Be sure to read this installation manual thoroughly prior to installation and making connections. If installation
methods or non-standard parts not specified in this installation manual are used, accidents or injury may
result.
Professional techniques and experience are required in order to install this system. It is recommended that
you contact the place of purchase for installation to be carried out. After reading the installation manual
thoroughly, keep them in a safe place for later reference.
To dealers:
Give this installation manual to the customer after installation and all connections have been completed.
REAR CAMERA
INSTALLATION MANUAL
Components
Installation Diagram
For your safety in using the BEC105
Installing the Rear Camera
Camera Angle Adjustment
2
2
Points to note after installing the rear camera 4
6
11
Before
installation
Installation
System Connection Example 12
Connections
Contents
Contents
5
MODEL
2
Waterproof cushion
x 1
7
Harness affixing tape
x 2
6
※Rear camera
x 1
1
Bracket
x 1
2
Screw
(M3x6)x 2
3
Rear Camera Components
Double-sided tape
(Spare) x 1
4
Cable rail
x 6
5
Components
Components
Check that all of the following components are present
Check that all of the following components are present
*The rear camera cable includes a 3-pin intermediate connector (male-female) to improve ease of installation.
Warnings and caution signs, illustrated bellow, are posted throughout this manual as well as on the BEC105.
They show safe and correct ways to handle the product to prevent personal injury to you and others and avoid
damage to property.
Before reading through the manual, take time to read through and learn the important information listed in
this section.
This "WARNING" sign indicates a situation in which incorrect handling may result in
death or serious personal injury.
This "CAUTION" sign indicates a situation in which incorrect handling may result in
personal injury or may result solely in damage to property.
This section contains information that can help to prevent problems and
damage to the unit, and also contain other useful information.
Tip
F
For y
or your saf
our safety in using the BEC105
ety in using the BEC105
