Side 1/2
i) Follow this path to add the serial no. of this device:
Org -> Inventory -> Register Device
1 2
Detachable Antennas
2 x 2.4GHz Antennas
2 x 5GHz Antennas
iii) Select an organization and
then click “ ” on the
down-right corner to add
the device.
+
iv)
Device Label
Scan the QR code on the device label for adding the device
to Inventory of this organization. You also can manually add
S/N to Inventory of this organization.
v) Add the device to your network, slide the device to left and
then click “Add to Network” by using EnGenius Cloud App.
Using
EnGenius Cloud Services
Cloud Managed Outdoor Access Point
ECW Series
Version1.1
Ethernet port:
Power source option - An ECW device can be powered up by an
802.3af/at-compliant PoE device.
* LAN (PoE): Uplink port accepts an 802.3af/at power source.
Package Contents
-ECW160
-ECW260
Quick Installation
Guide
Pole Mounting
Strap x1
AP / Bridge Adhesive Label
On the Cloud APP
C-2. Register devices through the mobile app
i) Download the EnGenius Cloud App via your smartphone
ii) Log in with your cloud account (if you do not have an
account, please sign up on https://cloud.engenius.ai)
Locate the serial no. on the back of the device.
C) Register device to your cloud account
← Device Label
C-1. Register device through EnGenius Cloud
On the Cloud GUI
AP / Bridge Quick Installation
Guide
Detachable Antennas
2 x 2.4GHz Antennas
2 x 5GHz Antennas
Mounting Bracket
Ground Wire & Screw Set Mounting Screw
Kit x 2
Wall Mount
Screw Kit
ii) Input the serial no. from the device label, and then click
"Register"
iii) In the “ Inventory” page , using “Assign to Network”
( )to assign the device to your personalized
network.

Pre-Installation Preparation
Registering a device and configuring on EnGenius Cloud should
be completed before performing an on-site installation.
Please confirm that your device has established a
connection to the Internet before proceeding.
A) Register an account to sign in EnGenius Cloud
(https://cloud.engenius.ai) if you use this service first time.
When logging on, you can use the existed default Network
or create a personalized Network under the Org. and provide
a configuration to enable push operations to cloud devices.
B)
Notice: The browser version for Cloud GUI supported list as following.
(1) Google Chrome: 57.0.2987.110 and later
(2) Apple Safaris: 10.0.3(12602.4.8) and later
(3) Microsoft Edge: 80.0.361.103 and later
(4) Mozilla Firefox: 52.0 and later
1
ECW260
A) Thread the open end of the pole strap through the two tabs on
the pole mount bracket.
B) Lock and tighten pole strap to secure pole mount bracket to pole.
A
B
A
BC
Determine where the Access Point to be placed and mark location
on the surface for the four mounting holes of wall mount base.
Use the appropriate drill bit to drill two 8.1mm diagram and 26mm
depth holes in the markings and hammer the bolts into the
openings. Screw the anchors into the holes until they are flush
with the wall.
Slide the mount bracket into the slot of the Access Point.
B)
A)
C)
Screw the included screws into the anchors.
Technical Support
Country of Purchase
Service Center
Service Information
Los Angeles, USA
Dubai, UAE
support@engeniusnetworks.eu
Netherlands
Europe
www.engeniusnetworks.eu
North America
www.engeniuscanada.com
Africa / CIS / Middle East
www.engenius-me.com
support@engeniustech.com
Local: (+65) 6227 1088
Singapore
www.engeniustech.com.sg
Asia / Oceania
twsupport@engeniusnetworks.com
Toll Free: 0800-003-885
Taiwan
www.engeniustech.com.tw
support@engeniustech.com
Local: (+1)714 432 8668
Press 1 - Tech support
Canada
www.engeniustech.com
rma@engeniuscanada.com
Local:(+1) 905 940 8181
and then follow the prompts press 3
- RMA and Tech Support
support@engenius-me.com
Local: (+971) 4 339 1227
B)
A) Thread the open end of the Pole Strap through the two tabs on
the Pole Mount Bracket.
Lock and tighten Pole Strap to secure Pole Mount Bracket to the
Pole.
a) Select “Local Setting” on this page.
b) Change IPv4 setting from “AS DHCP client” to “Use Static IP”.
Reconnect this device to the LAN again if necessary.
d)
c) Configure the IP address, gateway, net mask, and proxy
policy as required.
iii) By default, EnGenius cloud access point (ECW series) is
assigned an IP address dynamically by the DHCP server.
If you encounter issues with IP address assignment, please
double check the IP settings including IP address, subnet
mask, gateway, proxy, and management VLAN.
If the issue is still existed, you may change your IP assignment
from "DHCP mode" to "Static IP" via the following procedure.
ii) Enter the URL in web browser:
or the IP to access the http://EnGenius.local 192.168.1.1
device’s user interface. You can review device status after
logging into the AP with the default account/password
( default admin account/ password : admin/ admin.)
Pole Mounting the Outdoor Device
ECW160
Wall Mounting the Outdoor Device
ECW160
ECW260
Troubleshooting the Cloud Connection
Check your firewall settings to prevent any issues.
E)
Automatically Firmware upgradeF)
Once the device is connected to Cloud, it will be upgraded
to the most up-to-date firmware version automatically.
While the firmware is upgrading, the LED light will blink for
few minutes till the process has been finished.
Usually it will take 2-3 minutes to power up the AP and connect
to the Cloud. If firmware upgrade is required, it might take even
longer to 8-10 minutes for firmware upgrade done. If you still
see power LED light blinking after three more minutes, there
might have the problem about connecting to EnGenius Cloud.
i)
To troubleshoot the connection issue, you may login to Local page:
Use your client device (e.g., a laptop, mobile device, or tablet)
to find the SSID: “EnMGMTxxxx” (xxxx is the last four digits
of LAN MAC which can be found on the back of the device)
and connect to it.
D) This device is now added into your network.
Maximum data rates are based on the IEEE standards. Actual throughput and range may vary depending on many
factors including environmental conditions, distance between devices, radio interference in the operating
device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept any interference received, including interference
that may cause undesired operation. Trademarks and registered trademarks are the property of their
respective owners. For United States of America: Copyright © 2020 EnGenius Technologies, Inc. All rights reserved.
NOTE
Determine where the Access Point to placed and stick the
Adhesive label on the surface.
Use the appropriate drill bit to drill two 8.1 mm diagram and
26mm depth holes on the markings of the label.
Remove the label and Screw the anchors unto the holes until
they are flush with the wall.
B)
A)
C)
Screw the included screws into the anchors. Place the Access
Point against wall with the mounting screw heads.
D)
Make sure that your firewall allows 80/443 port outbound
access.
