Side 1/6

PN 686953

March 1998 Rev.1, 9/01

T5-600/T5-1000

Electrical Tester

Service Information

Introduction

This service information sheet provides the following information for the T5-600 and T5-1000 Electrical

Testers (hereafter referred to as "the tester").

• Safety information

• Parts and service information

• Specifications

• Cleaning procedure

• Required equipment

• Performance tests

• Parts and accessories list

• Battery replacement procedure

For operating instructions, refer to the T5-600/T5-1000 Electrical Tester Instruction Sheet.

Safety Information

Warning

To avoid possible electric shock or personal injury, follow these guidelines:

• Do not use the tester if it is damaged or operating abnormally. Protection

may be impaired.

• Before each use:

• Make sure the battery door is closed and latched.

• Inspect the tester and test leads. Look for cracks, missing plastic, exposed

metal, or damaged insulation. Replace damaged test leads before using the

tester.

• Verify the tester’s operation by measuring a known voltage.

• Replace the batteries as soon as the low battery indicator (M) appears.

• Do not use the tester around explosive gas, vapor or dust.

• Do not apply more than the rated voltage, as marked on the tester, between

terminals or between any terminal and earth ground.

• Refer servicing to qualified personnel.

• Use caution when working above 30 V ac rms, 42 V ac peak, or 60 V dc.

• When using the probes, keep your fingers behind the finger guards on the

probes.

• Connect the common test lead before you connect the live test lead.

Disconnect the live test lead first.

• The display will not display hazardous voltages in display hold. The voltage

indicator LED ( ) continues to operate.

Service Information

Serial Numbers 79559999 and Below

General Specifications (continued)

RF Field Specification 0.5 % full scale + (specified accuracy) at 3 V/m

Safety Complies with ANSI/ISA-S82.01-94, UL Classified to IEC 61010, CSA/CAN C22.2 No.1010.1-

92, and EN61010-1 1995.

EMC EN 61326

Certifications In accordance with IEC 61010-1 54CJ

Resolution and Accuracy

Function T5-600 Range T5-1000 Range Resolution Accuracy

K600 V rms 1000 V rms 1 V ±(1.5 % + 2 digits)

L600 V 1000 V 1 V ±(1 % + 1 digit)

?100.0 A 100.0 A 0.1 A ±(3 % + 3 digits)

e1000 1000 1 Ω Ω Ω ±(1 % + 2 digits)

Input Characteristics

Input Protection

Function T5-600 T5-1000

Input impedance (nomial

K600 V rms 1000 V rms 1 MΩ, <100 pF ac-coupled

L600 V rms 1000 V rms 1 MΩ, <100 pF

e600 V rms 1000 V rms

Open Circuit Test Voltage Short Circuit Current

e1.65 V dc (nominal) <600 µA

CAT III protects against transients in a fixed equipment installation such as a distribution panel, and lighting systems in

large buildings.

CAT IV protects against transients from a primary supply such as an electricity meter or an overhead or underground utility

service.

Serial Numbers 79559999 and Below

General Specifications

Calibration One-year calibration cycle.

Maximum Voltage

Between any Terminal

and Earth Ground

T5-600: 600 V rms, Overvoltage Category III

T5-1000: 1000 V rms, Overvoltage Category III

Temperature Operating: -10 ° ° ° ° ° ° ° °C to +50 C (14 F to 122 F); Storage: -30 C to +60 C (-22 F to +140 F)

Altitude Operating: 2000 m (6562 ft); Storage: 10,000 m (32808 ft)

Relative Humidity 0 % to 95 %, 5 ° °C to 30 C (41 C (86 °F to 86°F); 0 % to 75 %, 30 ° °C to 40 °F to 104 °F);

0 % to 45 %, 40 ° °C to 50 C (104 °F to 122 °F)

Battery Type and Life AA (2); 400 hours continuous with alkaline; 200 hours continuous with zinc chloride

Produkt Specifikationer

Mærke:	Fluke
Kategori:	Termometer
Model:	T5-600
Vægt:	300 g
Batterispænding:	1.5 V
Produkttype:	Digitalt multimeter
Skærm:	LCD
Dimensioner (BxDxH):	30.5 x 51 x 203 mm
Vandfast:	Ja
Støv-modstand:	Ja
DC spændingsområde:	0 - 600 V
AC-spæningsområde:	0 - 600 V
AC strømområde:	0 - 100 A
Modstandsområde:	0 - 1000 ohm (Ω)
