EXPLODED VIEW
FERM FBF-8E PLUNGE ROUTER
USERS MANUAL
TECHNICAL SPECIFICATIONS
PACKAGE CONTENTS
The package contains:
1 Router
1 Parallel guide – unassembled
1 Guide bush
2 Screws
2 Nuts
1 8mm collet
1 6mm collet
1 Collet
1 Cutter
1 dust extractor adaptor
1 Spanner
1 Instruction Manual
1 Guarantee card"
Check the machine, loose parts and accessories for
transport damage.
PRODUCT INFORMATION
1 On/off switch
2 Handle
3 Router base
4 Locking bolt for parallel guide
5 Opening for parallel guide
6 Collet nut
7 Spindle lock
8 Revolver-depth stop
9 Locking bolt depth stop
10 Depth stop
11 Clamping lever
12 Scale cutting depth
13 Adjusting wheel electronic speed control
SAFETY INSTRUCTIONS
The following symbols are used throughout this manual:
Denotes risk of personal injury, loss of life or
damage to the tool in case of non-observance of the
instructions in this manual.
Denotes risk of electric shock.
Carefully read this manual before using the machine.
Make sure that you know how the machine functions and
how to operate it. Maintain the machine in accordance
with the instructions to make sure it functions properly.
Keep this manual and the enclosed documentation with
the machine.
Ferm products are manufactured to high quality stan-
dards, they are safe and fit for purpose at time of sale, but
all tools can be dangerous if the correct precautions are
not taken. Always follow these instructions, do not carry
out the operation until you are sure you can do so in saf-
ety. Remember to consider the work environment for
safe operation as well as safety for tool use.
Warning! When using electric tools, basic safety
precautions should always be followed to reduce
the risk of fire, electric shock and personal injury. Read all
these instructions before attempting to operate this product.
Save these instructions for future reference.
Voltage | 230 V~
Frequency | 50 Hz
Power input | 850 W
No load speed | min-1
| 9000–28000
Max. cutter diameter | 30 mm
Cutting depth | 35 mm
Collet | 8 mm
Weight | 3.2 kg
Lpa (sound pressure) | 83 dB(A)
Lwa (sound power) | 96 dB(A)
Vibration value | <3.3 m/s2
