Thank you for purchasing the Lasergrip 1080 Infrared Thermometer by

Etekcity. This easy-to-use device lets you conveniently and accurately

measure surface temperatures from a distance without the need of any

direct contact. Should you have any questions or concerns, feel free to

contact our helpful customer support team toll-free at 855.686.3835 or

by email at support@etekcity.com.

NOTE: The Lasergrip cannot measure the temperature of objects behind

glass. Inaccuracy may also occur when exposed to steam, dust or any

other contaminants in the air.

NOTE: The Lasergrip LCD will display ‘OH’ when the measured

temperature is above the measurable range, and will display ‘OL’ when the

measured temperature is below the measurable range.

NOTE: The Lasergrip cannot measure the

temperature of objects behind glass. Inaccuracy

may also occur when exposed to steam, dust or

any other contaminants in the air.

WARNING: THIS DEVICE PRODUCES LASER RADIATION. USE CLASS 2

EXTREME CAUTION AT ALL TIMES WHEN LASER IS IN USE. DO NOT

LOOK INTO DIRECT OR REFLECTED LASER-LIGHT BEAM OR VIEW BEAM

WITH OPTICAL INSTRUMENTS. DO NOT AIM LASER-LIGHT AT ANOTHER

PERSON OR ANIMAL. LASER RADIATION MAY DAMAGE YOUR EYE. DO

NOT DISASSEMBLE THE DEVICE.

IMPORTANT: Read all of the instructions in this manual.

Failure to comply with the instructions in this manual or use

of the device, in ways other than the ones mentioned in this

manual, may result in hazardous radiation exposure.

Safety Use & Care

Features

Specications

Operation

Function Diagram

• DO NOT point the laser-light at another person or animal.

• DO NOT attempt to point laser-light at an aircraft.

• Avoid direct/indirect eye contact with the laser-beam. Laser radiation

may cause eye damage.

• DO NOT view the beam with optical instruments.

• In the vicinity of use, make any bystanders aware of the dangers of

looking directly into the laser beam.

• DO NOT allow children to operate the device.

• Use a 9V battery when replacing the battery within the device. Make

sure to insert the battery in accordance with the correct polarities.

• ALWAYS remove the batteries when cleaning the device.

• DO NOT use leaking batteries or dispose old batteries in fire.

• Remove battery for storage if the device is not being used for a

prolonged period of time.

• DO NOT disassemble the device or tamper with internal components.

Doing so will void any warranty.

• DO NOT touch the lens or wipe it using anything other than a soft

cloth or cotton swab.

• Laser guided targeting for aiming precision

• Narrow distance-spot ratio for accurate results at greater distances

• Safely measure hazardous or inaccessible objects

• Standard 9V battery powers up to 12 hours of cumulative use

• Auto-off after 15 seconds of inactivity

Measurement Range: -58°F ~ 1022°F (-50°C ~ 550°C)

Accuracy: ±2% / ±2°C

Resolution: 0.1°F / °C

Maximum Output: < 1 mW

Wavelength: 630 - 670 nm

Distance-Spot Ratio: 12:1

Response Time: < 500 ms

Emissivity (Adjustable): 0.1-1.0

Battery: DC 9V

1. LCD Display

2. Unit(°C/°F)/DOWN

3. Emissivity Adjustment Mode

4. UP/Laser Pointer/Backlight

5. Measurement Trigger

6. Battery Compartment

7. Laser Hole

8. IR Sensor

1. Low Battery

2. Laser On

3. Back-light On

4. Continue Scanning

5. °C / °F

6. Temperature Result

7. Max Temperature /

Emissivity Result

8. Max Temperature Sign

9. Adjustable Emissivity Sign

1. Once the battery is properly installed, press the measurement trigger

to activate the device.

2. Point the Lasergrip towards the surface of measurement.

3. Press and hold the measurement trigger and the laser will activate for

aiming guidance.

4. Keep holding the trigger as you move the Lasergrip if you wish to live

scan the surface area for temperature measurement.

5. Once the laser is pointed to the desired point of measurement, release

the trigger and the LCD display will lock the calculated temperature.

6. Press the measurement trigger once again to make another

measurement.

• Keep the thermometer away from electromagnetic fields produced by

objects such as arc welders and induction heaters.

• DO NOT expose the thermometer to direct sources of heat for

extended periods of time.

• The thermometer measures surface temperature, not internal

temperature. Do not use the Lasergrip as a reliable source to measure

body temperatures.

Surface Temperature Measurement

HOLD for continuous

temperature reading

RELEASE to lock the

temperature result

To switch between units of temperature

measurement, press the °C/°F button at any

time while the Lasergrip is on.

To activate and deactivate the laser, press the

laser pointer On/Off button at any time while the

Lasergrip is on.

To activate and deactivate the display backlight,

press and hold measurement trigger and then

press the display backlight On/Off button at the

same time.

To adjust the emissivity value before

measurement, press the emissivity adjustment

mode button, then use the UP and DOWM

buttons to navigate to the desired value. You

may refer to the emissivity reference chart for

correct surface emissivity values. To transfer

into Max Temperature Mode, press the mode

button again.

Unit Conversion

Laser Activation

Display Backlight Operation

Emissivity Adjustment & Max Temperature

Display Icon Key

Package Contents

1 x Etekcity Lasergrip 1080 Infrared Thermometer

1 x 9V DC Battery

1 x User Manual

Infrared Thermometer

Model No.:

Lasergrip 1080

Questions or Concerns?

support@etekcity.com • (855)-686-3835

The emissivity of a material is its efficiency in emitting thermal energy.

Non-reflective surfaces have a higher emissivity (closer to 1) than

reflective surfaces (closer to 0). Inaccurate results may occur when

measuring reflective surfaces such as glass, polished wood, and granite.

The device certification information is

labeled directly on the device. The sticker is

located on the left side of the Lasergrip.

To take accurate temperature measurement of reflective surfaces with

low emissivity, adjust the emissivity value before measurement using the

reference chart. Or, place a strip of masking tape over the surface and

allow for it to adjust to the temperature of the surface for approximately

30 minutes. Measure the surface, scanning the taped section, eliminating

the issue of inaccuracy.

The Lasergrip 1080 measures surface temperature on the basis of

distance to spot diameter ratio (D:S). As the distance between the

thermometer and the surface increases, the total surface area measured

will also increase. With a distance to spot ratio of 12:1 the surface area

measured has a diameter of roughly 1/12 the distance.

For the most accurate results, make sure the target has a surface area

of twice the corresponding spot diameter. Insufficient surface area will

result in inaccurate results. The recommended distance to hold the

Lasergrip from the surface of measurement is 14.17 in (36 cm). This

creates a spot measurement area of 1.18 inches (3 cm) in diameter.

This device complies with Part 15 of the FCC Rules. Operation is subject

to the following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including

interference that may cause undesired operation.

NOTE: This equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on,

the user is encouraged to try to correct the interference by one or more of

the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

FCC Caution: Any changes or modifications not expressly approved by

the party responsible for compliance could void the user’s authority to

operate this equipment.

Federal Communication Commission

Interference Statement

Emissivity

Emissivity Of MaterialsDistance-Spot Ratio

The device warning and aperture safety

information are also labeled directly on the

device; the sticker is located on the right side

of the Lasergrip.

Any updates to the product information

(date of manufacturing and manufacturer

address) will be added as adhesive overlays.

A3_22D06_us

Warranty Information

Customer Support

Scan Here to Receive Exclusive News:

Your product comes with 2 years of warranty,

starting from the date of purchase.

1. Scan the QR code or visit etekcity.com/warranty.

2. Enter your purchase info to receive

exclusive news.

3. Learn about our quality customer support

and gain easy access to warranty

information.

*Please have your invoice and order ID ready before contacting

Customer Support.

Etekcity Corporation

1202 N. Miller St., Suite A

Anaheim, CA 92806

Support Hours

Mon–Fri,

9:00 am–5:00 pm PST/PDT

Email: support@etekcity.com

Toll-Free: (855) 686-3835

If you encounter any issues or have any questions about your new

product, please contact our helpful Customer Support Team.

FCC SDOC SUPPLIER’S DECLARATION OF

CONFORMITY

Etekcity Corporation hereby declares that this equipment is in

compliance with the FCC Part 15 Subpart B. The declaration

of conformity may be consulted in the support section of our

website, accessible from www.etekcity.com

A new pre-installed 9V battery comes in protective plastic wrap inside

your Lasergrip. Follow the steps below to properly install or replace the

battery.

1. Open the battery cover. For first-time use, take the battery out and

remove the plastic wrapper. [Figure 1.1]

2. Securely connect the battery to the battery terminals, making sure the

leads and terminals are connected correctly. [Figure 1.2]

3. Reinsert the battery back into the compartment.

4. Close the battery cover, making sure that the wires are tucked inside the

battery compartment. [Figure 1.3 ]

Battery Installation & Replacement

NOTE:

• The low battery indicator will appear on the display when the power is running

low. Immediately replace the battery when the icon appears.

• Remove the battery before storing if the Lasergrip is not being used for a long

time.

[Figure 1.1]

9V Battery

[Figure 1.2]

[Figure 1.3]

PAIR

Material Feature Material Feature EmissivityEmissivity

Aluminium

Oxidized 0.3

Human

Skin

0.98

Polished 0.02-0.04 Graphite Oxidized 0.20-0.60

Brass

Oxidized 0.5 Plastic

Non-

transparent

0.95

Polished 0.02-0.05 Rubber 0.95

Gold 0.01-0.10

Plastic

Cement

0.85-0.95

Iron Oxidized 0.7 Concrete 0.95

Steel Oxidized 0.70-0.90 Cement 0.96

Asbestos 0.95 Soil 0.90-0.98

Plaster 0.80-0.90 Mortar 0.89-0.91

Asphalt 0.95 Brick 0.90-0.96

Rock 0.7 Marble 0.94

Wood 0.90-0.95 Textile 0.90

Charcoal Powered 0.96 Paper 0.95

Carbon 0.85 Sand 0.90

Lacquerwork Lackluster 0.97 Clay 0.92-0.96

Carbon

Cement

0.90 Sand 0.9

Soap

Bubble

0.75-0.80 Glass 0.85-0.92

Water 0.93 Textile 0.95

Snow 0.83-0.90

Heated

Food

0.95

Ice 0.96-0.98 Plastic 0.95

Frozen

Foods

0.95 Oil 0.94

Ceramics 0.95

Steel and

iron

0.80

Limestone 0.98 Wool Natural 0.94

Paint 0.93 Lead Oxidized 0.5

Distance (D) to Spot (S) size D:S = 12:1

recommended

14.17 in

11.81 in

0.98 in

1.18 in

Produkt Specifikationer

Mærke:	Etekcity
Kategori:	Termometer
Model:	Lasergrip 1080

Har du brug for hjælp?

Hvis du har brug for hjælp til Etekcity Lasergrip 1080 stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Termometer Etekcity Manualer

Etekcity Lasergrip 1080 Manual

28 December 2024

Etekcity Lasergrip 1022D Manual

17 August 2024

Etekcity Lasergrip 774 Manual

17 August 2024

Termometer Manualer

Nyeste Termometer Manualer

Scala SC 312 Manual

30 September 2025

ClimeMET CM2011 Manual

29 September 2025

Inkbird INT-11X-B Manual

28 September 2025

Inkbird IDT-34c-B Manual

28 September 2025

Inkbird INT-12E Manual

28 September 2025

Neno Medic T07 Manual

25 September 2025

BBQ Premium GT-TMBBQ-04s Manual

18 September 2025

Brandson 306118 Manual

15 September 2025

TFA 30.3072.01.90 Manual

12 September 2025

Berdsen BD-101 Manual

9 September 2025
