Side 1/8

MADE IN CZECH REPUBLIC

•backup in case of voltage failure > 100 hours

•direct installation on junction box

•well-arranged backlit display

VENUS switch design

•possibility of extending the external

sensor

N L COM NO N L COM NO

DESCRIPTION

PT712 is a digital thermostat with a room sensor, specially designed for electric ﬂ oor heating control.

The thermostat senses the temperature in the room and the difference between actual and

desired temperature switches connected heating device.

When you purchase an external sensor is possible to extend with additional features:

1) control the ﬂ oor temperature;

2) spatial control with monitoring of maximum ﬂ oor temperature.

Another advantage is simple installation in the KU/KP68 junction boxes by means of the PLUG-IN

system, as well as the possibility of setting 2 weekly programs with 6 temperature changes per day.

INSTALLATION AND LOCATION

Install the thermostat in a suitable place (minimum height of 1.2-1.5 m above the ﬂ oor) where its operation

will not be affected by direct hot/cold air ﬂ ow, sunshine or other disturbing inﬂ uences. Do not mount the

thermostat on an exterior wall either. In rooms with increased humidity (bathroom, kitchen), observe valid

standards and install the thermostat as far from the bathtub, shower, basin or sink as possible.

When using external sensor observe the following:

The external ﬂ oor sensor (type CT04-10k, CYXY 2 x 0.5 mm, 10 k:, lenght 3 m, PVC plastic case)

must be located in a ﬂ exible plastic tube embedded in the ﬂ oor, as near to the surface as possible. The

tube must be sealed and protected against in-leak of building materials so that the ﬂ oor sensor can be

replaced easily, if need be. It must not run parallel with power conductors! It can be extended to

a maximum length of 30 metres. The installation can only be done by a properly qualiﬁ ed person!

Disconnect power supply before installation!

1) Switch off the main circuit breaker.

2) Check that the junction box is placed parallel with the wall.

3) Separate the power part of the thermostat from its microprocessor (main) part; see Fig. 1.

4) Pull the connecting terminals out of the thermostat rear part, see Fig. 2.

5) Connect conductors to the terminals acc. to the wiring diagram below, see Fig. 3.

6) Insert the terminals into the thermostat terminals and fasten the power part to the junction

box, see Fig. 4 and 5.

7) Insert the main part connector into the power part and push it; the metal springs must

ﬁ t in the given holes, see Fig. 6 and 7.

8) Switch on the main circuit breaker; the thermostat is ready for operation. LCD backlight becomes active only

after charging the backup battery (up to 24 hours).

9) Set the constant 4 (page 6) according to the load, this could cause an inaccurate display of the current

temperature.

Note: We recommend you test correct connection after installation, see the TEST function (page 7).

Wiring diagram: Fig. 1

When using the low tariff

L‘ = disconnected phase

power part main part

PULLPULL

connecting

terminals

HEATING

NTC 10k NTC 10k

* P= max. 2760 W
