User’s Guide

earthworksaudio.com

July 11, 2018

Product Registration

To help you get the most out of your

Earthworks purchase, please take a moment

and register your product with us online at

earthworksaudio.com/register.

Service & Repair

If you have any problems with your

Earthworks products, please contact our

Service & Repair Department.

Email: returns@earthworksaudio.com

Telephone: (603) 654-2433, ext. 119

MADE IN USA

Printed in USA

Frequency Response of TC20 (typical)

Description

The Earthworks TC20 is an omnidirectional (pressure)

pre-polarized condenser microphone directly coupled to

a dedicated wideband, low output impedance pream-

plier. The TC20 requires a standard 24-48V phantom

power supply. It features a linear free-eld frequency re-

sponse from 9Hz to 20kHz, fast impulse response, very

low handling noise, uniform polar pattern, and very high

SPL handling capabilities. It exhibits no proximity effect.

Applications

The Earthworks TC20 is easy to operate. Connect the

microphone to a microphone preamplier supplying

48V phantom power using a standard XLR microphone

cable. Please allow up to one minute for the microphone

to settle. Plugging in the microphone “hot” (phantom

power already present at the input) will not damage the

microphone, and is actually preferred for faster settling.

It is normal for any phantom powered mic to “pop” when

plugged in or powered up. Make sure to mute the signal

to speakers or headphones when phantom power is rst

applied.

The TC20 is our least expensive general-purpose omni. It

is a good choice for close-miking louder sources such as

instrument amps, drums, or close-miked brass. It is also

very popular for drum overheads. A pair of TC20s con-

nected to a stereo recorder will provide excellent results

for recording rehearsals and performances. The TC20 is

great for general studio use and is an exceptional value.

It has no handling noise, no proximity effect, and is very

forgiving in terms of placement.

A mounting clip is included with the microphone. This

microphone has no removable parts.

Care of Microphone

The Earthworks TC20 microphone is a precision instru-

ment designed and built to provide years of excellent

performance. Following these simple rules will help to

protect your investment in the TC20:

Avoid touching the front protective screen.

Never attempt to disassemble the microphone –

it cannot be opened.

Avoid extreme heat and condensing humidity. Allow the

microphone to warm up in the case when bringing it in

from the cold weather.

Rough handling may damage the microphone even if no

visible marks are left.

When not in use keep the TC20 in its case.

•

XLR Output Connector Assignment of TC20

Specications

Frequency response: 10Hz to 20kHz +1/-3dB

Polar Pattern: Omnidirectional

Sensitivity: 8mV/Pa (Typical)

Power Requirements: 24-48V Phantom, 10mA

Peak Acoustic Input: 150dB SPL

Output: XLR-3

Output Impedance: 65Ω, balanced between pins 2 & 3

Minimum Load: 600Ω btw. pins 2 & 3

Noise: 26dB, A equivalent

Dimensions L x D: 165 x 22 mm (6.5 x .860 in.)

Weight: 160g (.3lb)

Impulse Response of TC20 (typical)

Polar Response of TC20 (typical)

Specications are subject to change without notice.
