Professional On-Line & Line-Interactive UPS Solutions
True Double Conversion 1.0kVA - 20kVA & 30kVA - 800kVA
Output Power Factor 0.9 - Rack/Tower 2 in 1 Design - LCD Display - Perfect Battery Pack
IndusPower Online UPS Systems
40kVA/60kVA/80kVA with battery bank solution, 3-Phase Input / 3-Phase Output
Induspower Series, applied with state-of-the-art PWM-transformerless technology, can easily adapt to all kinds of diverse and
complicated loads, such as the non-linear systems (IT systems), strongly inductive or capacitive loads, discharge lamps, and
induction motors. It is designed in terms of criteria of maximum efficiency and energy savings with highly compact format. Each
unit also has a wide range of communication possibilities and a large variety of options to fill out customers’ diverse inquiries. To
facilitate expansion easily, this unit can be set up in parallel-redundant systems without any need for additional hardware in the
near future.
Features & Advantages
●
●
●
●
●
●
●
●
●
●
●
●
Online double conversion technology with DSP control
Advanced control with Adaptive Feed Forward Cancellation (AFC) technology for very low harmonic
distortion
Very low input current distortion (THDi < 1%)
Input power factor 0.99 at 10% load
Output efficiency up to 95%
Space-saving compact design
Over 60% materials recyclable
Front access makes maintenance and replacement easily
Highly flexibility in single phase/ three-phase set-UPS
Parallel redundant operation with up to 4 units
Variety of communications and options available
Remaining backup time calculation
Induspower Series
40 / 60 / 80 kVA
Battery Bank Battery Bank Size (mm) Battery Capacity Battery Brand
BB-744/18T 1150 x 470 x 1190 744V / 18Ah Yuasa
BB-744/26T 780 x 880 x 1190 744V / 26Ah Yuasa
BB-744/65T 1500 x 900 x 1370 744V / 65Ah Yuasa
BB-744/100T 1500 x 900 x 1370 744V / 100Ah Yuasa
Backup Time Table
UPS + Battery Bank Capacity Bacup Tim (min) Battery Brand
100% Load 75% Load
Induspower
IN-3340TL
Tower
40.0kVA
+ 1 x BB-744/18T - 744V/18Ah 9,5 17,1 Yuasa
+ 1 x BB-744/38T - 744V/38Ah 33 47 Yuasa
+ 1 x BB-744/65T - 744V/65Ah 61 80,5 Yuasa
+ 1 x BB-744/100T - 744V/100Ah 93,5 130 Yuasa
Induspower
IN-3360TL
Tower
60.0kVA
+ 1 x BB-744/26T - 744V/26Ah 9,4 14 Yuasa
+ 1 x BB-744/38T - 744V/38Ah 15,9 23 Yuasa
+ 1 x BB-744/65T - 744V/65Ah 26,6 38 Yuasa
+ 1 x BB-744/100T - 744V/100Ah 61 87 Yuasa
Induspower
IN-3380TL
Tower
80.0kVA
+ 1 x BB-744/26T - 744V/26Ah 6 9,4 Yuasa
+ 1 x BB-744/38T - 744V/38Ah 9,3 15,2 Yuasa
+ 1 x BB-744/65T - 744V/65Ah 18,2 25 Yuasa
+ 1 x BB-744/100T - 744V/100Ah 27,1 41 Yuasa
P Model kVA Datasheet Manual SNMP Card Software Inquiry
1 IN-3340-TL 40.0 kVA
2 IN-3360-TL 60.0 kVA PDF PDF Go to SNMP Go to Software To join FSP
3 IN-3380-TL 80.0 kVA
Specification
Model IN-3340-TL IN-3360-TL IN-3380-TL
Phase 3 phase in / 3 phase out
Capacity 40.0 kVA / 32kW 60.0 kVA / 48kW 80.0 kVA / 64kW
Input
Nominal Voltage 3x 400V (3Ph + N)
Acceptable Voltage Range +15% / -20%
Frequency Range 50/60Hz ± 5%
Total Harmonic Distortion (THD)
< 1.5% @ 100% load
< 2.5% @ 50% load
< 6.5% @ 10% load
< 1.0% @ 100% load
< 2.0% @ 10% load
< 5.0% @ 50% load
< 1.5% @ 100% load
< 2.0% @ 50% load
< 6.0% @ 10% load
Current Limitation High overload: PFC Limit (discharging batteries)50 / 60 Hz ±5 %
Power Factor 1.0
Inverter
Nominal Voltage 3x400 VAC (3Ph + N) 208/220/230/240VAC
Precision Stationary: ±1% ; Transitory: ±2% (load variations 100-0-100%)
Frequency 50/60 Hz synchronised ±4 % With mains absent ±0.05%
Max. Synchronisation Speed ±10 Hz/s
Waveform Pure Sinewave
Total Harmonic Distortion (THD) ≦ 0.5% THD (Linear Load) ; ≦ 1.5% THD (Non-linear Load)
Phase Displacement 120º ±1% (balanced load) ; 120º ±2% (imbalances 50% of the load)
Dynamic Recovery Time 10 ms. at 98 % of the static value Pure Sinewave
Admissible Overload 125% for 10 min., 150% for 60 s
Admissible Crest Factor 3.2:1 2.8:1
Admissible Power factor 0.7 inductive to 0.7 capacitive
Imbalance Output Voltage
@ 100% Unbalanced Load <1%
Current Limit High overload, short-circuit: RMS Voltage Limit ; High Crest-Factor current: Peak Voltage Limit
Static Bypass
Type Solid State
Voltage 3x400V (3Ph + N)
Frequency 50/60 Hz
Activation Criterion Microprocessor Control
Transfer Time Zero
Admissible Overload 400% for 10sec.
Transfer to Bypass Immediate, for overloads above 150%
Retransfer Automatic after alarm clear
AC Input & Output Connectors
AC Input Connector Ter mina l
AC Output Connector Ter mina l
Standards
IEC 62040-1 (safety) Yes
IEC-62040-2 (EMC) Yes
CE Yes
Maintenance Bypass
Type Without Interruption
Voltage 3x400V (3Ph + N)
Frequency 50/60 Hz
Overall Efficiency (Line Mode) 92.5% 93% 94%
Physical dimensions
Long-Run
Model
Dimension (mm) 805 (D) x 590 (W) x 1320 (H) 805 (D) x 590 (W) x 1320 (H) 805 (D) x 590 (W) x 1320 (H)
Net Weight (kgs) 180 210 230
Induspower Series Backup Time Table
Induspower 40.0 kVA - 62 Batteries, Battery Voltage 744V, Charging Current 0,2C
External Battery Type Sets 100% Full Load (in min.) 75% Load (in min.)
17 Ah (CSB GP12170)
1 8,5 14,1
2 28,2 41,1
3 49 71
26 Ah (CSB GP12260)
1 16,7 24,5
2 42,5 60,9
3 70,9 98,5
40 Ah (CSB GP12400)
1 23,9 35,2
2 60,9 86,8
3 102,3 145,8
65 Ah (CSB GP12650)
1 40,4 61,2
2 114 172,7
3 204 288
100 Ah (CSB GP121000)
1 75,5 115
2 210 293
3 347 489
