Side 1/7

Viale Vicenza 14

36063 Marostica VI - Italy

www.vimar.com

30811.x-02974 02 2507

30811.x - 02974 Connected dial thermostat

VIEW WIRELESS SMART HOME

THREE OPERATING MODES (ALTERNATIVE)

Stand alone • •

Download the View Wireless App from the stores onto the tablet/smartphone you

will be using for configuration.

When the device is powered for the rst conguration, we recommend you search for any

new rmware and perform the update.

Depending on the mode you select, you will need:

Stand alone

Nothing else

Gateway

art. 30807.x-20597-19597-16497-14597

Smart Home Hub

View App

for management via smartphone/tablet

Samsung SmartThings

Hub

Amazon Alexa, Google Assistant, Siri (Homekit)

voice assistants for possible voice operation

Create your Installer account on MyVimar (on-line).

STAND ALONE CONFIGURATION

1. Wire all the thermostats.

2. Start the View Wireless App and log in with the credentials you just created.

3. Create the system and the environments.

4. Associate all the thermostats with the environments.

To associate the thermostat:

• Select “Add” ( ), choose the environment to place it and give it a name

• Select ; activate the Bluetooth connection on your tablet/smartphone and approach the

thermostat

• Press for 5 s; the ring ﬂashes blue and association is complete.

5. For each thermostat, set the functions and parameters.

6. Go to the “Temperature control” menu and for each thermostat set the time schedules, the

setpoints for the operating modes and the current time.

Note: In the event of a mains power outage and subsequent restoration, the product will return to

operating in manual mode with the last set point set. You will therefore need to set the date/time

(see paragraph entitled "Thermostat date/time setting") to restore operation in automatic mode.

CONFIGURATION IN

1. Wire all the devices in the system (2-way switches, relays, thermostats, gateway, etc.).

Start the View Wireless App and log in with the credentials you just created.

3. Create the system and the environments.

4. Associate all the devices with the environments, except for the gateway (which should be

associated last).

To associate the thermostat:

• Select “Add” ( ), choose the environment to place it and give it a name

• Select ; activate the Bluetooth connection on your tablet/smartphone and approach the

thermostat

• Press for 5 s; the ring ﬂashes blue and association is complete.

5. For every device, set the function, the parameters and any accessory devices (magnetic

contact art. 03980 and related function).

Transfer the configuration of the devices to the gateway and connect it to the Wi-Fi network.

7. Transfer the system to the Administrator user (who must have created his/her profile on

MyVimar).

For full details, see the View Wireless App manual that can be downloaded from the www.

vimar.com website.

CONFIGURATION IN

Perform the procedure set out in points 1 and 2 of configuration in Bluetooth.

Associate the thermostat directly with a ZigBee hub (for instance a SmartThings Hub).

1) Download the Zigbee software onto the thermostat using the View Wireless App (see the View

Wireless App manual). Press the button until the display shows “bt” and the ring flashes

blue. Perform the same procedure to update the software on the device.

2) After conversion to Zigbee technology (or the software update), the thermostat automatically

goes into pairing mode for 5 minutes, during which the ring flashes white. If the thermostat is

not in pairing mode, cut off the power supply and restore it after a few seconds.

3) Associate the thermostat following the procedure envisaged by the ZigBee hub.

4) Associate the module following the procedure envisaged by the ZigBee hub (see the hub

manufacturer’s documentation).

Set the thermostat parameters.

Within the first 10 minutes of powering the thermostat (already associated with the ZigBee hub)

or after restarting at the end of association with Zigbee, press the button relating to the parameter

to edit as shown below.

• Short press = degrees Celsius/Fahrenheit selection

• Long press (5 s) = the thermostat enters the configuration phase (bt)

• Prolonged press (30 s) within the first 5 min of powering = device reset (rst)

Programmable function key:

• Display brightness and RGB LED in standby setting

- 1

press = current brightness display

- Subsequent presses = cyclic display of available brightness values L-3

(high), L-2 (medium), L-1 (low) and L-0 (off).

• Heating/air conditioning mode selection

• Call up scenario

Display

• bt = devices in Bluetooth configuration

• off = thermostat off; on = thermostat on

• °C = degrees Celsius; °F = degrees Fahrenheit

• L-0, L-1, L-2, L-3 = brightness in standby (from the lowest to the highest)

• H = heating; C = air conditioning

• opn* = window open (associated with the thermostat via magnetic contact art.

03980 or with an input of the 3in 1out module art. 03983 )

Set point adjustment dial

Lightable ring

• Power on and off.

Upon power on or off, the thermostat starts in the last operating mode associated

with it set via the View* or View Wireless* App.

Programmable function key:

• Heating/air conditioning mode selection

• Fan speed setting

* Only for Bluetooth technology

Ring signalling

All flashing blue = thermostat in configuration mode

All lit amber* = thermostat in heating mode and relay active

All lit blue** = thermostat in air conditioning mode and relay active

• Lit amber* = thermostat in heating mode and relay not active

• Lit blue** = thermostat air conditioning mode and relay not active

In standby, the brightness is set during configuration; otherwise, the value is the

maximum one.

2***

• Flashing red = the thermostat, in automatic mode, has lost the hourly value and

has therefore switched to manual mode.

When it receives the hourly value from the gateway or the View Wireless App again,

the thermostat returns to automatic mode and the flashing ends.

* Amber with automatic colour or of the selected colour.

** Blue with automatic colour or of the selected colour.

*** Only for Bluetooth technology
