Side 1/145

IGS-5408P

User Manual

01-2019 / v1.0

FCC Warning

This Equipment has been tested and found to comply with the limits for a Class-A digital device,

pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates, uses, and can radiate radio

frequency energy. It may cause harmful interference to radio communications if the equipment is not

installed and used in accordance with the instructions. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures:

I-1 Reorient or relocate the receiving antenna.

II-1 Increase the separation between the equipment and receiver.

III-1 Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

IV-1 Consult the dealer or an experienced radio/TV technician for help.

Produkt Specifikationer

Mærke:	Edimax
Kategori:	bryter
Model:	IGS-5416P
Kode for international beskyttelse (IP):	IP30
Bredde:	145 mm
Dybde:	90.8 mm
Højde:	113 mm
Vægt:	1400 g
Produktfarve:	Sort
Opbevaringstemperatur (T-T):	-40 - 80 °C
Relativ luftfugtighed ved drift (H-H):	10 - 95 %
Relativ luftfugtighed ved opbevaring (H-H):	10 - 90 %
Antal USB 2.0-porte:	1
Driftstemperatur (T-T):	-40 - 75 °C
Sikkerhedsalgoritmer:	SNMP, SNMPv3, SSH-2, SSL/TLS
Husmateriale:	Aluminium
Certificering:	IEC61000-4-2 (ESD), IEC61000-4-3 (RS), IEC61000-4-4 (EFT), IEC61000-4-5 (Surge), IEC61000-4-6 (CS), IEC61000-4-8; RoHS; FCC 15 B A, CE EN 55032 A; IEC60068-2-6; IEC60068-2-27; IEC60068-2-32
Strømforbrug (maks.):	22.08 W
Netværksstandarder:	IEEE 802.3af, IEEE 802.3at
Knap til nulstilling:	Ja
Servicekvalitet support (QoS):	Ja
LED-indikatorer:	Activity, Link, Power
Harmoniseret systemkode (HS):	85176990
DC indgangsspænding:	48 - 57 V
Firmware kan opgraderes:	Ja
Fiber optisk strømstik:	SFP
Fuld duplex:	Ja
Strøm over Ethernet (PoE):	Ja
Gennemsnitstid mellem fejl (MTBF):	100000 t
Switch-type:	Administreret
Total Power over Ethernet (PoE):	240 W
Power over Ethernet plus (PoE+) porte, antal:	8
Power over Ethernet (PoE) effekt pr. port:	30 W
10G understøttelse:	Ingen
Spanning tree protokol:	Ja
VLAN understøttelse:	Ja
Flowkontrol support:	Ja
Port-spejlning:	Ja
Antal VLAN'er:	4096
Link aggregering:	Ja
Kobber ethernet kabelteknologi:	10BASE-T, 100BASE-TX, 1000BASE-T
Broadcast stormkontrol:	Ja
Vituelle LAN funktioner:	Tagged VLAN, Port-based VLAN
Basis omskiftning RJ-45 Ethernet porte, antal:	16
Basis omskiftning RJ-45 Ethernet porttype:	Gigabit Ethernet (10/100/1000)
Port til konsol:	RJ-45
IGMP snooping:	Ja
Adgangskontrolliste (ACL):	Ja
Fiber ethernet kabelteknologi:	1000BASE‑LX, 1000BASE‑SX
Opbevar-og-frem:	Ja
MAC adresselabel:	16000 entries
Switch kapacitet:	40 Gbit/sek.
Jumbo Frames support:	Ja
Jumbo rammer:	16000
Multicast-understøttelse:	Ja
Strømbeskyttelsesfunktioner:	Overload, Reverse polarity
Antal SFP modulslots:	4
Beskyttelse af adgangskode:	Ja
DIN-skinne montering:	Ja
DHCP funktioner:	DHCP server, DHCP client
Pakke bufferlager:	12 MB
Hastighed for videresendelse:	29.76 Mpps
Elektromagnetisk kompatibilitet:	61000-6-2, 61000-6-4
Pakke videresendelsesrate (1 Gbps):	1488000 pps
Pakke videresendelsesrate (100 Mbps):	148800 pps
Pakke videresendelsesrate (10 Mbps):	14880 pps
Algoritmer for køplanlægning:	SP, SPQ, WRR+SP, Weighted Round Robin (WRR)
Relæ udgange:	1
IPv4 & IPv6 funktioner:	Dual stack IPv4/IPv6
Telnet:	Ja
