Side 1/1
INSTALLATION INSTRUCTIONS
© Panduit Corp. 2013
For Instructions in Local Languages
and Technical Support:
www.panduit.com/resources/install_maintain.asp
Page 1 of 1
www.panduit.com
PN547B
E-mail:
Phone:
866-405-6654
MP528 Specifications
Cable jacket diameter 0.140 - 0.160 in.
28 AWG stranded or solid conductor
maximum insulated diameter 0.024 in.
Panduit recommends T568B wiring
scheme for use with cable constructed
with the brown pair opposing the
orange pair.
Category 5e 28-30 AWG Modular Plug
Part Numbers: MP528, MP530
8
7
6
5 4
3
2
1
2
2.0"
1
(not to scale)
T568B BRN
8
WHT
7
BRN/
6
GRN
WHT
5
BLU/
4
BLU
WHT
3
GRN/
2
ORG
WHT
1
ORG/
Pin #
T568A BRN
WHT
BRN/
ORG
WHT
BLU/
BLU
WHT
ORG/
GRN
WHT
GRN/
3
4
Orient cable
manager as
shown
8
1
5
6
7
Trim
conductors
flush
8
SGPT
Click
9
MPT5-8AS
Panduit recommends using MPT5-8AS
tool for use with Category 5e 28/30
AWG Plug termination.
Wiring Sequence
MP530 Specifications
Cable jacket diameter 0.122 - 0.130 in.
30 AWG stranded maximum insulated
diameter 0.021 in.
Panduit recommends T568B wiring
scheme for use with cable constructed
with the brown pair opposing the
orange pair.
Gauge
Identification
(tinted)
Gauge
Identification
(clear)
