Module Removal Guide
68-3031-50 Rev. A
08 16
© 2016 Extron Electronics. All rights reserved.
www.extron.com
Remove the
module.
ExtronExtron
3
Locking
Tabs (2)
Extron
Extron
ExtronExtron
Insert pry tool
to line.
12
Pry Tool
Pull the pry tool to the
left to unhook each
locking tab from the
mounting bracket.
VOLUME
DISPLAY
OFF
ON
PC
Locking
Tab (1)
For modules with one locking tab,
unhook the tab located at the center.
ExtronExtron
NOTE: Some modules are
difcult to remove once installed.
Make sure the wiring is correct
before snapping in each module.
