EL2242-BT

7/15/2021

EL2242-BT Hardened PoE Media Converter

Installation Guide

1 Unpacking

Unpack the items. Your package should include:

➢ One EL2242-BT PoE Media Converter

➢ Power input terminal block

➢ Wall and DIN-Rail mounting hardware

brackets

If items are missing or damaged, notify your

EtherWAN representative. Keep the carton and

packing material.

More information available at:

https://www.etherwan.com/us

For warranty information, visit:

https://www.etherwan.com/us/support/warrant

y-policy

2 Equipment Needed

➢ Category 5e or better cable for RJ-45 port

➢ SFP Module

➢ Single Mode/Multimode Fiber Cable

➢ Power supply with supplied voltage within

specified range of 52 to 56VDC

3 Select a Location

➢ DIN-rail installations: Attach the bracket on

the unit using the included screws and then

mount on a DIN-rail.

➢ Wall installations: Attach the brackets on the

unit using the included screws and then

mount on a wall.

➢ Identify a power source within 6 feet (1.8

meters).

➢ Choose a dry area with ambient temperature

between -40 and 75ºC (-40 and 167ºF).

➢ Keep away from heat sources, sunlight, warm

air exhausts, hot-air vents, and heaters.

➢ Make sure there is adequate airflow.

4 Connect to the Ports

The EL2242-BT has the following ports:

➢ 1 10/100/1000 Mbps copper port

➢ 1 dedicated 100/1000 SFP slot

10/100/1000BASE-T Port

Port can be connected to a switch, a router or a

PoE device (PD).

SFP Slot

100/1000BASE SFP slot.

5 Connect Power

Terminal Block

Connect the unit to a suitable power supply using

appropriate wire, 18-24AWG, rated for 105°C or

higher.

Redundant power is supported. However, only

one power input is required to operate the unit.

1. Connect power wires to the appropriate

V1+/- or V2+/- pins on the terminal

block.

2. Connect the grounding wire to the ground

screw.

3. Plug the terminal block into the socket.

6 Front Panel LEDs

LED Panel Layout

LED

Color

Status

Power

1 & 2

Green

ON = power detected

OFF = power not detected

PoE

Amber

ON = PD is detected

Off = No PD detected

RJ-45

Link/Act

Green

ON – TX port is detected

FLASHING – TX data is

transmitting

SFP

Link/Act

Green

ON – FX port is detected

FLASHING – FX data is

transmitting/receiving
