Side 1/10

Operating instructions

W2S130-AA03-01

Translation of the original operating instructions

ebm-papst Mulfingen GmbH & Co. KG

Bachmühle 2

D-74673 Mulfingen

Phone +49 (0) 7938 81-0

Fax +49 (0) 7938 81-110

info1@de.ebmpapst.com

www.ebmpapst.com

CONTENTS

1. SAFETY REGULATIONS AND NOTES

11. SAFETY REGULATIONS AND NOTES

Please read these operating instructions carefully before starting to work

with the device. Observe the following warnings to prevent malfunctions

or physical damage to both property and people.

These operating instructions are to be regarded as part of this device.

If the device is sold or transferred, the operating instructions must

accompany it.

These operating instructions may be duplicated and forwarded for

information about potential dangers and their prevention.

1.1 Levels of hazard warnings

11.1 Levels of hazard warnings

These operating instructions use the following hazard levels to indicate

potentially hazardous situations and important safety regulations:

DANGER

Indicates an imminently hazardous situation which, if not

avoided, will result in death or serious injury. Compliance with

the measures is mandatory.

WARNING

Indicates a potentially hazardous situation which, if not avoided,

could result in death or serious injury. Exercise extreme

caution while working.

CAUTION

Indicates a potentially hazardous situation which, if not avoided,

may result in minor or moderate injury or damage of property.

NOTE

A potentially harmful situation can occur and, if not avoided, can

lead to property damage.

1.2 Staff qualification

11.2 Staff qualification

The device may only be transported, unpacked, installed, operated,

maintained and otherwise used by qualified, trained and authorised

technical staff.

Only authorised specialists are permitted to install the device, to carry

out a test run and to perform work on the electrical installation.

1.3 Basic safety rules

11.3 Basic safety rules

Any safety hazards stemming from the device must be re-evaluated

once it is installed in the end device.

The local industrial safety regulations must always be observed when

working on the device.

Keep the workplace clean and tidy. Untidiness in the working area

increases the risk of injury.

Observe the following when working on the unit:

; Do not make any modifications, additions or conversions to the

device without the approval of ebm-papst.

1.4 Electrical voltage

11.4 Electrical voltage

; Check the electrical equipment of the device at regular intervals, refer

to chapter 5.2 Safety test.

; Replace loose connections and defective cables immediately.

DANGER

Electrical load on the device

Risk of electric shock

→ Stand on a rubber mat if you are working on an electrically

charged device.

21.5 Safety and protective functions

21.6 Mechanical movement

21.7 Emission

21.8 Hot surface

21.9 Transport

21.10 Storage

32. PROPER USE

43. TECHNICAL DATA

43.1 Product drawing

53.2 Nominal data

53.3 Technical features

53.4 Mounting data

53.5 Transport and storage conditions

64. CONNECTION AND START-UP

64.1 Connecting the mechanical system

64.2 Connecting the electrical system

74.3 Connection of the cables

84.4 Connection screen

94.5 Checking the connections

94.6 Switch on device

94.7 Switching off the device

95. MAINTENANCE, MALFUNCTIONS, POSSIBLE

CAUSES AND REMEDIES

105.1 Cleaning

105.2 Safety test

105.3 Disposal

Item no. 10434-5-9970 · ENG · Revision 202174 · Release 2019-01-04 · Page 1 / 10

ebm-papst Mulfingen GmbH & Co. KG · Bachmühle 2 · D-74673 Mulfingen · Phone +49 (0) 7938 81-0 · Fax +49 (0) 7938 81-110 · info1@de.ebmpapst.com · www.ebmpapst.com

Operating instructions

W2S130-AA03-01

Translation of the original operating instructions

WARNING

Terminals and connections have voltage even with a

unit that is shut off

Electric shock

→ Wait five minutes after disconnecting the voltage at all poles

before opening the device.

CAUTION

In the event of failure, there is electric voltage at the

rotor and impeller

The rotor and impeller are base insulated.

→ Do not touch the rotor and impeller once they are installed.

CAUTION

The motor restarts automatically when operating voltage

is applied, e.g. after a power failure.

Danger of injury

→ Keep out of the danger zone of the device.

→ When working on the device, switch off the mains

supply voltage and secure the latter from being switched on

again.

→ Wait until the device stops.

1.5 Safety and protective functions

DANGER

Protective device missing and protective device not

functioning

Without a protective device there is a risk of serious injury, for

instance when reaching into the device during operation.

→ Operate the device only with a fixed protective device and

guard grille.

→ The fixed protective device must be able to withstand the

kinetic energy of a fan blade that becomes detached at

maximum speed. There must not be any gaps which it is

possible to reach into with the fingers, for example.

→ The device is a built-in component. As the operator, you

are responsible for ensuring that the device is secured

adequately.

→ Stop the device immediately if a protective device is

found to be missing or ineffective.

1.6 Mechanical movement

DANGER

Rotating device

Body parts that come into contact with the rotor and impeller

can be injured.

→ Secure the device against accidental contact.

→ Before working on the system/machine, wait until all

parts have come to a standstill.

WARNING

Rotating device

Long hair, dangling items of clothing, jewellery and similar items

can become entangled and be pulled into the device. Risk of

injury.

→ Do not wear any loose-fitting or dangling clothing or jewellery

while working on rotating parts.

→ Protect long hair with a cap.

1.7 Emission

WARNING

Depending on the installation and operating conditions,

a sound pressure level greater than 70 dB(A) may arise.

Danger of noise-induced hearing loss

→ Take appropriate technical safety measures.

→ Protect operating personnel with appropriate safety

equipment, e.g. hearing protection.

→ Also observe the requirements of local agencies.

1.8 Hot surface

CAUTION

High temperature at the motor housing

Danger of burn injuries

→ Ensure that sufficient protection against accidental contact is

provided.

1.9 Transport

NOTE

Transport of device

→ Transport the device in its original packaging only.

→ Secure the device so that it does not slip, e.g. by using a

clamping strap.

1.10 Storage

; Store the device, partially or fully assembled, in the original

packaging in a clean, dry and weatherproof place free of vibrations.

; Protect the device against environmental effects and dirt until final

installation.

; We recommend storing the device for no longer than one year in

order to guarantee trouble-free operation and longest possible service

life.

; Even devices explicitly intended for outdoor use are to be stored as

described prior to commissioning.

; Maintain the storage temperature, see

chapter 3.5 Transport and storage conditions.
