Side 1/28

OWNER’S MANUAL | MANUAL DE INSTRUCCIONES

MODE D’EMPLOI | MANUAL DO PROPRIETÁRIO

MANUALE UTENTE | BEDIENUNGSHANDBUCH

INSTRUKCJA OBSŁUGI | NÁVOD K POUŽITÍ

NÁVOD NA POUŽITIE | UPORABNIŠKI PRIROČNIK

オーナーズ・マニュアル

用户手册

A. INPUT: Combination instrument/microphone inputs

for channels one and two.

B. VOLUME: Volume level controls for channels one and

two.

C. BASS: Low-frequency tone controls for channels one

and two.

D. MIDDLE: Mid-frequency tone controls for channels

one and two.

E. TREBLE: High-frequency tone controls for channels

one and two.

F. REVERB: Reverb level controls for channels one and

two.

G. AUX/PHONES: /” auxiliary input above for use with

external devices (use external device’s volume control

to adjust its volume level); /” headphone output

below for both channels automatically mutes speaker

output.

H. POWER INDICATOR: Illuminates when the

Acoustasonic  is on.

I. POWER SWITCH: Turns the Acoustasonic  on and off.

J. IEC POWER INLET: On the rear panel (see illustra-

tion at right), attach the included power cord here.

Connect to a grounded outlet in accordance with

the input power voltage and frequency specified just

below the power inlet.

K. BALANCED LINE OUT: On the rear panel (see illustra-

tion at right), this XLR output sends a balanced signal

to external recording and sound reinforcement equip-

ment.

ENGLISH

The Acoustasonic 40 amplifier offers portable amplification for acoustic-electric guitar and

microphone. It’s a simple, flexible “grab and go” 40-watt amp ideal for a variety of musical per-

formance and basic public address applications, and it can also be used as an onstage monitor

when combined with a PA system.

Acoustasonic™ 40

INPUT

CHANNEL 2

INPUT VOLUME BASS MIDDLE TREBLE REVERB

CHANNEL 1

EQUALIZER

For questions and troubleshooting,

contact a Fender specialist at:

1-800-856-9801 (U.S. toll free)

1-480-596-7195 (International)

Produkt Specifikationer

Mærke:	Fender
Kategori:	Modtager
Model:	Acoustasonic 40
Tænd-/slukkontakt:	Ja
Vekselstrømsindgangsspænding:	230 V
Bredde:	380 mm
Højde:	279 mm
Vægt:	7500 g
Produktfarve:	Black, Brown
Antal højttalere:	2
Udgangseffekt (RMS):	40 W
Impedens:	8 ohm (Ω)
Forbindelsesteknologi:	Ledningsført
Lyd-output kanaler:	2.0 kanaler
Strømkilde type:	Vekselstrøm
Bærehåndtag:	Ja
Tilslutning af hovedtelefoner:	3,5 mm
AC (strøm) indgang:	Ja
XLR udgående:	1
XLR indgang:	Ja
