Side 1/16
www.ferm.com
© 2011 Ferm B.V. 1103-29
EN
Original instructions
02
DE
Übersetzung der
Originalbetriebsanleitung
04
NL
Vertaling van de oorspronkelijke
gebruiksaanwijzing
06
FR
Traduction de la notice originale
08
ES
Traducción del manual original
11
TILE CUTTER
TCM1012
EN
2
TILE CUTTER
Thank you for buying this Ferm product.
By doing so you now have an excellent product,
delivered by one of Europeís leading suppliers.
All products delivered to you by Ferm are
manufactured according to the highest standards
of performance and safety. As part of our
philosophy we also provide an excellent customer
service, backed by our comprehensive Warranty.
We hope you will enjoy using this product for
many years to come.
Read the operating instructions
carefully before using this device.
Familiarize yourself with its functions
and basic operation. Service the device
as per the instructions to ensure that it
always functions properly. The
operating instructions and the
accompanying documentation must be
kept in the vicinity of the device.
Contents
1. Technical specifications
2. Safety instructions
3. Assembly
4. Use
5. Maintenance
1. Technical specifications
max. 10 mm
max. 400 mm
30-80 mm
0-45°
2. Special safety instructions
1. The tile cutting machine is fitted with a
replaceable circular blade. Therefore, keep
children away.
2. After use the machine must be stored in a
safe and dry place, away from children.
3. This machine has been designed for cutting
and breaking glazed tiles, and must not be
used for any other purpose.
4. When using the tile cutting machine make
sure to keep extension leads and such away
from the machine.
5. Always place the tile cutting machine on a
level and firm surface.
6. CAUTION! The edges of cut tiles are sharp.
3. Assembly
Assemble the tile cutting machine as shown in the
drawing.
Assembly of the tile cutting machine
Remove all the parts from the box and assemble
the tile cutting machine as follows:
1. Slide the black rubber feet (T) over the
corners of the tile cutter. Slide a washer onto
the bolt and push this into the rubber foot.
Now slide a washer and a nut over the bolt on
the back and fasten this properly. Repeat this
for the other three corners.
2. Mount the fastening blocks (N) with the 2
tubes (M) onto the bottom plate (V) using the
4 bolts (O) and washers (P).
3. Screw the lever (H) onto the tube fastening (I).
4. Finally, mount the sash angle (U) onto the
bottom plate (V) using the knob (S) and
washer.
Assembly of the hollow square chisel
1. Place the hollow square chisel above the hole
in the bottom plate (V).
2. Make sure that the clamping plate (E) comes
under the 2 tubes and fasten this using the
socket head wrench supplied. The socket
head wrench is situated in the black fastening
plate (C).
3. It is important that the drill (G) and the knife
(F) are adjusted in such a way that they just
touch the bottom plate (V). This adjustment
can be done using the two nuts at the top of
the hollow square chisel. Then fasten these
nuts against each other.
3. How to cut and break tiles
1. Use a soft-tipped (carpenter’s) pencil to mark
off the cutting line.
2. Place the tile against the stop, the glazed
side facing upward. The pencil mark must be
