11 ENG IPERTU-SMRXXX 02 V01_0824
Semi Universal Analog Input & Analog Output Extension Modules
General Specicaons :
* Modules have 2 or 4 input channels according to module type
* Analog input types (each analog
input can be set in different type
individually) :
- V, mA
* ON/OFF kontrol, PID kontrol, AutoTune, SelfTune
* According to module type; 4 or 2 analog output (V/mA)
* Modbus RTU communicaon protocol with RS485
* USB Device (For device conguration)
* Modular connecon (up to 16 modules including itself)
* Led indicators:
- Power Supply, USB, RS-485
- Analog Input error led indicators
- Acve Output led indicators
SMR1P1-00-01-00-01_1
SMR1P1-00-03-00-03_1
SMR1P1-00-20-00-01_1
SMR1P1-00-21-00-03_1
Technical Specicaons
Module Type SMR1P1-00-01-00-01 SMR1P1-00-03-00-03 SMR1P1-00-20-00-01 SMR1P1-00-21-00-03
Supply Voltage - 28,8 VDC)
Power Consumpon 3W 4W 3W 4W
Communicaon RS-485 Modbus RTU
USB Device Mini USB, USB 2.0
Analog Inputs
Number of Inputs 4 2 4 2
Input Sensor Type Cu-50, PT-100, PT-1000, PTC, NTC, mV V, mA
Measurement Range
/ Resoluon
Cu-50 -200 ....
-328 ....
PT-100 -200 ...
-328 ...
PT-1000 -200 ...
-328 ...
PTC -50 .....
-58 .....
NTC -50 .....
-58 .....
mV 0 .........
V 0 ......... +2V / 1 mV
0 ......... +5V / 1 mV
0 ......... +10V / 1 mV
2 ......... +10V / 1 mV
mA 0 .........
4 .........
ADC resoluon 15 bit
Input Impedance
Voltage type inputs Other type inputs
mA type inputs
Overall accuracy % 0.2 (full scale)
Response me Per channel
300msec
150 msec 150 msec 150 msec
Average function
The aritmec average of the last read measurements according to the specied average
number of samples
Fault detecons 1- short circuit, 2- sensor break, 3- over range
Analog Outputs
Number of Outputs 2 x V / mA 4 x V / mA 2 x V / mA 4 x V / mA
Output range 0-10V or 0-20mA (only one tpe can be selected in the same me)
Overall accuracy % 0.5 (in the full scale measurement range)
Output Resistance For voltage output for current output
Response me ~200 msec
Led Indicators
Power
Always ON if the power input is in working limits, ashes 0.1s when undervoltage detected
Flashes 1s if the communicaon between Master and Slave module broken
12 ENG IPERTU-SMRXXX 02 V01_0824
Flashes 0.2s ON / 2s OFF if the device in Software Boot Mode
USB
Always ON if the USB cable plugged, ashes during data transfer
RS485
Flashes during Modbus data transfer
Analog Input
Always OFF in normal operaon
Always ON in case of fault detecon (Sensor Break, Short Circuit, Over Range)
Flashes during PID auto-tune or self-tune process ongoing
Analog Output ON when output acve, OFF otherwise
Operaon / Storage Environment
Operaon Temp. -
Storage Temp. -
Isolation
* There is no isolaon between Power, RS485 and USB
* There is no isolaon between Analog Inputs
* There is no isolaon between Analog Outputs
* 500 VAC between Analog Input and Power Input
* 500 VAC between Analog Output and Power Input
* 500 VAC between Analog Input and Analog Output
Modbus Parameters Addresses
Address
R/W
Parameter Name Denion Default
Modbus Parametreleri
40001 R/W ID Modbus ID can be set between 1 255 1
40002 R/W Baud Rate (kbps)
0- 1200 3- 9600 6- 57600
1- 2400 4- 19200 7- 115200
2- 4800 5- 38400
6
40003 R/W Stop Bit 0- 1 Bit 1- 2 Bit 0
40004 R/W Parity 0- None 1- Even 2- Odd 0
Cihaz Parametreleri
40005 R Reserved
In case of Master Mode, shows number of connected
Slave Modules
-
40006 R Type/Bus Order
b15-b8 : module types according to code :
SMR1P1-00-01-00-01_1 = 0xB3
SMR1P1-00-03-00-03_1 = 0xB1
SMR1P1-00-20-00-01_1 = 0xB4
SMR1P1-00-21-00-03_1 = 0xB2
b7-b0 : module bus order :
0- Master module
N-
17- Single module (No other device on bus)
-
40007 R Version
HW and SW versions displayed on a bitwise basis
b15-b12 : Hardware Version
b11-b6 : Soware Major Version
b5-b0 : Soware Minor Version
-
40008 R/W
Error Status
2
Error status displayed on a bitwise basis
b0 : Low Power Supply Voltage Level
b1 : Analog Input could not read
b2 : RS485 communication meout error
1
b8 : Error in slave module number
1
b9 : Error in slave module type
1
b10 : Error in communicaon between slave modules
1
b15-b12 : The number of the Slave module in which the
error was detected
Note-1 : Error bits are only valid for Master Module.
Note-2 : In case of communication timeout error arises in
Master Module, communicaon between slave modules
interrupted. By wring 3083 to the relavent address, the
error bit cleared and the communicaon started again.
-
