The channel 3 (CH3) input is on balanced twin 3 pole jacks, this input goes only to the ¼”
master via its volume control, the CH 3 input is given 6dB of gain.
When CH3 volume control is in middle position attenuates by 6dB so with CH3 volume
control in middle position the level sent to the master is the same as the level at the input, if a
higher signal is required the CH3 volume control only needs to be adjusted above mid.
Channel 3 has 2 bi- t is colour LED’s to indicate CH3 input level, left is Green/Yellow and righ
Yellow/Red.
When left green ashes slowly it indicates a signal of about -20dB and at -7dB it comes fully
on. When left yellow ashes it indicates a signal of -3dB and at +1dB it comes fully on.
When right yellow comes on it indicates +4dB and when right red comes on it indicates
+12dB or clip level.
There is a CUE button for CH3 allowing the user to monitor the signal pre volume control.
The microphone (MIC) input is on balanced XLR, there is a gain adjustment and phantom power
(18V) switch accessible through the base of the unit. The MIC also has a 2 band EQ accessible
through the base of the unit allowing MIC EQ to be set prior to use.
The MIC can be set to be in or out of the booth by another switch also accessible through the base
of the unit.
There is a volume control for the MIC input and a CUE button allowing the user to monitor the
signal pre volume control.
The MIC channel has 2 - s to indicate MIC input level, left is Green/Yellow and bi colour LED’
right is Yellow/Red.
When left green ashes slowly it indicates a signal of about -20dB and at -7dB it comes fully
on.
When left yellow ashes it indicates a signal of -3dB and at +1dB it comes fully on. When
right yellow comes on it indicates +4dB and when right red comes on it indicates +12dB or
clip level.
Headphones
The headphone output is on a 3 pole ¼” jack socket on the front vertical face of the FF2.2, the
output will drive headphones of greater than 32 ohms impedance.
The headphone controls include volume, CUE mix, split and pre/post EQ CUE selection. When
CUE is selected on one of the channels or MIC then that signal will be available at the headphone
control, note if multiple CUE buttons are pressed then there will be a mix of those signals selected.
