INJ90BT-24

1/6/2020

INJ90BT-24 Hardened PoE Injector

Installation Guide

1 Unpacking

Unpack the items. Your package should

include:

 One INJ90BT-24 PoE Injector

 Power input terminal block

 Wall and DIN-Rail mounting hardware

brackets

If items are missing or damaged, notify your

EtherWAN representative. Keep the carton

and packing material.

More information available at:

https://www.etherwan.com/us

For warranty information, visit:

https://www.etherwan.com/us/support/war

ranty-policy

2 Equipment Needed

 Category 5e or better cable for RJ-45

ports

 Power supply with supplied voltage within

specified range of 24 to 56VDC

3 Select a Location

 DIN-rail installations: Attach the bracket

on the unit using the included screws and

then mount on a DIN-rail.

 Wall installations: Attach the brackets on

the unit using the included screws and

then mount on a wall.

 Identify a power source within 6 feet (1.8

meters).

 Choose a dry area with ambient

temperature between -40 and 75ºC (-40

and 167ºF).

 Keep away from heat sources, sunlight,

warm air exhausts, hot-air vents, and

heaters.

 Make sure there is adequate airflow.

4 Connect to the Ports

The INJ90BT-24 has the following ports:

 2 10/100/1000 Mbps copper ports

10/100/1000BASE-T Ports

Port labeled “Data” can be connected to a

switch or a router. Port labeled “Power” can

be connected to a PoE device (PD).

5 Connect Power

Terminal Block

Connect the unit to a suitable power supply

using appropriate wire, 18-24AWG, rated for

105°C or higher.

Redundant power is supported. However,

only one power input is required to operate

the unit.

1. Connect power wires to the

appropriate V1+/- or V2+/- pins on

the terminal block.

2. Connect the grounding wire to the

ground screw.

3. Plug the terminal block into the

socket.

6 Front Panel LEDs

LED Panel Layout

LED Color Status

Power

1 & 2

Green ON = power detected

OFF = power not detected

PoE Amber ON = PD is detected

Off = No PD detected
