FWS-125/3K
47
STATEMENT OF CONFORMITY
VERSION 0409-13.1
Ferm BV
P.O. Box 30159
8003 CD Zwolle
Nederland
www.ferm.com
FWS-125/3K
2
XXXX
Congratulations!
With the purchase of this high quality Ferm tool,you have
made an excellent choice.Ferm products are rugged,safe
and easy to use.
It is very important to exercise care when handling and ser-
vicing this tool. Please read these instructions thoroughly,
and be sure to follow the directions given.You will then enjoy
many years of service from your Ferm tool.
Safety Instructions
In these instructions for use,the following symbols are
used:
Caution:risk of bodily harm,fatality or dama-
ge to the machine,from failure to follow the
directions in these instructions for use.
Caution:electrical current.
The machine is double insulated compliant
with EN50144;therefore no earth connecti-
on is required.
Visual check before starting to work
Faulty and/or discarded electrical or elec-
tronic apparatus have to be collected at the
appropriate recycling locations.
Product information
Package contents
• Electric wall chaser
• Handgrip
• Diamond cutting discs (2 x)
• Cam wrench
• Hex key
• Cold chisel
• Dust extraction adapter
• Set carbon brushes
• Instructions for use
• Guarantee card
Specifications
Voltage 230 V~
Frequency 50 Hz
Power rating 1300 W
Rotational speed (not loaded)
9000/min
Max.cutting depth 8-30 mm
Max.channel width 8-26 mm
Weight 4,2 kg
Cutting disc (2x) Ø125 x 22,2 x 2,0
Lpa (Sound pressure level) 90,9 dB(A)
Lwa (Sound power level) 103,9 dB(A)
Vibration level 0,9 m/s
2
GENERAL
1. On/off trigger switch
2. Attachment point
for handgrip
3. Connection for
mechanical dust
extraction
4. Guide wheel
5. Distance washers
6. Spindle nut
7. Cutting depth fixing
knob
8. Cutting direction
9. Shaft lock
