Side 1/2

January 25, 2019

GV-PA482 PoE Adapter

The GV-PA482 is a Power over Ethernet (PoE) adapter designed to provide power to the IP

camera through a single Ethernet cable. Adopting the PoE adapter enables you to mount an

IP camera anywhere in a building where power outlets are not available.

Packing List

1. GV-PA482 PoE Adapter x 1

2. Power Adapter (DC 48V, 2.5A, 120 W)

Connections

Two Ethernet cables are required for the connection.

1. Connect one end of the first Ethernet cable into the PoE 10/100 port on the GV-PA482,

and the other end to your camera.

2. Connect one end of the second Ethernet cable into the LAN 10/100 port on the GV-

PA482, and the other end to the hub or router connecting to your computer.

3. Insert the white wire of the supplied DC power adapter left-side pin of the terminal block

on the GV-PA482, and the black wire to the right-side pin.

LAN 10/100

Power IN

January 25, 2019

4. Attach the AC power cord to the DC power adaptor.

5. Connect the AC power cord to the power outlet. The Power LED on the front panel of the

GV-PA482 turns green now.

Specifications

PoE Standard

High Power Over Ethernet (Max. 120 W)

PoE Output (10 / 100 Out)

DC 48V, 2.5A (Max. 120 W)

Ethernet Cable Length

Max 100 m (328 ft) from GV-PA482 to IP device, CAT5e

Power Input

AC 100V ~ 240V, 2.5A

Operating Temperature

-10°C ~ 50°C (14°F ~ 122°F)

Dimensions (L x W x H)

43 x 69 x 40 mm (1.69 x 2.72 x 1.57”)

Weight

130 g (0.29 lb)

All specifications are subject to change without notice.



Produkt Specifikationer

Mærke:	Geovision
Kategori:	Netværkskort/adapter
Model:	GV-PA482
Bredde:	69 mm
Dybde:	43 mm
Højde:	40 mm
Vægt:	130 g
Ethernet LAN-porte (RJ-45):	1
Driftstemperatur (T-T):	-10 - 50 °C
Ethernet LAN-datahastigheder:	10, 100 Mbit/s
Indgangsspænding for vekselstrømsadapter:	100 - 240 V
Udgangseffekt:	120 W
Kabelteknologi:	10/100
Plug and play:	Ja
Indgangsstrøm:	2.5 A
Strøm over Ethernet (PoE):	Ja
Maksimal driftstilstand:	100 m
Ethernet-grænsefladetype:	Hurtigt ethernet
Antal produkter inkluderet:	1 stk
Understøttede kabeltyper:	Cat5e
Power over Ethernet (PoE) spænding:	48 V
