EVID FM4.2

Dual 4” Two-Way

Flush-Mounted

Loudspeaker System

Key Features:

• 4”two-waysystemwithpolypropylenediaphragmforreliable

long-termoperation.

• 4”passiveradiatorcoupledtothewooferdramaticallyex-

tendsandsmoothesthelowfrequencyresponse.

• Extremelycompactdepthfitsintotightspacesincluding

wallsandtightceilingspaces.

• Titaniumcoatedtweetergivesevenuniformhighfrequency

coverage

• Fullbandwidthoverloadprotection

• Frontbafflewattagetapadjustmentallowsforeasylevel

matchingafterinstallation.

• Easy4pinphoenixstyleterminalsforquickinstallation.

• Integratedlowlossmatchingtransformerallowsforeither

70v/100vor8ohmoperation.

General Description:

TheElectro-Voice®EVIDFM4.2flush-mountedloudspeakersystemis

acompletetwo-wayin-wallloudspeakerpackage.Thepackagecon-

sistsofabezelassembly,grille,rearenclosure,4”two-wayloudspeaker

coupledwitha4”passiveradiatorandaninternalline-matching

transformer.Theloudspeakerfeatures4”low-frequencyconeand

high-temperaturevoice-coilassemblyalongwitha4”longexcursion

passiveradiatorandtitaniumcoateddometweeter.TheEVIDFM4.2

loudspeakerutilizesacrossovernetwork,centeredat3,600Hz,that

provides16-dB-per-octavetweeterprotectionoutsideofitsoperating

range.InadditiontheEVIDFM4.2featuresacomprehensiveprotection

circuittoshieldthewooferandtweeterdriversfromexcessivepower

levels.

TheEVIDFM4.2utilizesatransformerthatoffersaselectionof1.75,

3.75,7.5,15or30wattsdeliveredtotheloudspeakersystemusing

either70-Vor100-Vlines.Thewattageisselectedviaaconvenient

switchonthefrontbaffle.Theunitcanalsobeoperatedasan8-ohm

speakerviathesamefrontpanelselectorswitch.

Theperforatedgrilleisfinishedinsemi-glosswhitepowder-coated

enamel.ThebaffleandbezelisconstructedfromheatresistantABS.

Therearenclosureisconstructedfromzinc-plated,steel.Therear

enclosureprovidesanoptimuminternalvolume,ensuringextendedlow-

frequencyperformance.Itisconstructedfromheavy-gauge,rugged

steel.ThesteelrearenclosurewasoptimizedusingFEAtovirtually

eliminatepanelresonance.Theentireenclosureislessthan4”deep

providinganeasyinstallationintonearlyanytightwallorceilingspace.

Arearcover,withprovisionsforajunctionboxfitting,providesaccess

toa4-pinterminalblockthatallowsdirectconnectiontothespeaker

andprovidespassthroughtoadditionalspeakers.FM4.2loudspeakers

providewidedispersion,high-efficiency,high-maximumoutput,easeof

installation,andwide-rangereproductionofmusicorvoice.

Technical Specifications:

Freq.Response(-3dB): 70Hz-20kHz

Freq.Range(-10dB): 52Hz-20kHz

AxialSensitivity: 87dB(SPL1W/1m)

Impedance: 8ohmsnominal(transformerbypass)

CrossoverFrequency: 3.6kHz

Rec.HighpassFrequency: 70Hz

PowerHandling1 : 100WCont.Prog./200WPeak

HFTransducer: 1in.(25.4mm)

LFTransducer:

PassiveRadiator:

4in.(101.6mm)

TransformerTaps: 70V:1.75,3.75,7.5,15,or30W

100V:3.75,7.5,15,or30W

Bypass:8ohmsnominal

Connectors: 4pinphoenixstyleterminals

EnclosureMaterial: Baffle:UL94V-OratedABS

Backcan:Zincplatedsteel

Grille: Perforatedpowdercoatedsteelwithsafety

tether

MountingSystem: Integratedtoggleanchors

SupportHardware: Cutouttemplate,PaintShield

Dimensions: 349.9mmx188.3mmx96.5mm

(13.77”x7.42”x3.80”)

NetWeight(Each): 2.9kg(6.5lb)

ShippingWeight(Pair): 6.8kg(15.0lb)

AllSpecificationsbasedonHalf-SpaceEnvironmentasflush-mounted.

1ContinuousProgramRating:3dBgreaterthancontinuouspinknoise

rating(IEC-shapedpinknoisewith6dBcrestfactor)

TheEVIDFM4.2loudspeakersystemshallbecomprisedofabaffle/

bezelassembly,frontgrille,rearenclosure,transformer,4”passive

radiator,and4”loudspeaker.Theloudspeakerwillfeaturean4”low-

frequencyconeandahigh-temperaturevoice-coilassembly,coupled

witha4-inchpassiveradiator.A1”widedispersiontitaniumcoated

dometweeterextendstheresponseto20kHz.Frequencyresponse,

uniformfrom85Hzto18kHz.Pressuresensitivity,87dBSPLat1

meter(85dBat4feet)onaxiswithonewattofband-limitedpink

noisefrom500Hzto3kHz(ref.20µPa).Minimumimpedance,8.2

ohms.Theloudspeakershallbe349.9mm(13.77in.)by188.3mm

(7.42in.)and96.5mm(3.80in.)deep.Weightshallbe2.9kg(6.5lb)

each.Theflush-mountedloudspeakerpackageshallbetheElectro-

Voice®modelFM4.2.

12000PortlandAvenueSouth,Burnsville,MN55337

Phone:952/884-4051,Fax:952/884-0043

www.electrovoice.com

©BoschCommunicationsSystems 07/2009

Part Number LIT000234 Rev 3

U.S.A.andCanadaonly.Forcustomerorders,contactCustomerServiceat:

800/392-3497 Fax: 800/955-6831

Europe,Africa,andMiddleEastonly.Forcustomerorders,contactCustomerServiceat:

+ 49 9421-706 0 Fax: + 49 9421-706 265

OtherInternatonallocations.Forcustomerorders,ContactCustomerServiceat:

+ 1 952 884-4051 Fax: + 1 952 887-9212

Forwarrantyrepairorserviceinformation,contacttheServiceRepairdepartmentat:

800/685-2606

Fortechnicalassistance,contactTechnicalSupportat:866/78AUDIO

Specificationssubjecttochangewithoutnotice.

• D170406 PA2400T,2x40070vPowerAmplifier

• D170407 PA2250T,2x25070vPowerAmplifier

• D170408 PA2450L,2x450PowerAmplifier

• D170409 PA4150L,4x150PowerAmplifier

 • PRD000120-000

100

1000

10000

20000

3.16

100

316

100

110

Frequency (Hz)

Sensitivity (dB)

Impedance (Ohms)

Frequency Response, Half Space

Impedance

100

1000

10000

20000

3.6

100

360

Horizontal Vertical

Frequency (Hz)

-6dB Beamwidth (Degrees)

Beamwidth (Last Crossing)

100

1000

10000

20000

100

1000

Frequency (Hz)

Directivity Index (DI), dB

Directivity Factor (Q)
