Side 1/8

MADE IN CZECH REPUBLIC

•including external sensor

•backup in case of voltage failure > 100 hours

•direct installation on junction box

•well-arranged backlit display

VENUS switch design

N L COM NO N L COM NO

DESCRIPTION

PT712-EI is a digital thermostat with a room and ﬂ oor sensor, specially designed for electric ﬂ oor heating

control. The internal-external sensor combination enables the regulation of:

1) ﬂ oor temperature (external sensor) - suitable, for instance, for bathrooms where a warm ﬂ oor is

desirable, irrespective of the room temperature;

2) room temperature (internal sensor) - when comfortable room temperature is required;

3) combined (both sensors) - the internal sensor scans the room temperature, while the

external one monitors the maximum ﬂ oor temperature;

comfortable room temperature is required, however, with

simultaneous monitoring of the ﬂ oor temperat (suitable for wooden

and laminated ﬂ oors).

Another advantage is simple installation in the KU/KP68 junction boxes by means of the PLUG-IN

system, as well as the possibility of setting 2 weekly programs with 6 temperature changes per day.

INSTALLATION AND LOCATION

Install the thermostat in a suitable place (minimum height of 1.2-1.5 m above the ﬂ oor) where its operation

will not be affected by direct hot/cold air ﬂ ow, sunshine or other disturbing inﬂ uences. Do not mount the

thermostat on an exterior wall either. In rooms with increased humidity (bathroom, kitchen), observe valid

standards and install the thermostat as far from the bathtub, shower, basin or sink as possible.

The external ﬂ oor sensor (type CT04-10k, CYXY 2 x 0.5 mm, 10 k:, lenght 3 m, PVC plastic case)

must be located in a ﬂ exible plastic tube embedded in the ﬂ oor, as near to the surface as possible. The

tube must be sealed and protected against in-leak of building materials so that the ﬂ oor sensor can be

replaced easily, if need be. It must not run parallel with power conductors! It can be extended to

a maximum length of 30 metres. The installation can only be done by a properly qualiﬁ ed person!

Disconnect power supply before installation!

1) Switch off the main circuit breaker.

2) Check that the junction box is placed parallel with the wall.

3) Separate the power part of the thermostat from its microprocessor (main) part; see Fig. 1.

4) Pull the connecting terminals out of the thermostat rear part, see Fig. 2.

5) Connect conductors to the terminals acc. to the wiring diagram below, see Fig. 3.

6) Insert the terminals into the thermostat terminals and fasten the power part to the junction

box, see Fig. 4 and 5.

7) Insert the main part connector into the power part and push it; the metal springs must

ﬁ t in the given holes, see Fig. 6 and 7.

8) Switch on the main circuit breaker; the thermostat is ready for operation. LCD backlight becomes active only

after charging the backup battery (up to 24 hours).

9) Set the constant 4 (page 6) according to the load, this could cause an inaccurate display of the current

temperature.

Note: We recommend you test correct connection after installation, see the TEST function (page 7).

Wiring diagram: Fig. 1

When using the low tariff

L‘ = disconnected phase

power part main part

PULLPULL

connecting

terminals

HEATING

NTC 10k NTC 10k

* P= max. 2760 W
