G901 User Guide Document: G901-2
---------------------------------------------------------------------------------------------------------------------------------------------
1
Table of Contents
Disclaimer/Copyright statement........................................................................................................ 3
Warranty/RMA and FCC/CE statement.............................................................................................. 3
Introduction……………………………………………………………………………............................ 4
Outlook………………………………………………………………………………………………………. 5
User Guide
1. How to use IR Remote Controller.............................................................................................. 6
1.1. Key pad functions and extension cable……………………………………………………… 6
1.2. Change OSD language…………………………………………………………………………… 7
1.3. Individual OSD control in multiple unit application………………………………………... 7
1.4. OSD Lock and Unlock…………………………………………………………………………… 7
1.5. Change OSD location……………………………………………………………………………. 7
2. System Reset……………………………………………………………………………………………. 8
3. Front panel…………….......……………………………………………………………………………. 9
4. Back panel………………………………………………………………………………………………. 9
5. Seamless input source switching……….……….….................................................................. 10
6. Output signal and output port configuaration....................................................…………....... 10
7. Typical system connection…………………………………………………………………………… 11
8. Select input port
8.1. Select input port from OSD……………………………………………………………………… 11
8.2. Select input port from remote controller……………………………………………………… 12
9. Set output resolution and signal type ……………………………………………………………… 12
9.1. Select output resolution from remote controller……………………………………………. 13
9.2. Select output resolution from OSD preset mode..…………………………………………. 13
9.3. Programmable output resolution………………………………………………………………. 14
9.4. Enable 10-bit deep color output ………………………………………………………………. 15
9.5. HDR (BT.2020) processing……………………………………………………………………… 16
10. How to check system Information…………………………………………………………………… 16
11. System Control and setup……………………………………………………………………………… 17
11.1. Box ID…………………….................................................................................................... 18
11.2. Multi-units controlled by one remote controller............................................................ 18
11.3. RS232 setting……………………………………………………………………………………. 18
11.4. Ethernet setting................................................................................................................. 19
12. PIP/POP multiple window display
12.1. Main menu……………………………………………………………………………………….. 20
12.1.1. [Display]—select different multi-window display types…………………………… 20
12.1.2. [Size]—Change sub-window image size under [PIP] & [3x SBS]………………… 22
12.1.3. [Position]—Set PIP image position……………………………………………………. 22
12.1.4. [Ratio]—Display full range image or keep original aspect ratio…………………. 22
12.1.5. [Source] selection………………………………………………………………………… 23
12.1.6. [Rotation]: Sub-window image rotation………………………………………………. 24
12.1.7. [Overlap]-- Adjust cropping area and aspect ratio…………………………………. 25
