NO 101-400-0251-02:
Issue:1.2
Eyeball Network Camera
Quick Setup Guide
Special Announcement
, For more information please refer to website.
Fully understand this document before using this device, and
strictly observe rules in this document when using this device. If
you install this device in public places, provide the tip "You have
entered the area of electronic surveillance" in an eye-catching
place. Failure to correctly use electrical products may cause fire
and severe injuries.
It alerts you to moderate dangers which, if not
avoided, may cause minor or moderate injuries.
It alerts you to risks. Neglect of these risks may
cause device damage, data loss, device
performance deterioration, or unpredictable results.
It provides additional information.
ŸStrictly observe installation requirements when installing the
device. The manufacturer shall not be held responsible for
device damage caused by users' non-conformance to these
requirements.
ŸStrictly conform to local electrical safety standards and use
power adapters that are marked with the LPS standard when
installing and using this device. Otherwise, this device may be
damaged.
ŸUse accessories delivered with this device. The voltage must
meet input voltage requirements for this device.
ŸIf this device is installed in places with unsteady voltage, ground
this device to discharge high energy such as electrical surges in
order to prevent the power supply from burning out.
ŸWhen this device is in use, ensure that no water or any liquid
flows into the device. If water or liquid unexpectedly flows into
the device, immediately power off the device and disconnect all
cables (such as power cables and network cables) from this
device.
ŸDo not focus strong light (such as lighted bulbs or sunlight) on
ŸAvoid heavy loads, intensive shakes, and soaking to prevent
damages during transportation and storage. The warranty does
not cover any device damage that is caused during secondary
packaging and transportation after the original packaging is
taken apart.
ŸProtect this device from fall-down and intensive strikes, keep the
device away from magnetic field interference, and do not install
the device in places with shaking surfaces or under shocks.
ŸClean the device with a soft dry cloth. For stubborn dirt, dip the
cloth into slight neutral cleanser, gently wipe the dirt with the
cloth, and then dry the device.
ŸDo not jam the ventilation opening. Follow the installation
instructions provided in this document when installing the device.
ŸKeep the device away from heat sources such as radiators,
electric heaters, or other heat equipment.
ŸKeep the device away from moist, dusty, extremely hot or cold
places, or places with strong electric radiation.
ŸIf the device is installed outdoors, take insect- and moisture-
proof measures to avoid circuit board corrosion that can affect
monitoring.
ŸRemove the power plug if the device is idle for a long time.
ŸBefore unpacking, check whether the fragile sticker is damaged.
If the fragile sticker is damaged, contact customer services or
sales personnel. The manufacturer shall not be held responsible
for any artificial damage of the fragile sticker.
ŸAll complete products sold by the manufacturer are delivered
along with nameplates, quick setup guide and accessories after
strict inspection. The manufacturer shall not be held responsible
for counterfeit products.
ŸThe manufacturer will update this manual according to product
function enhancement or changes and regularly update the
software and hardware described in this manual. Update
information will be added to new versions of this manual without
prior notice.
ŸThis manual may contain misprints, technology information that
is not accurate enough, or product function and operation
description that is slightly inconsistent with the actual product,
the final interpretation of company is as a standard.
ŸThis manual is only for reference and does not ensure that the
information is totally consistent with the actual product. For
consistency, see the actual product.
Precautions
Open the package, check the appearance of product for no
obvious damage, and confirm the item list for table 1-1 is
consistent.
Table 1 1- Packing list
2.1 Device Ports
Component
Quantity
Remark
Eyeball Network Camera
1
Quick Setup Guide
1
Accessory package
1
Location sticker
1
Different devices may have different interfaces, multi-head
cables, and fill lights; Please refer to the actual product.
Figure 2 1- Hardware interfaces
Long press the reset button for 5 seconds to
restore the original settings.
1
ID Port Name
Table 2-1 Hardware interfaces description
CVBS video
out
Output an analog video signal. You can
connect the camera to a TV monitor through
this interface to view the analog video.
Description
NOTE
NOTE
NOTE
this device. Otherwise, the service life of the image sensor may
be shortened.
ŸIf this device is installed in places where thunder and lightning
frequently occur, ground the device nearby to discharge high
energy such as thunder strikes in order to prevent device
damage.
Reset button
2
3
SD card slot Install a SD card.
NOTE
ŸBefore installing a SD card, make sure the
card not in write protection state.
ŸBefore removing the SD card. make sure
the card not in write protection state.
Otherwise, the data may be lost ,or the SD
card may be damaged.
CAUTION
WARNING
WARNING
CAUTION
O
O
O
OOp
p
p
ppe
e
e
een P
n P
n P
n Pn Pa
a
a
aac
c
c
cck
k
k
kka
a
a
aag
g
g
gge E
e E
e E
e Ee Ex
x
x
xxa
a
a
aam
m
m
mmi
i
i
iin
n
n
nna
a
a
aat
t
t
tti
i
i
iio
o
o
oon
n
n
nn
1
D
D
D
DDe
e
e
eev
v
v
vvi
i
i
iic
c
c
cce S
e S
e S
e Se St
t
t
ttr
r
r
rru
u
u
uuc
c
c
cct
t
t
ttu
u
u
uur
r
r
rre
e
e
ee2
Table 2-3 Multi-head cable 2 description
Reset button
SD card slot
CVBS video out
Fill light settings
Camera’s fill light has four modes, they are intelligent dual light (
current fill light will switch to warm light after an alarm is triggered,
and will switch back to the original fill light for 30s after the alert is
released.), warm light, infrared lamp and none (Close the fill light
and the color of image will stay in previous mode).
The different cameras can be set different fill light modes, please
set fill light modes according to the actual scene.
Day mode: It can be used in the scene with sufficient ambient light
for 24 hours, do not turn on the fill light, and the image is in color.
Night mode: it can be used in the scene where there is insufficient
ambient light for 24 hours, turn on the fill light (it can be selected
according to the four modes of the fill light).
Auto mode: Automatically switch the fill light mode according to
the luminance of the environment.
Timing mode: Set the start and end time of the day, this time
period is day mode for camera.
2 2 Camera Dimensions.
Figure 2-4 Dimensions Unit: mm
Different devices may have different dimensions; Please
refer to the actual product.
NOTE
φ118
94
120.0°
120.0°
3-φ5
φ107
φ118
23
94
1
2
3（Some models
may not have）
Reset
Power
Figure2 2- Multi-head cable 1
Table 2-2 Multi-head cable description
ID
Core
Description
1
Network
access
interface
Connect to a standard Ethernet
cable or PoE. The green light is on,
the network connection is normal;
The yellow light flashes when the
data is transmitted. Some models
maybe not have the lights; Please
refer to the actual product.
2
Audio output
Connect to an external audio
device such as a speaker.
3
Audio input
port
Receive an analog audio signal
from devices such as a sound
pickup device.
4
Power supply
(DC 12V)
Connect to a 12V direct current
(DC) power supply.
5
Reset button
Long press the reset button for 5s
to restore the original settings.
6
G
Alarm output COM
OUT
Alarm output
G
Alarm input COM
IN
Alarm input
2
1
Network
access
interface
Connects to a standard Ethernet cable or
PoE. The green light is on, the network
connection is normal; The yellow light
flashes when the data is transmitted.
Some models maybe not have the lights;
Please refer to the actual product.
Support
PoE
supply.
Connects to a 12V direct current (DC)
power supply.
ID Core Description Remark
3Reset button
Power supply
(DC 12V)
Long press the reset button for 5s to
restore the original settings.
Figure 2 3- Multi-head cable 2
Res et
Port
2
3
4
5
6
（Some models may not have）
1
IN
OUT
GG
4.3 Browsing Video
To ensure the real-time video can be played properly, you must
perform the following operation when you log in the web for the first time:
If user can access the web immediately please ignore the steps of ,
adding trusted sites .
Figure 4 3 - Adding a trusted site
Step 2 In the Internet Explorer, choose Tool Internet Options > >
Security Customer level > , and set Download unsigned
ActiveX control and initialize and script ActiveX controls not
marked as safe for scripting under ActiveX controls and
plug-ins to Enable, as shown in figure 4-4.
Step 3 Download and install the player control as prompted.
If the repair tips displayed when installing the control , please
ignore the prompt, and continue the installation, the login page is
displayed when the control is loaded.
Step 1 the Internet Explorer. Choose Tools Internet options > >
Security Trusted sites Sites > > , in the display dialog box, click
Add, as shown in figure 4-3.
To browse a real-time video, click Live Video. The Live Video
page is displayed, as shown in figure 4-5.
Figure 4 5 - Live Video
Figure 4 4- Configuring ActiveX control and plug-in
NOTE
4.1 Login
Step 1 Open the Internet Explorer, enter the IP address of IP camera
(default value: 192.168.0.120 in the address box, and press Enter.
The login page is displayed as shown in figure 4-1 .
Step Input the user name and password.2
Ÿ The default user name is admin. The default password is admin. Modify
the password when user logs into the system for first time to ensure
system security.
Ÿ It is advised to restart the device three minutes later after modifying
password to ensure modified successfully
Ÿ You can change the system display language on the login page.
NOTE
Step3 Click Login, the main page is displayed.
4.2 Modify IP address
Choose , the Configuration > Device > Local Network Local
Network page is displayed.
Enter the IP address in the IP Address box and click as shown Apply
in figure 4-2.
After the success of the IP address setting, please use the new IP
address to log in the Web interface.
Figure 4 2 - Local Network
User Name
Password
English
Figure 4 1 - Login
Q
Q
Q
QQu
u
u
uui
i
i
iic
c
c
cck C
k C
k C
k Ck Co
o
o
oon
n
n
nnf
f
f
ffi
i
i
iig
g
g
ggu
u
u
uur
r
r
rra
a
a
aat
t
t
tti
i
i
iio
o
o
oon
n
n
nn(
(
(
((e
e
e
ee.
.
.
..g I
g I
g I
g Ig IE
E
E
EE)
)
)
))43 D
D
D
DDe
e
e
eev
v
v
vvi
i
i
iic
c
c
cce I
e I
e I
e Ie In
n
n
nns
s
s
sst
t
t
tta
a
a
aal
l
l
lll
l
l
lla
a
a
aat
t
t
tti
i
i
iio
o
o
oon
n
n
nn
Local Network
Network Card ID
IP Prot oc ol
DHCP
IP Add r es s
Subnet Mask
Default Gateway
Prefe rr ed D NS Ser ver
Alternate DNS Ser ve r
MTU(1280- 15 00 )
Re fr es h Ap pl y
1
IP v4
19 2 . 16 8. 0. 12 0
25 5 . 25 5. 25 5 . 0
19 2 . 16 8. 0. 1
19 2 . 16 8. 0. 1
19 2 . 16 8. 0. 2
15 00
ht tp :/ /1 92 .1 68 .0 .1 20
Li ve V id eo Pl ay ba ck Pe rs on ne l Co un t Configurat ion
Not e: Activ eX is bei ng used t o play li ve vide o now
Swi tch to VL C, then p lay the v ideo
Swi tch to Pl ugin, t hen pla y the vid eo
St ream
str eam 1
1
2
4.4 Intelligent Analysis
At Configuration Intelligent Analysis interface user can set the " > " ,
parameters of Perimeter Single Virtual Fence Double Virtual Fence , , ,
Multi Loiter Converse and Personnel Count as shown in figure 4 7 , , - .
Figure 4 7 - Intelligent Analysis
Li ve Vi deo Pl ayb ac k Pe rso nnel Co un t Co nfi gu ration
Dev ice Inf o
Str eam
Dev ice
Ext ernal D evice
Int ellig ent Anal ysis
Per imete r
Sin gle Virtua l Fence
Dou ble Virtual Fence s
Mul ti Loit er
Con verse
Per sonne l Count
Ala rm
AI Mu ltiob ject
Dev ice Rec ord
Pri vacy Ma sking
Net work Se rvice
Pri vileg e Manag er
Pro tocol
Dev ice Log
Loc al Conf ig
Mai ntena nce
Pe rim ete r
Ena ble
Sen sitiv ity
Out put Cha nnel
Ala rm Reco rd
SMT P
FTP Uplo ad
Cle ar
Ref resh
App ly
Sun
4.5 AI Multi object
At “Configuration > AI Multi object” interface, user can enable face
detection, full body detection, vehicle detection, set the other
parameters of detection, as shown in figure 4-8.
Face Detection
Fullbo dy Detection
Veh icle Det e ction
Display Tra c e Info
Sh o w De t ection Area
Con fid en c e Coeff icien t
Fa c e Pixel Min(30-300 )
Bo d y Pixel M i n(3 0-300 )
Bo d y Pixel M i n(3 0-300 )
Veh icle P ixe l Mi n (3 0-3 00)
Image Matting Q ual ity
Sn a psh ot Mode
Uploa d Image Interval(1-10 s )
FTP Up l oad Imag e Matting
FTP Up l oad Who le Image
Algor ith m s Library Versio n
Figure 4 8 - AI Multi-object
1 Personnel Count: User can query the data of personnel count,
through year, month, day. The statistics can be downloaded. The
data can be shown by line chart, histogram, list.
2 AI Live video: Click the icon to view the snapshots of human face
or license plate (click “Face” or “Plate” to switch ).
The bottom page will show the captured images of vehicle and
human face.
A
B
Pedestrian direction
15°
If user requires higher
accuracy of personnel count,
we recommend the user to
install camera and draw the
line following as figure 4-6.
Figure 4 6 - Installation of personnel count
CAUTION
NOTE
For better capture performance, it is recommended to use 6mm
focus length lens or above.
Cable out from the top
Plastic anchor
Installation Steps:
Step 1 Open the package, take out the camera, and disassemble
camera’s decorate cover, as shown in figure 3-1.
Step 2 Stick the installation location sticker on the ceiling or wall,
drill three holes following the marks on the sticker. Push
the plastic anchors into he holes, as shown in figure 3-2.
Step 3 Correspond the camera to plastic anchors, fix it to the
ceiling (or wall) by using self-tapping screws.
Step 4 Connected the multi-connector cable, the camera is
connected to screen to adjust monitoring perspective,
then tighten the decorate cover, as shown in figure 3-3.
Figure 3-2 Camera installation
Figure 3 3 - Finish installation
You can route cables from the top or from the side. If you use the
top routing method, drill a hole in the installation surface first, as
shown in figure 3-2, If you use the side routing method, please cut
the compression ring outlet, and route the multi-head cable out
from the side gap at the bottom of the camera.
NOTE
NOTE
The camera's monitoring angle can be adjusted by three-axis
rotation: horizontal rotation, up and down rotation, axial
rotation of the lens, adjust the direction of the camera and
aim the lens at the target.
1 The hemisphere can rotate up and down range of 0 to 80°;
2 the hemisphere can rotate left and right range of 0 to 360° ;
3 The ball lining can rotate 3 60° left and right.
Figure 3-1 Disassemble camera
Self-tapping screws

Produkt Specifikationer

Mærke: Ernitec
Kategori: Overvågningskamera
Model: 0070-08112

Har du brug for hjælp?

Hvis du har brug for hjælp til Ernitec 0070-08112 stil et spørgsmål nedenfor, og andre brugere vil svare dig


Overvågningskamera Ernitec Manualer

Ernitec

Ernitec 0070-08117 Manual

2 September 2024
Ernitec

Ernitec Wolf Pro Manual

1 September 2024
Ernitec

Ernitec 0070-08112 Manual

22 August 2024
Ernitec

Ernitec 0070-08214 Manual

22 August 2024
Ernitec

Ernitec 0070-08215 Manual

22 August 2024
Ernitec

Ernitec 0070-08316 Manual

22 August 2024
Ernitec

Ernitec Orion DX 832 IR Manual

21 August 2024
Ernitec

Ernitec TAURUS DX 622 Manual

21 August 2024
Ernitec

Ernitec 0070-04344IR Manual

20 August 2024
Ernitec

Ernitec ORION DX 822IR Manual

19 August 2024

Overvågningskamera Manualer

Nyeste Overvågningskamera Manualer

Panasonic

Panasonic AW-UE20 Manual

17 September 2025
InLine

InLine 40162 Manual

17 September 2025
Dahua Technology

Dahua Technology N45EYN2 Manual

15 September 2025
Ipevo

Ipevo VC-Z4K Manual

15 September 2025
TP-Link

TP-Link Tapo C425 Manual

15 September 2025
Dahua Technology

Dahua Technology 1A404DBNR Manual

15 September 2025
AMX

AMX NMX-NVR-N6123 Manual

14 September 2025
Hanwha

Hanwha QNE-7080RV Manual

14 September 2025
Hikvision

Hikvision DS-2CD4125FWD-IZ Manual

14 September 2025
Intellinet

Intellinet 524421 Manual

13 September 2025
