Side 1/2

ROOM THERMOSTAT PLACEMENT

Place your Room Thermostat in a room you use frequently in your

living space. For example; like the hall or living room of your home.

Avoid installing the Room Thermostat in places where there is a lot of

air circulation, such as at the doorway or by the window. Also, do not

place it close to heating units (heater core, ﬁreplace, etc.) and in direct

sunlight. We recommend that the room thermostat is placed at a

height of 150 cm from the ﬂoor.

ROOM THERMOSTAT WORKING PRINCIPLE

As soon as you energize your Room Thermostat, it will start working.

Your Room Thermostat measures the temperature of the

environment it is in every 5 seconds. If the ambient temperature rises

0.5 degrees above the temperature you set, your Room Thermostat

turns off the heating unit, and if it falls below 0.5 degrees, it turns on

the heating unit.

If the ﬂoor sensor measures temperature above 28°C, it turns off the

heating unit. The ﬂoor sensor operating sensitivity is ±1°C.*

Thus, it is ensured that the ambient temperature remains within a

certain range.

*External ﬂoor sensor is only active when it is connected.

Note: If a ﬂoor sensor is installed with Room Thermostat, only

GENERAL Life ﬂoor sensor should be installed. Otherwise, the

product will be out of warranty.

ROOM THERMOSTAT WIRING DIAGRAM

GENERAL SPECIFICATIONS

FH10/FH10S is a ﬂoor heating room thermostat. User provides more

comfortable and affordable heating by setting needed room

temperature.

 Sensitive Temperature Measurement

 Wired Connection

ON / OFF Control

FH10/FH10S AND EQUIPMENTS

TECHNICAL DATA

ROOM THERMOSTAT

Room Thermostat Indicator LED Descriptions

Room Thermostat

85.7mm / 85.7mm / 33.5mm

230V AC

7A (240VAC – Resistive load)

10A (120VAC – Resistive load)

0.1 C

0.5 C

o o

(5 C) – (30 C)

o o

(-10 C) – (+50 C)

o o

(-20 C) – (+60 C)

Dowels and

Screws

Dimensions ( H / L / W )

Operating Current

Relay NO Switching Current

Temperature Measurement

Accuracy

Operating Sensitivity

Operating Temperature Range

Operating Temperature

Storage Temperature

150 cm

min. 20 cm

ENGLISH

generallife.com.tr

UNDERFLOOR HEATING THERMOSTAT

Set Button

Indicator LED

Heating unit is working

Heating unit is not working

LED light is on

LED light is off

generallife.com.tr

UNDERFLOOR HEATING THERMOSTAT

WIRING DIAGRAM FOR ACTUATOR

WIRING DIAGRAM FOR WIRING CENTER

WARNING!

Operations related to the control panel, heating unit or electrical

installation must be carried out by persons with professional

qualiﬁcations.

NTC

WARNING!

The assembly of product

should be done according to

the image above.

For electrical connection,

please see diagram 5.

Should not be used in case

the usage of a wiring center.

N L

230V AC

ACTUATOR

N L

230V AC

WIRING

CENTER

FH10/FH10S

USER MANUAL

FH10/FH10S USER MANUAL

SERIES:

MITRA, ADEN, ARUNA, CERES, GAIA, ILLONA, NORA, SENNA, TERRA,

THERMA

SERIES:

MITRA, ADEN, ARUNA, CERES,

GAIA, ILLONA, NORA, SENNA,

TERRA, THERMA
