Fitting Instructions
PMM-43-ADPL
4.3” Factory Mount Mirror Monitor
with Auto-Dimming and Adjustable
Parking Lines
Introduction
Box Contents
Key Features
u User Guide
u Mirror Monitor
u Main Harness
u Cable Management
u Allen Key
Thank you for purchasing your EchoMaster Pro automotive monitor.
Your monitor displays a clear, high resolution image of the area
surrounding your vehicle, meaning your maneuvering and vehicle
awareness will be greatly improved.
Please ensure you read and understand all aspects of this manual before
tting or using your EchoMaster monitor.
Operating Instructions
u Dual video inputs
u Reverse trigger input
u Adjustable parking lines
u Remote control included
u Auto-dimming display
u OEM style mirror dimming
The PMM-43-ADPL will replace your factory tted rearview mirror.
Remove the original mirror from the vehicle and replace with the
PMM-43-ADPL.
Once the unit is in place, run the connections cable across the headliner of
the vehicle and down the A pillar.
Please ensure that you do not impede the operation of any airbags that
may be located in the A pillar of the vehicle. Any cable passing these
airbags should be run behind the airbag and not in front of it.
Once the cable has been routed down to the dashboard connect the
camera inputs and power connections as shown in the wiring diagram
section of this manual.
The vehicle ignition is required to be on for the unit to operate.
The unit will only turn on when a video signal is present.
To turn it on or off hold the POWER button for 1 second. The screen will
show the video signal connected to Video 1.
A short press of the POWER button will turn the auto-dimming glass
feature on or off.
