out of

sequence but will hold the times together as stated above.

4. Reset

If at any time during the programming you get confused and would like to start

the procedure from the beginning press the SELECT and – buttons at the

same time and hold for two seconds. This resets the Digistat to the factory

preset times and temperatures shown in the table (overleaf).

5. Self revert

If during programming no button is pressed for between one and two minutes

the Digistat will revert automatically to its normal operating mode.

Diagram D

Diagram C

Invensys Climate Controls Limited

Cordwallis Street, Maidenhead, Berkshire SL6 7BQ

Telephone: (01628) 672121 Sales Facsimile: (01628) 675062

Technical Helpline: (01895) 460444

An Invensys Product 090 798

Invensys Climate Controls reserve the right to make changes without notice and cannot accept liability for errors. 0200

Digistat RF3i ‘Wireless System’

User instructions

SCR RECEIVER

INITIAL START UP

IMPORTANT: ENSURE THAT THE COMMISSIONING PROCEDURE HAS

BEEN CARRIED OUT IN ACCORDANCE WITH THE ENCLOSED

INSTRUCTIONS.

SCR (RECEIVER) NORMAL OPERATING MODE

Once the ‘Wireless System’ has been commissioned, there should be little need

for any user interface with the SCR.

During normal operation the red and green LEDs will occasionally be on,

these signify the following:

Green LED

The green LED will be on when there is a demand for heating, and off when there

is no demand.

Red LED

The red LED will ﬂash for 7 seconds, approximately every 5 minutes.This denotes

that a radio signal is being received from the Digistat RF unit.

SITUATIONS REQUIRING ATTENTION

Red LED continually ﬂashing

This denotes that the batteries in the Digistat RF unit are approaching the end of

their life (see ‘battery replacement’).

Red LED continually on

This denotes that the SCR has been unable to receive a radio signal from the

Digistat RF unit. This may be caused by the batteries being dead (see ‘battery

replacement’) or some temporary interference with the radio signal.

To re-send and test the signal, go to the Digistat RF unit. If the ﬂame symbol

is visible on the display, press the ‘–’ button until it disappears. If the ﬂame symbol

is not visible, press the ‘+’ button until it appears. If the radio signal has been

successfully transmitted and received, the red LED will ﬂash for 7 seconds then

go off. If the red LED is still on, ‘learn mode’ may have been selected by accident

(SCR buttons 1 and 2 pressed simultaneously).To correct, open both RF battery

drawers and wait for the display to fade, close the right hand drawer followed by

the left and reprogramme RF with your desired time and temperature settings.

If the red LED is still on, there may be some other fault that will require the

attention of a heating engineer/electrician.

MANUAL OVERRIDE

The heating can be manually switched on and off by using the ‘OVERRIDE’ button

on the SCR in a fault situation, even though the red LED will stay on until a

satisfactory signal is reinstated.

Once the SCR receives a satisfactory signal again, it will automatically reset

itself for normal operation.

Drayton

8. Press the Yes (–) button again.This tells you that at

6.30, the heating system will control your home at

20°C. If you wish to alter the temperature use the +

and – buttons.

9. Press the “SET?” button.The time will now ﬂash. If

you wish to alter the switching time use the + and –

buttons.This will change the switching time in 10

minute steps.

10. Press the “SET?” button, this tells you that at 8.30,

the heating system will control your home at 16°C. If

you wish to alter this temperature use the + and –

buttons.

11. Continue to press the “SET?” button as in steps 9 and

10 above to advance through the times and

temperatures for Mon. to Fri. (1 – 5). If you wish to alter

any of the times and temperatures use the + and –

button, when the one you wish to alter is ﬂashing.

12. Once Mon. to Fri. have been set, the display will show

as here.This means do you want to set the times for

Monday (1) differently from the rest of the week? If you

do, press the Yes (–) Button, and follow the routine as

steps 9 to 11.

13. Continue to press the “SET?” button to advance

through the week (1 – 5).When this display shows,

press the Yes (–) button if you wish to view or alter

the times for Sat.-Sun. (6-7). Repeat steps 9-12 as

required.

14. Continue to press “SET?” button until you return to

normal operating mode with a display similar to the

one shown here.

OPERATING MODES

The Digistat can be operated in one of three modes.

1) – Timed, all preset times and temperatures

2) – Continuous night temperature (useful for low limit temperature

protection when on holiday)

3) – Continuous ‘DAY 1’ temperature

Use the SELECT button to change the operating mode to suit your

requirements, the symbols are positioned on the right hand side of the display.

TEMPERATURE OVERRIDE

If at anytime during normal operation, you wish to temporarily increase or

decrease the set temperature use the + or – buttons to change to your

desired setting. This can be done without entering the SET mode. 5 seconds

after releasing the + or – button the display will revert to showing the actual

room temperature. The Digistat will now control the temperature to the

override setting until the next programmed switching time, when it will revert

to the times and temperatures you have already programmed.

The Digistat RF3i features unique self learning optimum start software. They can

help achieve savings in excess of 10% on heating costs and reduce CO

2emissions,

by delaying the start time on milder days without affecting your comfort level.

USER INSTRUCTIONS FOR OPTIMUM START

There is no extra programming involved. The self learning software is factory

preset and will start to monitor and adjust the heating start times for setting ,

as soon as the unit is installed.

The optimum start feature only operates on the ﬁrst switching time of each

day ( ). Switching times , and switch at the programmed times

without any delay.

The delay period can vary between 0 - 60 minutes depending on:

a) The actual room temperature at the ﬁrst switching time ( ).

b) The set temperature of the Digistat RF3i.

c) The stored data on how fast the heating system responded the previous day.

During normal operation the ﬂame symbol on the display indicates the

current operating status.

Flame on = heating on

No ﬂame = heating off

FIashing ﬂame = saving energy (optimum start cycle operating)

When the ﬂame is ﬂashing, the optimum start cycle can be overriden by pressing

the + button once.This returns the unit to normal operation.

IMPORTANT

Always set your heating to the time that you would normally wish it to start

allowing for the coldest weather conditions. Optimum start will automatically

delay the start time and save you money on milder days.

DIGISTAT RF3i

Once the ‘wireless system’ has been commissioned,

the unit will display the actual room temperature

and the time at somewhere after 12.00 midnight

(Diagram A).

Note: If this unit has replaced a standard room

thermo-stat and/or a programmer is incorporated in

the control system, it is suggested that the central

heating (CH) channel is switched to On/Cont/24hrs.

Operation of the heating times and tempera-tures

will be controlled by this unit.

Diagram A Diagram B

Digistat RF3i has an indicator to show when the heating system is ON or OFF,

e.g. if the SET temperature is 20°C and the actual room temperature is below

20°C a ﬂame symbol will appear on the display (Diagram B). This indicates a

demand for heat (system will switch ON).

During normal operation, the Digistat RF3i will display actual room

temperature continuously.

SETTING THE TIME OF DAY (STEPS 1-5)

THE DIAGRAM NEXT TO EACH STEP DESCRIPTION SHOWS RESULTING DISPLAY.

1. Press “SET?” button

2. Press “Yes” (–) button.The hours will ﬂash as Fig. 2.

Use the + and – buttons to set correct hour.

3. Press “SET?” button again and the minutes will ﬂash,

use + and – buttons to set correct minute time.

4. Press “SET?” button, day of the week will ﬂash,

1 = Monday, 7 = Sunday, use + and – buttons to set

correct day.

5. Press “SET?” button twice to return to normal operating

mode.

PRE-PROGRAMMED TIMES AND

TEMPERATURES

The Digistat RF3i comes with the following preset programme.

Symbol Mon-Fri Sat-Sun Temperature

Time Time

6.30 7.00 20°C

8.30 9.00 16°C

4.30 pm 4.00 pm 21°C

10.30 pm 11.00 pm 7°C*

* 16°C if selector pin removed, see installation instructions.

TO VIEW OR CHANGE THE FACTORY SETTINGS (steps 6-14)

6. Press the “SET?” button until this display is shown.

7. Press the Yes (–) button.You have selected the Monday

to Friday part of the programme.

Continued overleaf

Produkt Specifikationer

Mærke:	Drayton
Kategori:	Termostat
Model:	Digistat RF 3i

Har du brug for hjælp?

Hvis du har brug for hjælp til Drayton Digistat RF 3i stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Termostat Drayton Manualer

Drayton MiStat C - C110C Manual

13 Januar 2025

Drayton MiTime T710R Manual

13 Januar 2025

Drayton MiTime T720R Manual

13 Januar 2025

Drayton RTS10 Manual

5 Oktober 2024

Drayton RTS2 Manual

16 September 2024

Drayton Digistat RF902 Manual

5 September 2024

Drayton Digistat RF901 Manual

5 September 2024

Drayton PTS1 Manual

5 September 2024

Drayton LP20RF & Digistat+ RF Manual

5 September 2024

Drayton Easy 2 Manual

5 September 2024

Termostat Manualer

Nyeste Termostat Manualer

Tesla TSL-TRV-GS361A Manual

31 Juli 2025

30 Juli 2025

29 Juli 2025

29 Juli 2025

25 Juli 2025

24 Juli 2025

Vimar 21814.F.70 Manual

24 Juli 2025

GENERAL Life HT390S Manual

24 Juli 2025

GENERAL Life HT440S Manual

24 Juli 2025

Vimar 01910.14 Manual

24 Juli 2025
