Certiﬁ ed by NSF International to go above and beyond standard performance!

NSF ANSI 8 2010 Standard

Project Name: AIA#: Model #:

Approved By:

Date:

3850N / 3975N

Premium

Heavy-Duty

Automatic Slicers

Premium Models:

r 3850N Two Speed Auto Slicer

r 3975N Nine Speed Auto Slicer

Premium Construction

• 13'' ™ hardened steel alloy knife PreciseEdge

blade with maximum tip-edge-holding ability

• Exclusive stainless steel construction, with

superior corrosion resistance against acids found

in fruit, meats and vegetables

• Best of the Best, ™ tableEZ-Glide

• No-drip base with Marine edge redirects liquids to

center of base away from controls and operator

• Precise slice-thickness adjustment, one-piece

handle, gear driven, and gasket-sealed

• Carriage angle: 45°, full gravity feed

• 2° angled drip groove on the slicer table directs

the  ow of liquids to the base

• 12'' long chute with 3 lb. stainless steel end weight

• Powerful 1/2 HP, 7 amp continuous use motor

• High-performance gear knife drive

• Maintenance-free drive system

• Permanently attached knife ring guard with

removable slice de ector

Food Zone Features

• Large stainless steel radii, open space base design

for cleaning and simple dismantling of components

• Base has a Marine edge from 1/2'' to 3/4'' wide and

indented areas with 3/16'' deep radiused transition

and 3/16'' deep internal coved corners. Both are

integral to the base’s work surface

• Knife sharpening system is removable and BPA Free

(no-bisphenol-A), immersible, and dishmachine-safe

for cleaning and sanitizing

• Moisture proof, easy-to-clean direct contact start/stop

touchpad controls

• Sealed splash zones for added sanitation and

protection of electronics

Operator Protection Features

• No voltage release prevents inadvertent reactivation

of slicer in the event of power or interlock interruption

• Knife cover interlock prevents slicer from operating

without the knife cover in place

• Permanent knife blade ring guard, removable cover,

and de ector.

• Touch pad start/stop controls and power indicator

light

• Ergonomic low-pro le design reduces operator

fatigue

• Dual arm lift lever for cleaning and sanitizing under

the slicer

Premium Heavy-Duty Automatic Slicers 3850N / 3975N

GLOBE FOOD EQUIPMENT COMPANY

Made in the U.S.A.

2010

2153 Dryden Rd., Dayton, OH 45439

Phone: 937-299-5493 Fax: 937-299-4147

800-347-5423

www.globeslicers.com

GLOBE FOOD EQUIPMENT COMPANY

Location: SIS#: Item #: Quantity:

Premium Heavy-Duty Automatic Slicers 3850N / 3975N

2153 Dryden Rd.

Dayton, OH 45439

Phone: 937-299-5493

Phone: 800-347-5423

Fax: 937-299-4147

Specications are subject to change without notice.Printed in U.S.A. 06-2012

GLOBE FOOD EQUIPMENT COMPANY

www.globeslicers.com

Ver. 1. 0612-B Rev. 1 GFE0812

FACTORY INSTALLED OPTIONS:

Cord & Plug: Attached 7 foot exible 3-wire cord with molded plug ts a grounded receptacle. NEMA 5-15

3850N / 3975N

Note: Different chute options

will change overall height

Drawings available through KCL. www.kclcad.com

SLICER ENHANCEMENT ACCESSORIES:

r Quick-Clean™ proprietary non-stick

nickel-based coating (knife cover and

slice table)

r Correctional package

r High moisture application package

(includes 13'' stainless steel knife)

r 15'' long food chute

r 13'' stainless steel knife

• 15 years on the knife drive gears

• Two-years parts

• One-year labor

WARRANTY:

r Stainless steel low food fence

(12'' L x 1 ⅜'' H)

r Stainless steel high food fence

(12'' L x 3'' H)

r 7'' D x 14'' L Stainless steel

vegetable hopper

r Clear plastic slicer cover

(Tip: Recommended for preconstruction)

r Additional cleaning brush

Warranty valid in North America.

Contact factory for warranty in other countries

Model Elevation Right Plan Back BIM 3D Revit

3850N

3975N

Plan / Top View

Side View

Side View/Lift Lever

Elevation / Front View

SPECIFICATIONS

Model Auto or

Manual

Motor Volts Amps Drive

Type

Slicing Volume

per Day

Cheese

Slicing

Blade

Diameter

Max

Slice

(Diameter)

(Width)

(Height)

3850N Both 1/2 HP 115-60-1 7 Gear All Day

100%0

Time

13''

(33.02 cm)

1-1/4''

(3.18 cm)

7.5''

(19.50 cm)

11.6''

(29.46 cm)

9''

(22.86 cm)

3975N Both 1/2 HP 115-60-1 7 Gear All Day

100%0

Time

13''

(33.02 cm)

1-1/4''

(3.18 cm)

7.5''

(19.50 cm)

11.6''

(29.46 cm)

9''

(22.86 cm)

Product Cutting Capacity

DIMENSIONS & SHIPPING INFORMATION

Cartons are reinforced for shipping. The weight and dimensions of this reinforced carton are included below, may vary from shipment to shipment and may include the

weight from an attached skid.

Model Foot Print Overall Dimensions Net Weight Shipping Dimensions Shipping Weight

3850N/

3975N

14'' D x 21.6'' W

(35.5 cm x 54.8 cm)

26.7'' L x 23'' W x 25.1'' H

(69.7 cm x 58.5 cm x 63.7 cm)

145 lbs.

(67.1 kg)

28'' L x 25'' W x 34'' H

(71.1 cm x 63.5 cm x 86.4 cm)
