NANO OPERATION OVERLORD

Multi-Instrumental Overdrive

Congratulations on your purchase of the NANO OPERATION OVERLORD, a

compact full-featured overdrive and distortion pedal. With the NANO

OVERLORD’s broad range of options and controls you can easily dial in great

drive sounds for any instrument. Active 3-band EQ controls, switchable BOOST

mode, and a dry blend provide versatility for different tones. You can create mild

overdrive to thick distortion, crank the volume to use the pedal as a boost with

or without grit, or generate unconventional sounds like intensely filtered clipping,

all with a few straightforward controls.

WARNING: Your Nano Operation Overlord comes equipped with an Electro-Harmonix

9.6DC-200BI power supply. The Nano Overlord requires 50mA at 9VDC with a center

negative plug. Use of the wrong adapter or a plug with the wrong polarity may damage

your Nano Overlord and void the warranty. Do not exceed 10.5VDC on the power plug.

Power supplies rated for less than 50mA will cause the Nano Overlord to act unreliably.

- FEATURES -

 Amp-like JFET overdrive with three gain stages

 Switchable boost mode for saturated distortion tones

 Active 3-band EQ for ultimate control

 Dry blend knob for preserving the instrument’s harmonic content, character,

and full frequency range

 Three-position input level sets the gain range perfectly for any instrument

 High-quality buffered bypass and soft switching

- MODES OF OPERATION: NORMAL VS. BOOST -

The NANO OVERLORD operates in two modes: NORMAL and BOOST. The

NORMAL mode uses three amp-like JFET gain stages for low to medium gain

sounds. The BOOST mode adds a classic pedal-style overdrive circuit before the

JFET stages to increase overall distortion. BOOST is engaged with the BOOST

pushbutton or an external momentary footswitch, and is active when the blue

LED is lit. In BOOST mode, a fixed amount of additional gain from the BOOST

circuit is fed into the main JFET circuit. The GAIN knob still controls the amount

of overdrive in BOOST mode, with more overall distortion on tap.

- CONTROLS -

GAIN Knob – The GAIN knob controls the amount of overdrive/distortion. As

you turn GAIN clockwise, the amount of input gain increases.

DRY Knob – The DRY knob mixes a clean unaltered signal with the distortion

produced by the NANO OVERLORD. At the minimum position of the DRY knob,

the output is 100% overdrive effect, and at the maximum position the output is

100% clean. This function is useful for preserving the harmonic integrity of your

playing, which is especially important for keyboards or bass. For guitarists, this

feature can be useful if you are stacking the NANO OVERLORD with other drive

pedals, or playing it through an overdriven amplifier.

INPUT LVL Switch – This switch controls the initial input level of your

instrument into the NANO OVERLORD. Use it to set an appropriate gain level for

a variety of instruments. Set the switch to HI for low-level instruments, like a

single-coil guitar or vintage electric piano. Set the switch to NORM for

humbucker guitars and most modern keyboard workstations. Use the LO setting

for high-output instruments, like some synthesizers or boosted guitars.

Tip: The GAIN Knob, INPUT LVL switch, and DRY knob all work together. If

the INPUT LVL switch is set properly, turning the DRY knob should not

significantly change the overall volume. However, varied settings of the INPUT

LVL switch could produce some interesting higher- or lower-gain sounds. Feel

free to experiment with this switch – setting it “wrong” might sound great for

you, and won’t damage the circuit!

BASS Knob – Active control of the level of the bass frequency range.

MID Knob – Active control of the level of the middle frequency range.

TREBLE Knob – Active control of the level of the treble frequency range.

VOL Knob – This knob controls the overall volume output of the NANO

OVERLORD. As this knob is turned clockwise, the output level increases.

Footswitch and red LED – This footswitch selects whether the NANO

OVERLORD is engaged or in buffered bypass mode. When the effect is engaged,

the red LED will be lit.

BOOST Button and blue LED – This button toggles Boost mode on and off.

When in Boost mode, the blue LED will be lit.
