Side 1/20
Side by Side Refrigerators
Design Guide
With Installation Instructions
If you have questions,call 800.626.2000 or visit our website at: www.monogram.com
Installation
Instructions
Safety Information
Skill Level – Installation of this refrigerator
requires basic mechanical, carpentry and plumbing
skills. Proper installation is the responsibility of the
installer. Product failure due to improper installation
is not covered under the GE Appliance Warranty.
See the Owner’s Manual for warranty information.
WARNING:
• These refrigerators are top-heavy and must
be secured to prevent the possibility of tipping
forward. Anti-Tip protection is required. See
page 12 for details.
• Use this appliance only for its intended purpose.
• Immediately repair or replace electric service cords
that become frayed or damaged.
• Unplug the refrigerator before cleaning or making
repairs.
• Repairs should be made by a qualified service
technician.
AVERTISSEMENT
• Ces réfrigérateurs sont lourds en haut et il faut les
arrimer pour éviter leur basculement. Il faut avoir
un système de protection contre le renversement.
Voir les détails page 12.
• Il ne faut utiliser cet appareil que pour l’utilisation
appropriée.
• Réparer ou remplacer immédiatement tout cordon
électrique effiloché ou endommagé.
• Il faut débrancher le réfrigérateur avant le
nettoyage ou toute intervention.
• Les réparations doivent être faites par un
technicien qualifié.
For Monogram local service in your area, call
1.800.444.1845.
For Monogram service in Canada, call
1.888.880.3030
For Monogram Parts and Accessories, call
1.800.626.2002.
www. monogram.com
2
BEFORE YOU BEGIN
Read these instructions completely and carefully.
• IMPORTANT – Save these instructions
for local inspector’s use. Observe all governing codes
and ordinances.
• Note to Installer – Be sure to leave these
instructions with the Consumer.
• Note to Consumer – Keep these instructions
with your Owner’s Manual for future reference.
WARNING:
This appliance must be properly grounded. See
“Grounding the Refrigerator,” page 10.
AVERTISSEMENT
Cet appareil doit être correctement mis à la terre.
Consulter « Mise à la terre du réfrigérateur », page 10.
If you received a damaged refrigerator, you should
immediately contact your dealer or builder.
CAUTION:
Due to the weight and size of this refrigerator, and
to reduce the risk of personal injury or damage to
the product – THREE PEOPLE ARE REQUIRED
FOR PROPER INSTALLATION OF A 36" WIDE
UNIT. FOUR PEOPLE ARE REQUIRED FOR
INSTALLATION OF A 42" OR 48" WIDE MODEL.
PRUDENCE
À cause du poids et de la taille de ce réfrigérator et
pour réduire le risque de blessure et de dommages,
IL FAUT TROIS PERSONNES POUR INSTALLER
CORRECTEMENT D’UN APPAREIL DE 91 cm (36 po)
DE LARGE. IL FAUT QUATRE PERSONNES POUR
L’INSTALLATION D’UN MODÈLE DE 107 OU 122 cm
(42 OU 48 po) DE LARGE.
CONTENTS
Planning Guide
The Installation Space ....................................3
Dimensions and Clearances ..........................3
130° Door Swing ..............................................4
90° Door Swing ................................................5
Customization Basics ......................................6
1/4" Framed Panel Dimensions ......................7
3/4" Overlay Panel Dimensions ......................8
Raised Overlay Panel Design ........................9
Side Panels......................................................10
Installation Instructions
Tools, Hardware, Materials ........................10
Grounding the Refrigerator ..........................10
Step 1, Remove Packaging ..........................11
Step 2, Install Water Line ............................11
Step 2A, RO Water Line ................................12
Step 3, Install Side Panels ..........................12
Step 4, Install Anti-Tip Brackets ................12
Step 5, Level Refrigerator ............................13
Step 6, Alternate Anti-Tip Procedure ........13
Step 7, Secure Refrigerator to Cabinetry ..14
Step 8, Adjust Door Swing ..........................14
Step 9, Install Grille Panel ............................14
Step 10, Install Framed Panels ....................15
Step 10A, Install Overlay Panels ..........16–17
Step 11, Install Dispenser Trim ....................18
Step 12, Connect Water Supply ..................18
Step 13, Connect Power ..............................19
Step 14, Start Icemaker ................................19
Step 15, Install Toekick ................................19
