RADAR beam path

Class B

AIS Transceiver

QUICK START GUIDE

What’s in the box?

For full instructions on how to install and use your

AIS Transceiver please refer to the product manual.

Step 1 – Install the Transceiver

Front panel controls

What do I need?

201-0708:3

Panel mounted

Overhead mounted

(reverse mounting bracket)

Desk mounted

Step 2 – Install the Antennas

GNSS antenna should be at least 5m (16ft)

from RADAR or satellite communication antennas.

It should also be away from the RADAR beam path

and mounted on a rigid surface.

VHF antenna should be at least

3m (10ft) from other transmitting radio,

satellite and RADAR antennas.

Power cable

Product CD

Warranty card

Product Mounting

Template

Quick Start

Guide

AIS transceiver

VHF antenna

(Connector

type: PL-259)

Pozidriv (PZ2)

screwdriver

Allen keys (3mm, 4mm)

12V/24V

power supply

DrillSaw (for panel cut-out)

MMSI number (9 digits):

Vessel name:

Vessel callsign:

Vessel dimensions and GNSS antenna position:

Information needed for installation:

Scroll wheel

(push to select)

Function keys

(up, down, left right)

Back / Home

Micro SD card

slot behind door

Navigation Status /

Screen brightness

Select

Options menu

Display

Mounting bracket

Fixings

GNSS antenna

and cable

Ref A

Antenna

Ref A + Ref B = Length in metres Ref C + Ref D = Beam in metres

Ref B

Stern Bow

Ref C

Ref D

Grounding wire

VHF antenna

GNSS antenna

3m (10ft)

5m (16ft)

Surge Arrestor

Data

Accessory Cable

NAME/MMSI Range Bearing TypeCPA TCPA Age

DUBLIN FISHER 1m 50s

PROXIMITY CRAFT 1m 47s

ATLANTIC PRIDE 0m 1s

212222222 0m 36s

EMSLAKE 0m 45s

PIER 4 0m 6s

444110175

3.15NM

15.5NM

6.9NM

6.7NM

5.2NM

35.8NM

3.15NM

15.5NM

6.9NM

6.7NM

5.2NM

35.8NM

5h 38m

120.8

22.6

37.20

313.4

86.6

167.3

0m 5s

Visible: 12 Filtered out: 0

TARGET LIST

16:58:29 SOG 21.1kt

UTC + 1h COG 88.0°

50° 32.0286’ N

0° 55.2715’ W

Speed / Course

Time

Time oset

Menu title

Main display

area

Messages

Filtering

Power Setting

GNSS status

Alarms

Position

NMEA2000

Optional connections

Chassis/GND

GNSS antenna

VHF antenna

Surge arrestor

12/24V

DC Supply

Red Black

An optional junction box, USB cable and 14/18 way data cables are available to assist with wiring to sensors and displays

NOTE: Numbers and tables refer to

connector pins on unit

This product must be connected to

protective earth via the earth connection

point. It is essential that the earth

connection point is used in all installations,

regardless of what other equipment

is connected. The earth connection point

must be bonded to protective earth using

as short a connection as possible.

11 10 9 78

15 14 1213

6 5 34

18 16

2 1

WIRE COLOUR

RED

BLACK

SIGNAL

VIN +

VIN -

SIGNAL

N2K_NET_SHIELD

N2K_NET_S

N2K_NET_C

N2K_NET_H

N2K_NET_L

5W !

Step 3 – Connecting

the transceiver

Step 4 – Quick Start Sequence

CONFIGURATION CHECK

--:-- -- SOG 21.1kt

UTC + 1h COG 88.0˚

5.0˚ 32.0286’ N

0˚ 55.2715’ W

Save settingsCancel setup

Power supply

MMSI 235001402

GPS position x

INTRODUCTION

--:-- -- SOG -

UTC + 1h COG -

Welcome to your new AIS transceiver.

This setup process will assist with conguring the basic aspects of this device

required for a standard installation. More advanced options (such as conguring

NMEA2000 data sources) are available in options menus after completion of the

setup process. All information entered can be changed at a later date.

The default administrator password is 0000.

NextSkip setup

WARNING - LIMITATIONS ON USE

--:-- -- SOG -

UTC + 1h COG -

This product, including the C-MAP by Jeppesen charts, is intended to be used

only as an aid to navigation. It should facilitate use of ocial government

charts, not replace them. Only Ocial Government Charts and Notices to

Mariners contain all the current information needed for safe navigation. This

product’s features cannot be relied on as complete or accurate and may vary

depending on location. It is the captain’s responsibility to use ocial

government charts, notices to mariners, caution, sound judgement and

proper navigational skills when operating their boat using this product.

This product supports C-MAP by Jeppesen electronic charts. Their use is

DATA SOURCES

--:-- -- SOG -

UTC + 1h COG -

NextCancel setup

Sensor 1

Sensor 2

Sensor 3

No data source

NMEA2000 data sources have to be explicitly selected from the NMEA2000

settings screen.

ENTER VESSEL IDENTITY

--:-- -- SOG -

UTC + 1h COG -

NextSkip setup

MMSI (required)

Vessel name

Vessel callsign

Vessel type

The unit is now

congured and

ready to go.

Final window, all three

ticks should be displayed.

5W5W

GNSS ANTENNA POSITION

--:-- -- SOG -

UTC + 1h COG -

NextCancel setup

B A

5W Please ensure that you

enter the correct MMSI

as this cannot be

changed at a later date.

PINWIRE COLOUR FUNCTIONPORT NAME

IN MKD

DESCRIPTION

BLACK

BLUE/WHITE

WHITE/BLUE

NMEA0183

PORT 1

NMEA0183

PORT 1

NMEA0183

PORT 1

NMEA0183

PORT 1 COM

NMEA0183

PORT 1 Tx B

NMEA0183

PORT 1 Tx A

HIGH SPEED NMEA0183

OUTPUT (38,400 baud)

INTENDED FOR CHART

PLOTTERS

PINWIRE COLOUR FUNCTIONPORT NAME

IN MKD

DESCRIPTION

RED/WHITE

ORANGE/WHITE

BLACK

NMEA0183

PORT 2

NMEA0183

PORT 2

NMEA0183

PORT 2

NMEA0183

PORT 2 Rx B

NMEA0183

PORT 2 Rx A

NMEA0183

PORT 2 COM

CAN BE SET TO LOW SPEED

(4,800 baud) INTENDED FOR

CONNECTION TO OTHER

NMEA0183 COMPATIBLE

SENSORS FOR

MULTIPLEXING OF DATA

TO THE CHART PLOTTER
