Component List:

1 Tent Body, 4 Long Poles 2 Side Poles, 1 Tent Fly,

1 Carry Bag, 1 Stake Bag and Stakes, 1 Pole Bag

ASSEMBLY: It is difficult to assemble this tent alone. It is a large

tent and we recommend that you have help.

1. Remove from the carry bag and separate all the components.

Unroll and unfold the fabric, top side up, on a clean, dry space

and open the doors. If windy, stake down the windward corner.

Remove the protective cover from the center hub.

2. Assemble the shockcorded poles and divide according to size

and shape. Take care; make sure that each pole section is fully

seated into the next. Do not allow the sections to snap together

as this can damage the ends.

3. so that the two arms, with the most downward Orient the hub

taper, point to the sides of the tent. Take care; make sure that the

fabric is not twisted.

Important: If the hub arms point in the wrong direction, the hub

could break under the stress of assembly.

4. facing , into the reinforced end of a long Slide the hub arm, A

pole. See fig.1. Disconnect the last section at the bottom end of

this pole. Insert a pin from the tent’s floor, into the end of the

second section. See fig. 2. & fig. 3.

7. from the side of the tent at . Slide a side pole onto the hub arm E

Clip the top two tent clips onto the frame. Disconnect the bottom

section and insert the pin into the end of the second section.

Repeat with the last pole on the opposite side at .F

8. Grasp the pole where it’s connected to the ring Raise the tent.

and pin, lift the corner off the ground and remove the pin.

Reconnect the last section and reinsert the pin. Repeat with

remaining poles until the tent is at full height and freestanding.

9. to the poles and attach the corner shockcords to Attach all clips

the J-hooks at the elbow of each corner pole. See fig. 6.

STORM CURTAINS: Storm Curtains zip into the fly to offer full weather

protection. Detach the buckles at the corners of the tent. Take the curtain

that corresponds with the opening to be covered. The curtains are made

in pairs: Front side right, front side left. Rear side right, rear side left. The

front and back curtains are identical and can be used in either location.

Zip the curtain into place and reconnect the buckles.

STORM RINGS: The tent is equipped with storm rings on the fly. In windy

conditions, use 1/8” to 1/4 x 12’ guylines and these rings to anchor the

tent down.

TAKE DOWN: Pull up stakes. Release the fly's hook & loop straps and

buckles. Remove ﬂy. Remove clips from poles and pull poles off of the

pins. Collapse the tent poles and stow. Fold the tent onto itself then fold

the fly and lay it on tent. Roll up both towards the door and stow.

AVAILABLE OPTIONS: Floor Saver, Gear Loft

5. from the tent’s roof to Attach the top two clips

this pole. See fig.4.

6. that Slide a second long pole onto the hub arm

points to . Disconnect the last section of this pole B

and insert the pin into the bottom of the remaining

section. Attach two top clips, from the roof, to this

pole. Repeat at and partially raising the tent C D,

as you work. See fig. 5.

11. Attach the ﬂy. ,With top side up on

ground at the front of the tent, arrange the fly into the same

rectangle as the tent.

NOTE: The fly is not symmetrical; it only fits one way.

Make sure the green web buckle on the fly matches up

with the green web buckle on the tent and that the tan web

buckle matches with the tan on the tent.

Grasp the corners of the narrow end of the fly and drag them

up and over the poles to completely cover the roof. ( This is

much easier with two people. ) The skylight window in the fly

should align with the zippered vent in the sleeping section of

the tent.

At the corners, reach under the fly and attach the hook & loop

straps to the tent poles securing the fly in place.

Fasten the side release buckles and adjust tension until the

wrinkles are gone. See fig. 8.

REV E 4.09

ASSEMBLY INSTRUCTIONS

FOR THE CONDO TENT:

YOUR TENT IS READY !

fig 2

fig 3

fig 1

fig. 5

fig. 6

fig. 8

fig. 7

fig. 4

10. Drive stakes to capture Stake the tent down.

the rings at the base of each pole. See fig. 7. Stake

one corner, pull the fabric taut, dressing out the

ﬂoor as you work your way around the tent.
