Eastron SDM120-MB User Manual

Zhejiang Eastron Electronic Co.,Ltd. Web: www.eastrongroup.com

SDM120-MB

Single-Phase Multi-function DIN Rail Meter

 Measures kWh, kVArh, kW, kVAr, KVA, PF, Hz, dmd, V, A, etc.

 Bi-directional measurement IMP & EXP

 Two pulse outputs

 M-bus conmmunication

 Din rail 18mm

 45A direct connection

 Class C(Class 0.5) / Class B(Class 1)

 EN50470-3:2022

User Manual V1.0

Eastron SDM120-MB User Manual

Zhejiang Eastron Electronic Co.,Ltd. Web: www.eastrongroup.com

Risk Reduction

Information for Your Own Safety

This manual does not contain all of the safety measures operating the equipment (module, device) for different

conditions and requirements. However, it does contain information which you must know for your own safety and to

avoid damages. These information are highlighted by a warning triangle indicating the degree of potential danger.

Warning

This means that failure to observe the instruction can result in death, serious injury or considerable

material damage.

Caution

This means hazard of electric shock and failure to take the necessary safety precautions will result in

death, serious injury or considerable material damage.

Qualified personnel

Operation of the equipment (module, device) described in this manual may only be performed by qualified personnel.

Qualified personnel in this manual means person who are authorized to commission, start up, ground and label devices,

systems and circuits according to safety and Regulatory standards.

Proper handling

The prerequisites for perfect, reliable operation of the product are proper transport, proper storage, installation and

proper operation and maintenance. When operating electrical equipment, parts of this equipment automatically carry

dangerous voltages. Improper handling can therefore result in serious injuries or material damage.

 Use only insulating tools.

 Do not connect while circuit is live (hot).

 Do not connect the meter to a 3 phase - 400VAC – network.

 Place the meter only in dry surroundings.

 Do not mount the meter in an explosive area or expose the meter to dust, mildew and insects.

 Make sure the wires are suitable for the maximum current of this meter.

 Make sure the AC wires are connected correctly before activating the current/voltage to the meter.

 Do not touch the meter connecting clamps directly with metal, blank wire and your bare hands as you may get

electrical shock.

 Make sure the protection cover is placed after installation.

 Installation, maintenance and reparation should only be done by qualified personnel.

 Never break the seals and open the front cover as this might influence the function of the meter, and will cause no

warranty.

 Do not drop, or allow strong physical impact on the meter as the high precisely components inside may be

damaged.

 Designed to be mounted inside of switchboards or cabinet on DIN RAIL
