Side 1/6
Features
Protection, control and metering
Automatic engine start / stop
and load transfer
Automatic shutdown on fault condition
LED status and fault indication
Simple push-button controlled operation
Automatic and test mode control
Two user configurable inputs
Fully programmable
Controls
Engine fuel supply or engine stopping
Starter motor
Automatic generator start
Load transfer on mains failure
Load transfer to mains
External alarm horn
Fail Monitoring
Alternator voltage and frequency
Charging generator field current
Engine temperature
Oil pressure
Low battery voltage
Monitors
Mains voltage (Phase-Phase, Phase-Neutral)
Alternator voltage and frequency
Battery voltage
Error indication
Program parameters
The EAOM-17 controller unit offers automatic engine starting, stopping, transfer switching, protection, control and
metering of generator sets. In the event of a mains supply failure, the unit automatically transfers the load from the
mains to the generator. Microprocessor technology allows exact measurement, set point adjustment and timing
functions with the parameters to be simply programmed and displayed from the front panel.
The EAOM-17 automatic transfer switch controller provides integrated generator set control, protection, metering
and automatic load transfer. If a fault is detected, the engine will automatically shutdown and the failure will be
indicated by a relevant fault LED and alarm horn. The unit detects failure of any phase of the mains supply and is
able to start the generator and transfer the load. When the mains supply is restored within the pre-set limits, the
load is transferred back to the mains supply and the generator is shutdown in a controlled manner. EAOM-17 offers
fully automatic operation and test mode which allows the generator to be run without taking the load. Mode of
operation can be changed at any time without affecting the operational status of the generator or load connection.
Mains voltage is continuously measured and compared with programmable upper and lower voltage limits. The
AUTO push button selects automatic operation, whereby the unit uses these limit parameters to decide when to
switch the load between the mains supply and the generator. When the mains supply has been restored, the unit
will switch the load back from the generator to the mains supply. Programmable delays allow time for the voltage to
settle before reconnecting the load.
TEST mode selection allows off load testing of the generator. As with automatic and manual modes, all fault
indication circuits and alarms are operational. If a mains failure occurs whilst the unit is in test mode, the unit will
automatically revert to AUTO operation and switch the load to the generator. Automatic Testing to exercise the
generator and re-charge the batteries can be programmed to operate at time intervals to suit the user and
application.
Two user configurable inputs are included which can be configured to respond in any of eight different ways per
input. They may be configured to sound an external horn, flash warning indicators, stop the engine, disconnect the
load or to provide latched and unlatched indication always or while the engine is running or in addition to this
shutdown the engine or the remote inhibit if selected.
Operation
Automatic Mode
Test Mode
LED Indicators and Alarms
For certain fault conditions the ALARM LED will also flash,
advising specific LED fault messages or information alarms which can be read from the front panel 4 digit display.
1
Automatic Transfer Switch Controller, 72x72 DIN Size
EAOM-17
Automatic Transfer Switch
Controller, 72 x 72 DIN Size
Introduction Brochure. ENG EAOM-17 01 V00 05/12
Generator Speed (frequency)
Equipment Use
Electrical control equipment for generating sets
Housing & Mounting 72mmx72mmx95mm (including connectors) DIN43700 plastic housing for panel mounting
Panel Cut-out
69mmx69mm
Protection
NEMA4X (IP65 at front panel, IP20 at rear side)
Weight
Approximately 0.27 kg
Environmental Rating
Standard, indoor at an altitude of less then 2000 meters with non-condensing humidity
Operating / Storage Temperature
-25ºC to +70ºC / -40ºC to +85ºC
Operating / Storage Humidity
90% max. (Non-condensing)
Installation Over Voltage Cat.
II appliances, portable equipment
Pollution Degree
II, Normal office or workplace, non-conductive pollution
Mode of Operation
Continuous
EMC EN-61000-6-4, EMC generic emission standard for industrial equipment
EN-61000-6-2, EMC generic immunity standard for industrial equipment
Electrical Safety EN-61010-1, safety requirements for electrical equipment for measurement, control and
laboratory use
Battery Supply Voltage(Z)
8-32 VZ max. Operating current is 240 mA
Cranking Dropouts Battery voltage can be 0VZ for max. 100msn during cranking (battery voltage should be
at least nominal voltage before cranking)
Battery Voltage Measurement
8-32VZ, accuracy:1% FS, resolution : 0.1V
Mains Voltage Measurement
Selectable three phase or single phase, 4-wire connection for three phase,
2-wire connection for single phase gen-set
35-300VL-NVRMS (@15.6-99.9 Hz). Accuracy: 1% FS. Resolution : 1V
Generator Voltage Measurement
35-300VL-NVRMS (@15.6-99.9 Hz). Accuracy: 1% FS. Resolution : 1V
Specifications
Charge Generator Excitation
220mA, max.4W
Display 4 Digits, 7 segments LED display showing :
Mains voltage (Phase-Phase and Phase-Neutral)
Alternator voltage
Alternator frequency
Battery voltage
Program parameters
Failure Indicators Engine start
High temperature
Low oil pressure
Generator over frequency
Generator voltage failure
Charge generator failure
Battery voltage failure
Configurable input-1
Configurable input-2
Status Indicators TEST mode LED
PROG mode LED
OFF mode LED
AUTO mode LED
Mains contactor LED
Generator contactor LED
Contact Sensing Inputs
Oil Pressure Switch (NC)
Temperature Switch (NO)
Configurable Input-1 (NO)
Configurable Input-2 (NO)
Relay Outputs
Start relay (1NO. 12A@32V Z )
Fuel relay (1NO. 12A@32V Z )
Horn relay (1NO. 12A@32V Z )
Mains contactor relay (1NC. 5A@250V V )
Generator contactor relay (1NO. 5A@250V V )
15.6 to 99.9 Hz. (@35-300 VL-N V) Accuracy; 0.25 % FS, Resolution; 0.1 Hz.
Information Alarm Stop Error Message (Fail to Engine Stopping)
2
Automatic Transfer Switch Controller, 72x72 DIN Size
