ACTIVE TUBE
SPECIFICATIONS
 CS-AT1100
PeakPower(Watts) 360
RatedPower(Watts)120
FrequencyResponse 36Hz-250Hz
LowPassFilter(Variable) 40Hz-250Hz
TuningBassReex
WooferSize 10”
Fuse20A
Dimensions(mm) 559(l)x306(w)x306(h)
 22-1/32x12-1/16x12-1/16”
CS-AT1100
www.fusionelectronics.com
CONTROL DESCRIPTIONS
LEVEL
Thisallowstheadjustmentoftheamplierlevelofthesubwoofer.
Turnclockwisetoincreasethelevel.Ifthesoundbecomesdistorted
reducethelevel.
LOW PASS FILTER (LPF)
This allows the adjustment of the highest frequency the Active
Tubewillproduce.Thisshouldbeadjustedtoblendwithyourmain
speakers.Typically,thiswillbesettoaround100Hz(approximately
thecentralpositionofthecontrolknob).
REMOTE LEVEL CONTROLLER
Whenconnected,thisallowsfurthercontroloverthelevelfroma
remotelocation,usingthesuppliedlead.
INSTALLATION
Makesure the ActiveTubeis rmlyxed inyour vehicle.Check
beforedrillingorcuttingholes.DONOTworkneargastanks,fuel
lines,hydrauliclinesorelectricalwiring.
DONOTmounttheActiveTubeinsuchawayastopinchordamage
thewires.
Make sure everything is rmly connected, before attaching the
+12Vwire.Ensurethe+12Vwireisfusedascloseaspossibletothe
battery.Alwaysuseafusewiththerecommendedrating.
DISCLAIMER
AlwaysensuretheActiveTubeissecurelyattached,toavoidmovement.FUSIONacceptsnoresponsibilityfordamageorinjuryinrelation
toinappropriatesecuringofthisproduct.
WIRING
• Connectthegroundwiretothevehiclerst(cleandirtandpaint
 tobaremetal).
• Connecttheremoteon(bluewire).
• ConnecttheRCAcablesifapplicable,OR
• Connectthespeakerlevelwirebysplicingintotheheadunits
 speakerwires.See onreverse.Note1
• Connecttheremotelevelcontrollerwiththesuppliedlead.
• Connectthe12volt(redwire)tothepositivebatteryterminal.
• Checkallconnections.
PUBLISHEDBYFUSIONELECTRONICSLIMITED:©Copyright2010byFUSIONElectronicsLimited.Allrightsreserved.Specicationsanddesignaresubjecttochangewithoutnotice.
YOUCANHELPPROTECTTHEENVIRONMENT!Pleaseremembertorespectthelocalregulations:Handinthenon-workingelectricalequipmenttoanappropriatewastedisposalcenter.
RECORD YOUR PURCHASE DETAILS HERE:
SERIALNUMBER
DATEOFPURCHASE
AFFIXRECEIPTHERE
WARNING:AudioSystemscanproducesoundlevelsover135dB.Continuousexposuretosoundpressurelevelsover100dBmaycausepermanent
hearingloss!Pleasewatchforemergencyvehiclesaswarningsignalsmaynotbeheard.USECOMMONSENSE!
Forfurtherproductandinstallationinformation,pleasevisitwww.fusionelectronics.com
Pourplusd’informationssurlesproduitsetl’installation,rendez-voussurwww.fusionelectronics.com
Paraobtenermásinformaciónacercadelosproductosydesuinstalación,visiteelsitiowebwww.fusionelectronics.com
Bezoekwww.fusionelectronics.comvoormeerproduct-eninstallatie-informatie.
WeitereProdukt-undInstallationsinformationenndenSieunterwww.fusionelectronics.com
Perulterioriinformazionisuiprodottielaloroinstallazione,potetevisitarewww.fusionelectronics.com
Для получения дополнительной информации о продуктах и установке зайдите, пожалуйста, на: www.fusionelectronics.com
Note 1
Takecaretomakesurethewires
aresplicedinthecorrectphase.
Positivetopositive,negativeto
negative.Failuretodothiscorrectly
couldresultinlossofbass.
SeeNote1
Spliceintosource
unit’sspeakerwires
(R+)Grey/White
(R-)Grey
(L+)Green/White
(L-)Green
Connecttheremote
levelcontrollerleadto
theamplier
Connectredwire
topositive(+12V)
batteryterminal
Connectbluewiretosourceunit’s
accessoryleadorswitched12volt
source(REM)
Connectblackwire
tochassisground
ofvehicle(Ground)
SpeakerLevel
InputPlug
RemoteLevelController
VehicleBattery
