- Vertically mechanically adjustable air discharge
- Air-intake filter with activated carbon lter (4)
- 3 meter long, pre-assembled cooling line with
- Wall fastening for external unit
- Cooling quantity: 740 g
- Energy-Eciency-Class*: C
- EER / COP*: 2.81 / 2.61
- Energy consumption at cooling*: 623 kWh/year
- Cooling capacity*: 3,500 W
- Heating capacity*: 2,980 W
- Air circulation max.: 680 m³/h
- Exhausted room humidity
max. (30°C/80% RH): approx. 43l/day
- Noise level inside unit: 54dB (A) ≤
- Noise level external unit: 62dB (A) ≤
- Dimensions inside unit approx.: 365x608x746 mm
- Dimensions external unit approx.: 500x310x520 mm
- Weight inside unit (net) approx.: 32 kg
- Weight external unit (net) approx.: 13 kg
- Weight complete with package: 48 kg
- Packaging approx.: 1,150x400x780 mm
*Characteristics of EN 14511
Portable Split Air Conditioner
- Target – temperature attitude: +18°C up to +32°C
- Operating level section (MODE): automatic,
- Power-on time: 1-24h, Continuous operation
- Automatic, cooling, fan, heating
- Condensation water tank full
The portable and compact air conditioner co
ists of two units and provides a comfo
table indoor climate. The
external unit (liquefier unit) and the inside unit (vaporiser unit) are associated with a 3 meter long cooling line. The
external unit is set up in the free or hung up at a outside wall. The mobile inside unit is set up in the area which
should be air-conditioned. The unit is completely assembled and directly ready for use. With the soft keys or with the
remote control all operating levels can be set on the inside unit and also the air conditioner can be switched on/o.
The thermostat regulation provides a well-balanced indoor climate. This model is suitable for rooms of max. 100 m³.
